General-purpose timers (TIM15/TIM16/TIM17)
25.5.15

TIM15 capture/compare register 2 (TIM15_CCR2)

Address offset: 0x38
Reset value: 0x0000
15
14
13
rw
rw
rw
Bits 15:0 CCR2[15:0]: Capture/Compare 2 value
25.5.16

TIM15 break and dead-time register (TIM15_BDTR)

Address offset: 0x44
Reset value: 0x0000 0000
31
30
29
Res.
Res.
Res.
BKBID
15
14
13
MOE
AOE
BKP
BKE
rw
rw
rw
Note:
As the BKBID, BKDSRM, BKF[3:0], AOE, BKP, BKE, OSSI, OSSR and DTG[7:0] bits may
be write-locked depending on the LOCK configuration, it may be necessary to configure all
of them during the first write access to the TIMx_BDTR register.
Bits 31:29 Reserved, must be kept at reset value.
Bit 28 BKBID: Break Bidirectional
0: Break input BRK in input mode
1: Break input BRK in bidirectional mode
In the bidirectional mode (BKBID bit set to 1), the break input is configured both in input
mode and in open drain output mode. Any active break event asserts a low logic level on the
Break input to indicate an internal break event to external devices.
Note: This bit cannot be modified as long as LOCK level 1 has been programmed (LOCK bits
Note: Any write operation to this bit takes a delay of 1 APB clock cycle to become effective.
798/1390
12
11
10
9
rw
rw
rw
rw
If channel CC2 is configured as output:
CCR2 is the value to be loaded in the actual capture/compare 2 register (preload value).
It is loaded permanently if the preload feature is not selected in the TIMx_CCMR2 register
(bit OC2PE). Else the preload value is copied in the active capture/compare 2 register when
an update event occurs.
The active capture/compare register contains the value to be compared to the counter
TIMx_CNT and signalled on OC2 output.
If channel CC2 is configured as input:
CCR2 is the counter value transferred by the last input capture 2 event (IC2).
28
27
26
25
BK
Res.
Res.
DSRM
rw
rw
12
11
10
9
OSSR
OSSI
LOCK[1:0]
rw
rw
rw
rw
in TIMx_BDTR register).
8
7
6
CCR2[15:0]
rw
rw
rw
24
23
22
Res.
Res.
Res.
8
7
6
rw
rw
rw
RM0444 Rev 5
5
4
3
2
rw
rw
rw
rw
21
20
19
18
Res.
Res.
rw
rw
5
4
3
2
DTG[7:0]
rw
rw
rw
rw
RM0444
1
0
rw
rw
17
16
BKF[3:0]
rw
rw
1
0
rw
rw
