RM0008
23.5

USB registers

The USB peripheral registers can be divided into the following groups:
•
Common Registers: Interrupt and Control registers
• Endpoint Registers: Endpoint configuration and status
•
Buffer Descriptor Table: Location of packet memory used to locate data buffers
All register addresses are expressed as offsets with respect to the USB peripheral registers
base address 0x4000 5C00, except the buffer descriptor table locations, which starts at the
address specified by the USB_BTABLE register. Due to the common limitation of APB1
bridges on word addressability, all register addresses are aligned to 32-bit word boundaries
although they are 16-bit wide. The same address alignment is used to access packet buffer
memory locations, which are located starting from 0x4000 6000.
Refer to
The peripheral registers can be accessed by half-words (16-bit) or words (32-bit).
23.5.1

Common registers

These registers affect the general behavior of the USB peripheral defining operating mode,
interrupt handling, device address and giving access to the current frame number updated
by the host PC.
USB control register (USB_CNTR)
Address offset: 0x40
Reset value: 0x0003
15 14 13
CTRM PMAOVRM ERRM WKUPM SUSPM RESETM SOFM ESOFM
rw rw rw
Bit 15 CTRM: Correct transfer interrupt mask
Bit 14 PMAOVRM: Packet memory area over / underrun interrupt mask
Bit 13 ERRM: Error interrupt mask
Bit 12 WKUPM: Wakeup interrupt mask
Section 2.1 on page 47
12 11 10
rw rw rw
0: Correct Transfer (CTR) Interrupt disabled.
1: CTR Interrupt enabled, an interrupt request is generated when the corresponding bit in the
USB_ISTR register is set.
0: PMAOVR Interrupt disabled.
1: PMAOVR Interrupt enabled, an interrupt request is generated when the corresponding bit
in the USB_ISTR register is set.
0: ERR Interrupt disabled.
1: ERR Interrupt enabled, an interrupt request is generated when the corresponding bit in
the USB_ISTR register is set.
0: WKUP Interrupt disabled.
1: WKUP Interrupt enabled, an interrupt request is generated when the corresponding bit in
the USB_ISTR register is set.
Universal serial bus full-speed device interface (USB)
for a list of abbreviations used in register descriptions.
9 8 7 6
Reserved
rw rw
DocID13902 Rev 15
5 4 3 2
RESUME FSUSP LP_MODE PDWN FRES
rw rw rw
1 0
rw rw
628/1128
