RM0008
15.4.11

TIMx prescaler (TIMx_PSC)

Address offset: 0x28
Reset value: 0x0000
15 14 13
rw rw rw
Bits 15:0 PSC[15:0]: Prescaler value
15.4.12

TIMx auto-reload register (TIMx_ARR)

Address offset: 0x2C
Reset value: 0x0000
15 14 13
rw rw rw
Bits 15:0
15.4.13

TIMx capture/compare register 1 (TIMx_CCR1)

Address offset: 0x34
Reset value: 0x0000
15 14 13
rw rw rw
Bits 15:0 CCR1[15:0]: Capture/Compare 1 value
12 11 10 9
rw rw rw rw
The counter clock frequency CK_CNT is equal to f
PSC contains the value to be loaded in the active prescaler register at each update event.
12 11 10 9
rw rw rw rw
ARR[15:0]: Prescaler value
ARR is the value to be loaded in the actual auto-reload register.
Refer to the Section 15.3.1: Time-base unit on page 362
and behavior.
The counter is blocked while the auto-reload value is null.
12 11 10 9
rw rw rw rw
If channel CC1 is configured as output:
CCR1 is the value to be loaded in the actual capture/compare 1 register (preload value).
It is loaded permanently if the preload feature is not selected in the TIMx_CCMR1 register
(bit OC1PE). Else the preload value is copied in the active capture/compare 1 register when
an update event occurs.
The active capture/compare register contains the value to be compared to the counter
TIMx_CNT and signaled on OC1 output.
If channel CC1is configured as input:
CCR1 is the counter value transferred by the last input capture 1 event (IC1).
General-purpose timers (TIM2 to TIM5)
8 7 6
PSC[15:0]
rw rw rw
8 7 6
ARR[15:0]
rw rw rw
8 7 6
CCR1[15:0]
rw rw rw
DocID13902 Rev 15
5 4 3 2
rw rw rw rw
/ (PSC[15:0] + 1).
CK_PSC
5 4 3 2
rw rw rw rw
for more details about ARR update
5 4 3 2
rw rw rw rw
1 0
rw rw
1 0
rw rw
1 0
rw rw
412/1128
