RM0008
11.12

ADC registers

Refer to
The peripheral registers have to be accessed by words (32-bit).
11.12.1

ADC status register (ADC_SR)

Address offset: 0x00
Reset value: 0x0000 0000
31 30 29 28
15 14 13 12
Bits 31:5 Reserved, must be kept at reset value.
Bit 4 STRT: Regular channel Start flag
This bit is set by hardware when regular channel conversion starts. It is cleared by software.
0: No regular channel conversion started
1: Regular channel conversion has started
Bit 3 JSTRT: Injected channel Start flag
This bit is set by hardware when injected channel group conversion starts. It is cleared by
software.
0: No injected group conversion started
1: Injected group conversion has started
Bit 2 JEOC: Injected channel end of conversion
This bit is set by hardware at the end of all injected group channel conversion. It is cleared
by software.
0: Conversion is not complete
1: Conversion complete
Bit 1 EOC: End of conversion
This bit is set by hardware at the end of a group channel conversion (regular or injected). It is
cleared by software or by reading the ADC_DR.
0: Conversion is not complete
1: Conversion complete
Bit 0 AWD: Analog watchdog flag
This bit is set by hardware when the converted voltage crosses the values programmed in
the ADC_LTR and ADC_HTR registers. It is cleared by software.
0: No Analog watchdog event occurred
1: Analog watchdog event occurred
Section 2.1 on page 47
27 26 25
11 10 9
Reserved
for a list of abbreviations used in register descriptions.
24 23 22
Reserved
8 7 6
DocID13902 Rev 15
Analog-to-digital converter (ADC)
21 20 19 18
5 4 3 2
STRT JSTRT JEOC
rc_w0 rc_w0 rc_w0
17 16
1 0
EOC AWD
rc_w0 rc_w0
236/1128
