configure diffserv examination code-point

configure diffserv examination code-point <code-point> {qosprofile}
<qosprofile>
Description
Configures the default ingress DiffServ code points (DSCP) to QoS profile mapping.
Syntax Description
code-point
qosprofile
Default
See Table 19.
Usage Guidelines
You can specify up to 64 different code points for each port. Code point values are grouped and
assigned to the default QoS profiles as shown in
Table 19: Default DiffServ code point-to-QoS profile mapping
Code point
0-7
8-15
16-23
24-31
32-39
40-47
48-55
56-63
BlackDiamond 10K switch only. If a port is in more than one virtual router, you cannot set per port
DiffServ examination code points. The default VLAN DiffServ examination mappings apply on ports in
more than one VR. If you attempt to configure examining DiffServ information on a port that is in more
than one virtual router, the system returns the following message:
Warning: Port belongs to more than one VR. Port properties related to diff serv and
code replacement will not take effect.
ExtremeWare XOS 11.3 Command Reference
Specifies a DiffServ code point (a 6-bit value in the IP-TOS byte in the IP
header).
Specifies the QoS profile to which the DiffServ code point is mapped.
Table
BlackDiamond 10K switch
QoS profile
QP1
QP2
QP3
QP4
QP5
QP6
QP7
QP8
configure diffserv examination code-point
19.
BlackDiamond 8800 family of switches and
Summit X450 switch QoS profile
QP1
QP1
QP1
QP1
QP1
QP1
QP1
QP8
