Table 174. Cyclone 10 GX Dynamic Reconfiguration Feature Support
Reconfiguration
Channel Reconfiguration
PLL Reconfiguration
Related Information
Unsupported Features

6.2. Interacting with the Reconfiguration Interface

Each transceiver channel and PLL contains an Avalon Memory-Mapped (Avalon-MM)
reconfiguration interface. The reconfiguration interface provides direct access to the
programmable space of each channel and PLL. Communication with the channel and
PLL reconfiguration interface requires an Avalon-MM master. Because each channel
and PLL has its own dedicated Avalon-MM interface, you can dynamically modify
channels either concurrently or sequentially, depending on how the Avalon-MM master
is connected to the Avalon-MM reconfiguration interface.
® ®
Intel Cyclone 10 GX Transceiver PHY User Guide
316
6. Reconfiguration Interface and Dynamic Reconfiguration
PMA analog features
• V
OD
• Pre-emphasis
• Continuous Time Linear Equalizer (CTLE)
TX PLL
• TX local clock dividers
• TX PLL switching
RX CDR
• RX CDR settings
• RX CDR reference clock switching
Reconfiguration of PCS blocks within the datapath
Datapath switching
• Standard, Enhanced, PCS Direct
PLL settings
• Counters
PLL reference clock switching
on page 371
UG-20070 | 2018.09.24
Features
Send Feedback
