2 On the View Control Bar, click
3 In the Graphic Display Options dialog, in the Edges panel, select a Silhouette style (for example,
4 Click OK.
To remove a line style from a silhouette edge:
1 Click Modify tab
2 Click Linework tab
3 Select the edges in silhouette, and the silhouette is removed.

Finding Referring Views

The Find Referring Views tool locates all views where the view annotation symbol is visible. For example, if
you activate this tool for an elevation view, the Go to View dialog opens and lists all views where the elevation
symbol is currently visible.
You can activate this tool from the Project Browser or in the drawing area.

Finding a View Symbol

1 In the Project Browser, right-click the view for which you want to locate view annotation symbols.
2 Select Find Referring Views.
3 In the Go To View dialog, select a view.
4 Click Open View.

Managing Views

The following topics describe different ways to manage project views to simplify your workflow and help
to manage your building project.

Customizing Project View Organization in the Project Browser

You can sort views and sheets in the Project Browser using any of the property values for the view or sheet.
For example, the following image shows views in the Project Browser organized by discipline, then by phase,
and then by view type. The top level of the Views branch also shows the name of the sort group currently
applied (in this case, Discipline).
Wide Lines).
Edit Linework panel
Element panel, and from the Type Selector, select <Not Silhouette>.
For more information about the Linework tool, see
398.
You can also open the view, and right-click in the drawing area.
The view opens with the view symbol selected.
(Shadows Off/On) Graphic Display Options.
Linework.
Changing the Line Style of Elements on page
Finding Referring Views | 255
