Sd Status Register; Table 146. Sd Status - ST STM32F101 series Reference Manual

Secure digital input/output interface (SDIO)
Bits Identifier
3 AKE_SEQ_ERROR
2 Reserved for application specific commands
1
Reserved for manufacturer test mode
0
22.4.12

SD status register

The SD status contains status bits that are related to the SD memory card proprietary
features and may be used for future application-specific usage. The size of the SD Status is
one data block of 512 bits. The contents of this register are transmitted to the SDIO card
host if ACMD13 is sent (CMD55 followed with CMD13). ACMD13 can be sent to a card in
transfer state only (card is selected).
Table 146
fields in the table are abbreviated as follows:
Type:
•
E: error bit
•
S: status bit
•
R: detected and set for the actual command response
•
X: detected and set during command execution. The SDIO card Host must poll the card
by issuing the status command to read these bits
Clear condition:
•
A: according to the card current state
•
B: always related to the previous command. Reception of a valid command clears it
(with a delay of one command)
•
C: clear by read
Bits Identifier
511: 510 DAT_BUS_WIDTH S R
509 SECURED_MODE S R
508: 496 Reserved
583/1128
Table 145. Card status (continued)
Type Value
'0'= no error
E R
'1'= error
defines the different entries of the SD status register. The type and clear condition

Table 146. SD status

Type
'00'= 1 (default)
'01'= reserved
'10'= 4 bit width
'11'= reserved
'0'= Not in the mode
'1'= In Secured Mode
DocID13902 Rev 15
Description
Error in the sequence of the
authentication process
Value
Shows the currently defined
databus width that was
defined by
SET_BUS_WIDTH
command
Card is in Secured Mode of
operation (refer to the "SD
Security Specification").
RM0008
condition
C
Description
condition
A
A
Clear
