2. Implementing Protocols in Intel Cyclone 10 GX Transceivers
UG-20070 | 2018.09.24
Table 141. General and Datapath Parameters
The first two sections of the Parameter Editor for the Transceiver Native PHY provide a list of general and
datapath options to customize the transceiver.
Message level for rule violations
Transceiver configuration rules
PMA configuration rules
Transceiver mode
Number of data channels
Data rate
Enable datapath and interface reconfiguration
Enable simplified data interface
Table 142. TX PMA Parameters
TX channel bonding mode
PCS TX channel bonding master
Actual PCS TX channel bonding master
TX local clock division factor
Number of TX PLL clock inputs per channel
Initial TX PLL clock input selection
Enable tx_pma_clkout port
Enable tx_pma_div_clkout port
tx_pma_div_clkout division factor
Enable tx_pma_elecidle port
Enable rx_serialpbken port
Table 143. RX PMA Parameters
Number of CDR reference clocks
Selected CDR reference clock
Selected CDR reference clock frequency
PPM detector threshold
CTLE adaptation mode
Enable rx_pma_clkout port
Enable rx_pma_div_clkout port
rx_pma_div_clkout division factor
Enable rx_pma_clkslip port
Send Feedback
Parameter
Parameter
Parameter
Range
error, warning
Basic (Enhanced PCS)
Basic, GPON
TX / RX Duplex, TX Simplex, RX Simplex
1 to 12
GX transceiver channel: 1 Gbps to 12.5 Gbps
On / Off
On / Off
Range
Not bonded, PMA only bonding, PMA and PCS bonding
Auto, 0 to n-1, n (where n = the number of data channels)
n-1 (where n = the number of data channels)
1, 2, 4, 8
1, 2, 3, 4
0
On / Off
On / Off
Disabled, 1, 2, 33, 40, 66
On / Off
On / Off
Range
1 to 5
0 to 4
For Basic (Enhanced PCS): Depends on the data rate
parameter
100, 300, 500, 1000
manual
On / Off
On / Off
Disabled, 1, 2, 33, 40, 66
On / Off
® ®
