Enable TX polarity inversion
Enable tx_polinv port
Enable RX bit reversal
Enable rx_std_bitrev_ena port
Enable RX byte reversal
Enable rx_std_byterev_ena port
Enable RX polarity inversion
Enable rx_polinv port
Enable rx_std_signaldetect port
All options under PCIe Ports

2.6.2. 10GBASE-R and 10GBASE-R with IEEE 1588v2 Variants

10GBASE-R PHY is the Ethernet-specific physical layer running at a 10.3125-Gbps
data rate as defined in Clause 49 of the IEEE 802.3-2008 specification. Cyclone 10 GX
transceivers can implement 10GBASE-R variants like 10GBASE-R with IEEE 1588v2.
The 10GBASE-R parallel data interface is the 10 Gigabit Media Independent Interface
(XGMII) that interfaces with the Media Access Control (MAC), which has the optional
Reconciliation Sub-layer (RS).
® ®
Intel Cyclone 10 GX Transceiver PHY User Guide
98
2. Implementing Protocols in Intel Cyclone 10 GX Transceivers
Parameters
UG-20070 | 2018.09.24
Value
On/Off
On/Off
Off
Off
Off
Off
On/Off
On/Off
On/Off
Off
