USB on-the-go full-speed (OTG_FS)

Bits 31:25 Reserved, must be kept at reset value.

Bits 24:21 FRMNUM: Frame number

Bits 20:17 PKTSTS: Packet status

Bits 16:15 DPID: Data PID

Bits 14:4 BCNT: Byte count

Bits 3:0 EPNUM: Endpoint number

OTG_FS Receive FIFO size register (OTG_FS_GRXFSIZ)

Address offset: 0x024

Reset value: 0x0000 0200

The application can program the RAM size that must be allocated to the RxFIFO.

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10

Bits 31:16 Reserved, must be kept at reset value.

Bits 15:0 RXFD: RxFIFO depth

This is the least significant 4 bits of the frame number in which the packet is received on the

USB. This field is supported only when isochronous OUT endpoints are supported.

Indicates the status of the received packet

0001: Global OUT NAK (triggers an interrupt)

0010: OUT data packet received

0011: OUT transfer completed (triggers an interrupt)

0100: SETUP transaction completed (triggers an interrupt)

0110: SETUP data packet received

Others: Reserved

Indicates the Data PID of the received OUT data packet

Indicates the byte count of the received data packet.

Indicates the endpoint number to which the current received packet belongs.

This value is in terms of 32-bit words.

Minimum value is 16

Maximum value is 256

The power-on reset value of this register is specified as the largest Rx data FIFO depth.
