VLAN Commands
configure vman add ports
configure vman <vman-name> add ports [ all | <port_list> ] {untagged |
tagged | nobroadcast }
Description
Adds one or more ports in a VMAN.
Syntax Description
vman-ame
all
port_list
untagged
tagged
nobroadcast
Default
N/A.
Usage Guidelines
If you do not specify a parameter, the default value is untagged. If you specify the parameter
, the system used the default value of untagged; you cannot add
nobroadcast
have specified tagged packets.
NOTE
The nobroadcast option is available only on the BlackDiamond 10K switch.
The VMAN tunnel begins at the ingress, or customer access, port and terminates at the egress, or trunk,
port. Traffic flows from the egress trunk port onto the network thereafter without the VMAN tag.
Ensure that all the switch-to-switch ports in the VMAN tunnel are configured as tagged ports.
Configure the VMAN ingress, or customer access, port as an untagged port (although this port does
accept tagged packets). You must configure the VMAN tunnel egress, or trunk, port as an untagged port
so that the VMAN header is stripped from the frame.
598
Specifies a VMAN name.
Specifies all ports.
Specifies a list of ports or slots and ports.
NOTE: On the BlackDiamond 8800 family of switches (formerly known as
Aspen), ports on a given slot can be either VLAN members or VMAN members,
but not both.
Specifies that the ports are untagged.
Specifies that the ports are tagged.
Specifies that the ports do not forward broadcast, multicast, or unknown
unicast packets.
NOTE: This option is available only on the BlackDiamond 10K switch.
once you
nobroadcast
ExtremeWare XOS 11.3 Command Reference
