2. Implementing Protocols in Intel Cyclone 10 GX Transceivers
UG-20070 | 2018.09.24
Parameter
Enable
rx_enh_data_valid port
Enable rx_enh_fifo_full
port
Enable
rx_enh_fifo_pfull port
Enable
rx_enh_fifo_empty
port
Enable
rx_enh_fifo_pempty
port
Enable rx_enh_fifo_del
port (10GBASE-R)
Enable
rx_enh_fifo_insert port
(10GBASE-R)
Enable
rx_enh_fifo_rd_en port
Enable
rx_enh_fifo_align_val
port (Interlaken)
Enable
rx_enh_fifo_align_clr
port (Interlaken)
Table 15. Interlaken Frame Generator Parameters
Parameter
Enable Interlaken
frame generator
Frame generator
metaframe length
Enable Frame
Generator Burst
Control
Send Feedback
Range
On / Off Enables the rx_enh_data_valid port. This signal indicates when
RX data from RX FIFO is valid. This signal is synchronous to
rx_coreclkin.
On / Off Enables the rx_enh_fifo_full port. This signal indicates when
the RX FIFO is full. This is an asynchronous signal.
On / Off Enables the rx_enh_fifo_pfull port. This signal indicates when
the RX FIFO has reached the specified partially full threshold. This
is an asynchronous signal.
On / Off Enables the rx_enh_fifo_empty port. This signal indicates when
the RX FIFO is empty. This signal is synchronous to
rx_coreclkin
On / Off Enables the rx_enh_fifo_pempty port. This signal indicates
when the RX FIFO has reached the specified partially empty
threshold. This signal is synchronous to
On / Off Enables the optional rx_enh_fifo_del status output port. This
signal indicates when a word has been deleted from the rate
match FIFO. This signal is only used for 10GBASE-R transceiver
configuration rule. This is an asynchronous signal.
On / Off Enables the rx_enh_fifo_insert port. This signal indicates when
a word has been inserted into the rate match FIFO. This signal is
only used for 10GBASE-R transceiver configuration rule. This
signal is synchronous to
On / Off Enables the rx_enh_fifo_rd_en input port. This signal is
enabled to read a word from the RX FIFO. This signal is
synchronous to
On / Off Enables the rx_enh_fifo_align_val status output port. Only
used for Interlaken transceiver configuration rule. This signal is
synchronous to
On / Off Enables the rx_enh_fifo_align_clr input port. Only used for
Interlaken. This signal is synchronous to
Range
On / Off Enables the frame generator block of the Enhanced PCS.
5-8192 Specifies the metaframe length of the frame generator. This
metaframe length includes 4 framing control words created by the
frame generator.
On / Off Enables frame generator burst. This determines whether the
frame generator reads data from the TX FIFO based on the input
of port
Description
.
rx_coreclkin
.
rx_coreclkin
.
rx_clkout
Description
.
tx_enh_frame_burst_en
® ®
Intel Cyclone 10 GX Transceiver PHY User Guide
.
rx_coreclkin
.
.
rx_clkout
continued...
