RM0008
27.6.5

Control register 2 (USART_CR2)

Address offset: 0x10
Reset value: 0x0000
31 30 29
15 14 13
LINEN STOP[1:0]
Res.
rw rw
Bits 31:15 Reserved, forced by hardware to 0.
Bit 14 LINEN: LIN mode enable
Bits 13:12 STOP: STOP bits
Bit 11 CLKEN: Clock enable
Bit 10 CPOL: Clock polarity
Bit 9 CPHA: Clock phase
Universal synchronous asynchronous receiver transmitter (USART)
28 27 26 25
12 11 10 9
CLK
CPOL CPHA
EN
rw rw rw rw
This bit is set and cleared by software.
0: LIN mode disabled
1: LIN mode enabled
The LIN mode enables the capability to send LIN Synch Breaks (13 low bits) using the SBK
bit in the USART_CR1 register, and to detect LIN Sync breaks.
These bits are used for programming the stop bits.
00: 1 Stop bit
01: 0.5 Stop bit
10: 2 Stop bits
11: 1.5 Stop bit
The 0.5 Stop bit and 1.5 Stop bit are not available for UART4 & UART5.
This bit allows the user to enable the CK pin.
0: CK pin disabled
1: CK pin enabled
This bit is not available for UART4 & UART5.
This bit allows the user to select the polarity of the clock output on the CK pin in synchronous
mode. It works in conjunction with the CPHA bit to produce the desired clock/data
relationship
0: Steady low value on CK pin outside transmission window.
1: Steady high value on CK pin outside transmission window.
This bit is not available for UART4 & UART5.
This bit allows the user to select the phase of the clock output on the CK pin in synchronous
mode. It works in conjunction with the CPOL bit to produce the desired clock/data
relationship (see figures
0: The first clock transition is the first data capture edge.
1: The second clock transition is the first data capture edge.
This bit is not available for UART4 & UART5.
24 23 22
Reserved
8 7 6
LBCL Res. LBDIE
rw rw
289 to 290)
DocID13902 Rev 15
21 20 19 18
5 4 3 2
LBDL Res.
rw rw rw rw
17 16
1 0
ADD[3:0]
rw rw
816/1128
