Control/status register (RCC_CSR)

Address: 0x24
Reset value: 0x0C00 0000, reset by system Reset, except reset flags by power Reset only.
Access: 0 ≤ wait state ≤ 3, word, half-word and byte access
Wait states are inserted in the case of successive accesses to this register.
31 30 29
LPWR WWDG IWDG
RSTF RSTF RSTF RSTF
rw rw rw
15 14 13
Bit 31 LPWRRSTF: Low-power reset flag
Set by hardware when a Low-power management reset occurs. It is cleared by writing to the
RMVF bit.
0: No Low-power management reset occurred
1: Low-power management reset occurred
For further information on Low-power management reset, refer to
management
Bit 30 WWDGRSTF: Window watchdog reset flag
Set by hardware when a window watchdog reset occurs. It is cleared by writing to the RMVF
bit.
0: No window watchdog reset occurred
1: Window watchdog reset occurred
Bit 29 IWDGRSTF: Independent watchdog reset flag
Set by hardware when an independent watchdog reset from V
cleared by writing to the RMVF bit.
0: No watchdog reset occurred
1: Watchdog reset occurred
Bit 28 SFTRSTF: Software reset flag
Set by hardware when a software reset occurs. It is cleared by writing to the RMVF bit.
0: No software reset occurred
1: Software reset occurred
Bit 27 PORRSTF: POR/PDR reset flag
Set by hardware when a POR/PDR reset occurs. It is cleared by writing to the RMVF bit.
0: No POR/PDR reset occurred
1: POR/PDR reset occurred
Bit 26 PINRSTF: PIN reset flag
Set by hardware when a reset from the NRST pin occurs. It is cleared by writing to the
RMVF bit.
0: No reset from NRST pin occurred
1: Reset from NRST pin occurred
Bit 25 Reserved, must be kept at reset value.
28 27 26 25
SFT POR PIN
RSTF RSTF
Res.
rw rw rw
12 11 10 9
Reserved
reset.
