2. Implementing Protocols in Intel Cyclone 10 GX Transceivers
UG-20070 | 2018.09.24
Parameter
RX rate match insert/
delete +ve pattern (hex)
Enable rx_std_rmfifo_full
port
Enable
rx_std_rmfifo_empty port
Table 29. Word Aligner and Bitslip Parameters
Parameter
Enable TX bitslip
Enable tx_std_bitslipboundarysel
port
RX word aligner mode
RX word aligner pattern length
RX word aligner pattern (hex)
Number of word alignment
patterns to achieve sync
Number of invalid words to lose
sync
Number of valid data words to
decrement error count
Enable fast sync status reporting
for deterministic Latency SM
Enable rx_std_wa_patternalign
port
Send Feedback
Range
User-specified 20 bit Specifies the +ve (positive) disparity value for the RX rate match
pattern FIFO as a hexadecimal string.
On / Off
Enables the optional
On / Off
Enables the
Range
On / Off When you turn on this option, the PCS includes the bitslip
function. The outgoing TX data can be slipped by the
number of bits specified by the
tx_std_bitslipboundarysel
On / Off
Enables the
bitslip Specifies the RX word aligner mode for the Standard PCS.
The word aligned width depends on the PCS and PMA width,
manual (PLD
and whether or not 8B/10B is enabled.
controlled)
Refer to "Word Aligner" for more information.
synchronous state
machine
deterministic
latency
7, 8, 10, 16, 20, Specifies the length of the pattern the word aligner uses for
32, 40 alignment.
Refer to "RX Word Aligner Pattern Length" table in "Word
Aligner". It shows the possible values of "Rx Word Aligner
Pattern Length" in all available word aligner modes.
User-specified Specifies the word alignment pattern in hex.
Specifies the number of valid word alignment patterns that
0-255
must be received before the word aligner achieves
synchronization lock. The default is 3.
Specifies the number of invalid data codes or disparity
0-63
errors that must be received before the word aligner loses
synchronization. The default is 3.
Specifies the number of valid data codes that must be
0-255
received to decrement the error counter. If the word aligner
receives enough valid data codes to decrement the error
count to 0, the word aligner returns to synchronization lock.
On / Off When enabled, the
immediately after the deserializer has completed slipping
the bits to achieve word alignment. When it is not selected,
rx_syncstatus
complete and the word alignment pattern is detected by the
PCS (i.e.
is only applicable when the selected protocol is CPRI (Auto).
On / Off
Enables the
word aligner is configured in manual mode and when this
signal is enabled, the word aligner aligns to next incoming
word alignment pattern.
Description
rx_std_rmfifo_full
port.
rx_std_rmfifo_empty
Description
control signal.
tx_std_bitslipboundarysel
rx_syncstatus
will assert after the cycle slip operation is
is asserted). This parameter
rx_patterndetect
rx_std_wa_patternalign
® ®
Intel Cyclone 10 GX Transceiver PHY User Guide
port.
control signal.
asserts high
port. When the
continued...
