Analog Parameter Setting
XCVR_C10_TX_PRE_EMP_SWITCHI
NG_CTRL_1ST_POST_TAP
XCVR_C10_TX_PRE_EMP_SWITCHI
NG_CTRL_2ND_POST_TAP
XCVR_C10_TX_VOD_OUTPUT_SWI
NG_CTRL
Table 215. Reference Clock Analog Parameter Settings
Analog Parameter Setting
XCVR_C10_REFCLK_TERM_TRISTAT
E
Note: You must set all the required analog settings according to your protocol configuration.
If you do not set the appropriate settings, then the Quartus Prime software selects the
default values which may not be appropriate for your protocol implementation.

8.4. Receiver General Analog Settings

8.4.1. XCVR_C10_RX_TERM_SEL

Pin planner or Assignment Editor Name
Receiver On-Chip Termination
Description
Controls the on-chip RX differential termination.
Note: You can either set this setting to R_R1 or R_R2.
Table 216. Available Options
Value
R_EXT0
R_R1
R_R2
Assign To
RX serial data pin.
Syntax
set_instance_assignment -name XCVR_C10_RX_TERM_SEL <value> -to
<rx_serial_data pin name>

8.5. Receiver Analog Equalization Settings

® ®
Intel Cyclone 10 GX Transceiver PHY User Guide
390
Pin Planner or Assignment Editor
Name
Transmitter Pre-Emphasis First
Post-Tap Magnitude
Transmitter Pre-Emphasis Second
Post-Tap Magnitude
Transmitter Output Swing Level
Pin Planner or Assignment Editor
Name
Dedicated Reference Clock Pin
Termination
8. Analog Parameter Settings
UG-20070 | 2018.09.24
Assignment Usage Guideline
Destination
TX serial data Pre-emphasis
TX serial data Pre-emphasis
TX serial data Differential output voltage
Assignment Usage Guideline
Destination
Reference clock On-chip termination
pin
Description
Tristate
100 Ohm
85 Ohm
