Extreme Networks ExtremeWare Command Reference Manual
  1. Manuals
  2. Brands
  3. Extreme Networks Manuals
  4. Software
  5. ExtremeWare
  6. Command reference manual
Extreme Networks ExtremeWare Command Reference Manual

Extreme Networks ExtremeWare Command Reference Manual

Version 7.5
Hide thumbs Also See for ExtremeWare:
1
2
Table Of Contents
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
346
347
348
349
350
351
352
353
354
355
356
357
358
359
360
361
362
363
364
365
366
367
368
369
370
371
372
373
374
375
376
377
378
379
380
381
382
383
384
385
386
387
388
389
390
391
392
393
394
395
396
397
398
399
400
401
402
403
404
405
406
407
408
409
410
411
412
413
414
415
416
417
418
419
420
421
422
423
424
425
426
427
428
429
430
431
432
433
434
435
436
437
438
439
440
441
442
443
444
445
446
447
448
449
450
451
452
453
454
455
456
457
458
459
460
461
462
463
464
465
466
467
468
469
470
471
472
473
474
475
476
477
478
479
480
481
482
483
484
485
486
487
488
489
490
491
492
493
494
495
496
497
498
499
500
501
502
503
504
505
506
507
508
509
510
511
512
513
514
515
516
517
518
519
520
521
522
523
524
525
526
527
528
529
530
531
532
533
534
535
536
537
538
539
540
541
542
543
544
545
546
547
548
549
550
551
552
553
554
555
556
557
558
559
560
561
562
563
564
565
566
567
568
569
570
571
572
573
574
575
576
577
578
579
580
581
582
583
584
585
586
587
588
589
590
591
592
593
594
595
596
597
598
599
600
601
602
603
604
605
606
607
608
609
610
611
612
613
614
615
616
617
618
619
620
621
622
623
624
625
626
627
628
629
630
631
632
633
634
635
636
637
638
639
640
641
642
643
644
645
646
647
648
649
650
651
652
653
654
655
656
657
658
659
660
661
662
663
664
665
666
667
668
669
670
671
672
673
674
675
676
677
678
679
680
681
682
683
684
685
686
687
688
689
690
691
692
693
694
695
696
697
698
699
700
701
702
703
704
705
706
707
708
709
710
711
712
713
714
715
716
717
718
719
720
721
722
723
724
725
726
727
728
729
730
731
732
733
734
735
736
737
738
739
740
741
742
743
744
745
746
747
748
749
750
751
752
753
754
755
756
757
758
759
760
761
762
763
764
765
766
767
768
769
770
771
772
773
774
775
776
777
778
779
780
781
782
783
784
785
786
787
788
789
790
791
792
793
794
795
796
797
798
799
800
801
802
803
804
805
806
807
808
809
810
811
812
813
814
815
816
817
818
819
820
821
822
823
824
825
826
827
828
829
830
831
832
833
834
835
836
837
838
839
840
841
842
843
844
845
846
847
848
849
850
851
852
853
854
855
856
857
858
859
860
861
862
863
864
865
866
867
868
869
870
871
872
873
874
875
876
877
878
879
880
881
882
883
884
885
886
887
888
889
890
891
892
893
894
895
896
897
898
899
900
901
902
903
904
905
906
907
908
909
910
911
912
913
914
915
916
917
918
919
920
921
922
923
924
925
926
927
928
929
930
931
932
933
934
935
936
937
938
939
940
941
942
943
944
945
946
947
948
949
950
951
952
953
954
955
956
957
958
959
960
961
962
963
964
965
966
967
968
969
970
971
972
973
974
975
976
977
978
979
980
981
982
983
984
985
986
987
988
989
990
Table of Contents

Advertisement

Quick Links

Download this manual See also: Command Reference Manual
ExtremeWare
Command Reference Guide
Software Version 7.5
Extreme Networks, Inc.
3585 Monroe Street
Santa Clara, California 95051
(888) 257-3000
http://www.extremenetworks.com
Published October, 2005
Part number: 100211-00 Rev. 01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ExtremeWare and is the answer not in the manual?

Questions and answers

Related Manuals for Extreme Networks ExtremeWare

Summary of Contents for Extreme Networks ExtremeWare

  • Page 1 ExtremeWare Command Reference Guide Software Version 7.5 Extreme Networks, Inc. 3585 Monroe Street Santa Clara, California 95051 (888) 257-3000 http://www.extremenetworks.com Published October, 2005 Part number: 100211-00 Rev. 01...
  • Page 2 Solution Partners Logo, ServiceWatch, Summit, the Summit7i Logo, and the Color Purple, among others, are trademarks or registered trademarks of Extreme Networks, Inc. or its subsidiaries in the United States and other countries. Other names and marks may be the property of their respective owners.

  • Page 3: Table Of Contents

    Contents Preface Chapter 1 Command Reference Overview Chapter 2 Commands for Accessing the Switch clear account lockout clear session configure account configure account password-policy char-validation configure account password-policy history configure account password-policy lockout-on-login-failures configure account password-policy maxage configure account password-policy min-pwd-length configure banner configure banner netlogin configure dns-client add...
  • Page 4 Contents create account delete account disable clipaging disable idletimeouts enable clipaging enable idletimeouts enable license history reboot show accounts password-policy show accounts pppuser show banner show dns-client show esrp-aware show switch traceroute Chapter 3 Commands for Managing the Switch configure snmp access-profile readonly configure snmp access-profile readwrite configure snmp add community configure snmp add trapreceiver...
  • Page 5 Contents configure snmpv3 add notify configure snmpv3 add target-addr configure snmpv3 add target-params configure snmpv3 add user configure snmpv3 add user clone-from configure snmpv3 delete access configure snmpv3 delete community configure snmpv3 delete filter configure snmpv3 delete filter-profile configure snmpv3 delete group user configure snmpv3 delete mib-view configure snmpv3 delete notify configure snmpv3 delete target-addr...
  • Page 6 Contents enable alt-queue-management enable dhcp ports vlan enable eapol-flooding enable snmp access enable snmp dot1dTpFdbTable enable snmp traps enable snmp traps exceed-committed-rate ports enable snmp traps mac-security enable snmp traps port-up-down enable sntp-client enable system-watchdog enable telnet enable web exit logout quit show eapol-flooding...
  • Page 7 Contents show vlan dhcp-address-allocation show vlan dhcp-config telnet unconfigure management Chapter 4 Commands for Configuring Slots and Ports on a Switch clear slot configure backplane-ls-policy configure ip-mtu vlan configure jumbo-frame size configure mirroring add configure mirroring delete configure msm-failover link-action configure msm-failover slave-config configure msm-failover timeout configure port aggregate-bandwidth percent...
  • Page 8 Contents disable mirroring disable ports disable sharing disable slot disable smartredundancy enable card-scan enable edp ports enable flooding ports enable jumbo-frame ports enable lbdetect port enable learning ports enable mirroring to port enable ports enable sharing grouping enable slot enable smartredundancy restart ports run msm-failover show edp...
  • Page 9 Contents unconfigure ports display string unconfigure ports redundant unconfigure slot Chapter 5 VLAN Commands configure dot1q ethertype configure gvrp port configure mac-vlan add mac-address configure mac-vlan delete configure ports monitor vlan configure protocol add configure protocol delete configure vlan add member-vlan configure vlan add ports configure vlan add ports loopback-vid configure vlan add secondary-ip...
  • Page 10 Contents show vlan unconfigure ports monitor vlan unconfigure vlan ipaddress Chapter 6 FDB Commands clear fdb configure fdb agingtime configure fdb-scan failure-action configure fdb-scan period create fdbentry secure-mac create fdbentry vlan blackhole create fdbentry vlan dynamic create fdbentry vlan ports delete fdbentry disable fdb-scan enable fdb-scan...
  • Page 11 Contents disable dot1p replacement ports disable qosmonitor disable red ports enable diffserv examination ports enable diffserv replacement ports enable dlcs enable dot1p replacement ports enable qosmonitor enable red ports show dlcs show dot1p show ports qosmonitor show qosprofile show qostype priority unconfigure diffserv examination ports unconfigure diffserv replacement ports unconfigure qostype priority...
  • Page 12 Contents Chapter 9 SLB Commands—“i” Series Switches Only clear slb connections clear slb persistence vip configure flow-redirect add next-hop configure flow-redirect delete next-hop configure flow-redirect service-check ftp configure flow-redirect service-check http configure flow-redirect service-check L4-port configure flow-redirect service-check nntp configure flow-redirect service-check ping configure flow-redirect service-check pop3 configure flow-redirect service-check smtp configure flow-redirect service-check telnet...
  • Page 13 Contents configure slb global tcp-port-check configure slb global telnet configure slb gogo-mode health-check configure slb gogo-mode ping-check configure slb gogo-mode service-check ftp configure slb gogo-mode service-check http configure slb gogo-mode service-check pop3 configure slb gogo-mode service-check smtp configure slb gogo-mode service-check telnet configure slb gogo-mode service-check timer configure slb gogo-mode tcp-port-check add configure slb gogo-mode tcp-port-check delete...
  • Page 14 Contents create slb pool create slb vip delete flow-redirect delete slb pool delete slb vip disable flow-redirect disable slb disable slb 3dns disable slb failover disable slb failover manual-failback disable slb failover ping-check disable slb global synguard disable slb gogo-mode disable slb gogo-mode ping-check disable slb gogo-mode service-check disable slb gogo-mode tcp-port-check...
  • Page 15 Contents enable slb gogo-mode ping-check enable slb gogo-mode service-check enable slb gogo-mode tcp-port-check enable slb L4-port enable slb node enable slb node ping-check enable slb node tcp-port-check enable slb proxy-client-persistence enable slb vip enable slb vip client-persistence enable slb vip service-check enable slb vip sticky-persistence enable slb vip svcdown-reset show flow-redirect...
  • Page 16 Contents Chapter 10 Commands for Status Monitoring and Statistics clear counters clear log clear log counters clear log diag error clear log diag remap clear transceiver-test configure flowstats export add port configure flowstats export delete port configure flowstats filter ports configure flowstats source configure flowstats timeout ports configure log display...
  • Page 17 Contents configure transceiver-test period configure transceiver-test threshold configure transceiver-test window create log filter delete log filter disable cli-config-logging disable flowstats disable flowstats filter ports disable flowstats ping-check disable flowstats ports disable log debug-mode disable log display disable log target disable rmon disable sflow disable sflow backoff-threshold disable sflow ports...
  • Page 18 Contents enable syslog enable temperature-logging enable transceiver-test save log show flowstats show flowstats show flowstats export show log show log components show log configuration show log configuration filter show log configuration target show log counters show log events show memory show packet-mem-scan-recovery-mode show packet miscompare show ports rxerrors...
  • Page 19 Contents unconfigure transceiver-test window upload log Chapter 11 Security Commands clear netlogin state clear netlogin state mac-address configure access-profile add configure access-profile delete configure access-profile mode configure auth mgmt-access local configure auth mgmt-access radius configure auth mgmt-access radius-accounting configure auth mgmt-access tacacs configure auth mgmt-access tacacs-accounting configure auth netlogin radius configure auth netlogin radius-accounting...
  • Page 20 Contents configure netlogin mac-address configure netlogin mac auth-retry-count configure netlogin mac reauth-period configure netlogin redirect-page configure radius server configure radius shared-secret configure radius timeout configure radius-accounting server configure radius-accounting shared-secret configure radius-accounting timeout configure route-map add configure route-map add goto configure route-map add match configure route-map add set configure route-map delete...
  • Page 21 Contents configure ssl certificate privkeylen country organization common-name configure ssl privkey pregenerated configure tacacs server configure tacacs server timeout configure tacacs shared-secret configure tacacs timeout configure tacacs-accounting server configure tacacs-accounting shared-secret configure tacacs-accounting timeout configure vlan access-profile configure vlan dhcp-address-range configure vlan dhcp-lease-timer configure vlan dhcp-options configure vlan netlogin-lease-timer...
  • Page 22 Contents disable arp-learning ports disable arp-learning vlan disable arp-learning vlan ports disable cpu-dos-protect disable dhcp ports vlan disable enhanced-dos-protect disable ip-subnet-lookup disable mac-lockdown-timeout ports disable netlogin disable netlogin logout-privilege disable netlogin ports disable netlogin ports mac disable netlogin session-refresh disable radius disable radius-accounting disable source-ip-lockdown ports disable ssh2...
  • Page 23 Contents enable enhanced-dos-protect enable ip-subnet-lookup enable mac-lockdown-timeout ports 1000 enable netlogin 1001 enable netlogin logout-privilege 1003 enable netlogin ports 1004 enable netlogin ports mac 1005 enable netlogin session-refresh 1006 enable radius 1007 enable radius-accounting 1008 enable source-ip-lockdown ports 1009 enable ssh2 1010 enable tacacs 1012...
  • Page 24 Contents show ip-subnet-lookup fdb 1040 show mac-lockdown-timeout ports 1041 show mac-lockdown-timeout fdb ports 1042 show netlogin 1044 show netlogin mac 1046 show radius 1047 show radius-accounting 1049 show rate-limit 1051 show route-map 1053 show security-profile 1054 show source-ip-lockdown ports 1057 show ssl 1058 show tacacs...
  • Page 25 Contents unconfigure vlan dhcp-options 1088 Chapter 12 Configuration and Image Commands configure configuration-mode 1092 configure download server 1093 configure switch 1094 configure wireless ports image 1096 download bootrom 1098 download configuration 1100 download configuration cancel 1102 download configuration every 1103 download file-name 1104 download image...
  • Page 26 Contents configure debug-trace dvmrp-neighbor 1136 configure debug-trace dvmrp-route 1138 configure debug-trace dvmrp-timer 1140 configure debug-trace eaps-system 1141 configure debug-trace flow-redirect 1143 configure debug-trace flowstats 1145 configure debug-trace health-check 1146 configure debug-trace iparp 1149 configure debug-trace ipxgns-message 1151 configure debug-trace ipxrip-message 1153 configure debug-trace ipxrip-route 1155...
  • Page 27 Contents configure debug-trace transceiver-test 1189 configure debug-trace udp-forwarding 1191 configure debug-trace vrrp 1192 configure debug-trace vrrp-hello 1193 configure debug-trace wireless 1195 configure diagnostics 1197 configure reboot-loop-protection 1199 configure system-dump server 1200 configure system-dump timeout 1201 disable log debug-mode 1202 enable log debug-mode 1203 nslookup 1204...
  • Page 28 Contents Chapter 14 Wireless Commands clear APmgmt port history 1247 clear wireless ports counters 1248 clear wireless ports interface ap-scan results 1249 clear wireless ports interface client-history 1250 clear wireless ports interface client-scan counters 1251 clear wireless ports interface client-scan results 1252 clear wireless ports log 1253...
  • Page 29 Contents configure wireless ports interface ap-scan updated-trap 1281 configure wireless ports interface channel 1282 configure wireless ports interface client-history size 1284 configure wireless ports interface client-history timeout 1285 configure wireless ports interface client-scan added-trap 1286 configure wireless ports interface client-scan removed-trap 1287 configure wireless ports interface client-scan results size 1288...
  • Page 30 Contents enable wireless ports every 1316 enable wireless ports interface 1317 enable wireless ports interface ap-scan 1318 enable wireless ports interface ap-scan off-channel 1319 enable wireless ports interface client-history 1320 enable wireless ports interface client-scan 1321 enable wireless ports interface iapp 1322 This command is available on the Summit 300-48, Summit 300-24, Summit 400-24p and Alpine switches.enable wireless ports interface svp...
  • Page 31 Contents show wireless ports interface client-scan results mac-address 1367 show wireless ports interface client-scan status 1368 show wireless ports interface clients 1370 show wireless ports interface configuration 1372 show wireless ports interface pae-diagnostics 1375 This command is available on the Summit 300-48, Summit 300-24, Summit 400-24p and Alpine switches.show wireless ports interface pae-statistics 1376 This command is available on the Summit 300-48, Summit 300-24, Summit 400-24p...
  • Page 32 Contents configure eaps fast-convergence 1411 configure eaps hellotime 1412 configure eaps mode 1413 configure eaps name 1414 configure eaps port 1415 configure eaps shared-port link-id 1416 configure eaps shared-port mode 1417 create eaps 1418 create eaps shared-port 1419 delete eaps 1420 delete eaps shared-port 1421...
  • Page 33 Contents configure stpd tag 1456 configure vlan add ports stpd 1457 create stpd 1459 delete stpd 1461 disable ignore-bpdu vlan 1462 disable ignore-stp vlan 1463 disable stpd 1464 disable stpd ports 1465 disable stpd rapid-root-failover 1467 enable ignore-bpdu vlan 1468 enable ignore-stp vlan 1469 enable stpd...
  • Page 34 Contents configure vlan add ports restart 1509 configure vlan add track-bgp 1510 configure vlan add track-diagnostic 1511 configure vlan add track-environment 1512 configure vlan add track-iproute 1513 configure vlan add track-ospf 1514 configure vlan add track-ping 1515 configure vlan add track-rip 1516 configure vlan add track-vlan 1517...
  • Page 35 Contents enable elrp-client 1549 enable elsm auto-restart ports 1550 enable elsm ports 1551 enable esrp vlan 1553 show elrp 1554 show elsm 1557 show elsm ports 1558 show esrp 1560 show esrp vlan 1563 show esrp-aware vlan 1565 show esrp-aware-ports 1566 unconfigure elrp-client 1567...
  • Page 36 Contents configure iparp add proxy 1598 configure iparp delete 1600 configure iparp delete proxy 1601 configure iparp max-entries 1602 configure iparp max-pending-entries 1603 configure iparp timeout 1604 configure ipfdb route-add 1605 configure iproute add 1606 configure iproute add blackhole 1607 configure iproute add blackhole default 1608 configure iproute add default...
  • Page 37 Contents disable icmp time-exceeded 1636 disable icmp timestamp 1637 disable icmp unreachables 1638 disable icmp useredirects 1639 disable ip-option loose-source-route 1640 disable ip-option record-route 1641 disable ip-option record-timestamp 1642 disable ip-option strict-source-route 1643 disable ip-option use-router-alert 1644 disable iparp checking 1645 disable iparp refresh 1646...
  • Page 38 Contents enable ip-option use-router-alert 1671 enable iparp checking 1672 enable iparp refresh 1673 enable ipforwarding 1674 enable ipforwarding lpm-routing 1676 enable iproute sharing 1677 enable irdp 1678 enable loopback-mode vlan 1679 enable multinetting 1680 enable subvlan-proxy-arp vlan 1681 enable udp-echo-server 1682 rtlookup 1683...
  • Page 39 Contents configure isis area delete domain-summary 1712 configure isis area domain-filter 1713 configure isis authentication 1714 configure isis delete area-address 1715 configure isis delete vlan 1716 configure isis external-filter 1717 configure isis lsp holddown interval 1718 configure isis lsp lifetime 1719 configure isis lsp refresh interval 1720...
  • Page 40 Contents configure ospf delete vlan 1748 configure ospf direct-filter 1749 configure ospf lsa-batch-interval 1750 configure ospf metric-table 1751 configure ospf priority 1752 configure ospf routerid 1753 configure ospf spf-hold-time 1755 configure ospf timer 1756 configure ospf virtual-link authentication password 1758 configure ospf vlan area 1759 configure ospf vlan neighbor add...
  • Page 41 Contents disable ospf capability opaque-lsa 1786 disable ospf export 1787 disable ospf originate-router-id 1789 disable rip 1790 disable rip aggregation 1791 disable rip export 1792 disable rip exportstatic 1794 disable rip originate-default 1795 disable rip poisonreverse 1796 disable rip splithorizon 1797 disable rip triggerupdate 1798...
  • Page 42 Contents show ospf 1829 show ospf area 1830 show ospf area detail 1831 show ospf ase-summary 1832 show ospf interfaces 1833 show ospf interfaces detail 1834 show ospf lsdb area lstype 1835 show ospf virtual-link 1837 show rip 1838 show rip stats 1839 show rip stats vlan 1840...
  • Page 43 Contents configure bgp neighbor no-dampening 1868 configure bgp neighbor password 1869 configure bgp neighbor peer-group 1871 configure bgp neighbor route-map-filter 1872 configure bgp neighbor route-reflector-client 1873 configure bgp neighbor send-community 1874 configure bgp neighbor soft-reset 1875 configure bgp neighbor source-interface 1876 configure bgp neighbor timer 1877...
  • Page 44 Contents disable bgp always-compare-med 1905 disable bgp community format 1906 disable bgp export 1907 disable bgp neighbor 1909 disable bgp neighbor remove-private-AS-numbers 1910 disable bgp neighbor soft-in-reset 1911 disable bgp peer-group 1912 disable bgp synchronization 1913 enable bgp 1914 enable bgp aggregation 1915 enable bgp always-compare-med 1916...
  • Page 45 Contents configure dvmrp vlan timer 1944 configure dvmrp vlan trusted-gateway 1945 configure ext-mcast loopback-port 1946 configure igmp 1947 configure igmp snooping add static group 1948 configure igmp snooping add static router 1950 configure igmp snooping delete static group 1951 configure igmp snooping delete static router 1952 configure igmp snooping filter 1953...
  • Page 46 Contents disable ipmcforwarding 1983 disable mcast-queue-mgmt 1984 disable pim 1985 disable pim snooping 1986 enable dvmrp 1987 enable dvmrp rxmode vlan 1988 enable dvmrp txmode vlan 1989 enable ext-mcast 1990 enable igmp 1991 enable igmp snooping 1992 enable igmp snooping with-proxy 1994 enable ipmcforwarding 1995...
  • Page 47 Contents unconfigure pim 2021 Chapter 24 IPX Commands—“i” Series Platforms Only configure ipxmaxhops 2024 configure ipxrip add vlan 2025 configure ipxrip delete vlan 2026 configure ipxrip vlan delay 2027 configure ipxrip vlan export-filter 2028 configure ipxrip vlan import-filter 2029 configure ipxrip vlan max-packet-size 2030 configure ipxrip vlan trusted-gateway 2031...
  • Page 48 Contents show ipxconfig 2055 show ipxfdb 2056 show ipxrip 2057 show ipxroute 2058 show ipxsap 2059 show ipxservice 2060 show ipxstats 2061 unconfigure ipxrip 2062 unconfigure ipxsap 2063 unconfigure vlan xnetid 2064 xping 2065 Chapter 25 ARM Commands—BlackDiamond Switch Only clear accounting counters 2069 configure route-map set accounting-index 1 value...
  • Page 49 Contents show wireless device-db 2092 show wireless redirect-db 2093 Chapter 27 ATM Commands—BlackDiamond 6800 Series Platforms Only configure atm add pvc 2096 configure atm delete pvc 2098 configure atm scrambling 2100 show atm 2101 show atm pvc 2104 Chapter 28 PoS Commands—BlackDiamond Switch Only configure aps 2108...
  • Page 50 Contents configure qosprofile 2140 configure red 2142 configure red min-threshold ports 2144 configure sonet clocking ports 2145 configure sonet framing ports 2146 configure sonet loop 2147 configure sonet signal label ports 2148 configure sonet threshold signal degrade ports 2149 configure sonet threshold signal fail ports 2150 configure sonet trace path ports 2151...
  • Page 51 Contents configure ports e1 receivergain 2180 configure ports e1 timeslots 2181 configure ports snmp alert 2182 configure ports t1 cablelength 2183 configure ports t1 fdl 2184 configure ports t1 framing 2185 configure ports t1 lbdetect 2186 configure ports t1 linecoding 2187 configure ports t1 yellow 2188...
  • Page 52 Contents show multilink 2216 show multilink alarms 2217 show multilink e1 errors 2218 show multilink stats 2219 show multilink t1 errors 2220 show ports alarms 2221 show ports configuration 2222 show ports errors 2223 show ports e1 errors 2224 show ports info 2225 show ports stats 2226...
  • Page 53 Contents run diagnostics cable 2256 show application examination 2258 show diagnostics cable 2259 show ports egress-rate-limit 2262 show ports ingress stats 2264 show qosprofile ingress 2267 show qostype ingress priority 2269 unconfigure diffserv ingress replacement ports 2270 unconfigure qostype ingress priority 2271 Chapter 31 Power Over Ethernet Commands—Summit 300 and 400-24p Switches...
  • Page 54 Contents enable inline-power ports 2306 enable inline-power slots 2308 reset inline-power ports 2310 reset inline-power slot 2311 show inline-power 2312 show inline-power configuration port 2314 show inline-power configuration slot 2316 show inline-power info show inline-power info port 2318 show inline-power slot 2322 show inline-power stats ports 2324...
  • Page 55 Contents configure lldp ports vendor-specific dot3 power-via-mdi 2350 configure lldp reinitialize-delay 2351 configure lldp snmp-notification-interval 2352 configure lldp transmit-delay 2353 configure lldp transmit-hold 2354 configure lldp transmit-interval 2355 disable lldp ports 2356 disable snmp traps lldp port 2357 enable lldp ports 2358 enable snmp traps lldp port 2359...
  • Page 56 Contents configure mpls rsvp-te add profile 2395 configure mpls rsvp-te profile 2396 configure mpls tls-tunnel lsp 2397 configure mpls vpls 2398 configure mpls vpls add 2400 configure mpls vpls add peer 2402 configure mpls vpls delete 2405 configure mpls vpls delete peer 2406 configure mpls vpls peer 2407...
  • Page 57 Contents configure mpls health-check delete vplsping 2446 configure mpls health-check delete vplsping 2447 configure mpls ldp acl 2448 configure mpls ldp acl add peer 2449 configure mpls ldp acl delete peer 2450 configure mpls ldp advertise 2451 configure mpls ldp advertise vlan 2453 configure mpls php 2454...
  • Page 58 Contents enable mpls 2496 mplsping 2497 mplstrace 2499 show fdb vpls 2501 show mpls health-check mplsping 2502 show mpls health-check vplsping 2503 show mpls ldp acl 2504 show mpls 2505 show mpls forwarding 2506 show mpls interface 2508 show mpls label 2509 show mpls ldp 2511...
  • Page 59 This guide is intended for use as a reference by network administrators who are responsible for installing and setting up network equipment. It assumes knowledge of Extreme Networks switch configuration. For conceptual information and guidance on configuring Extreme Networks switches, see the ExtremeWare Software User Guide for your version of the ExtremeWare software.

  • Page 60: Related Publications

    The publications related to this one are: • ExtremeWare release notes • ExtremeWare User Guide • Consolidated Hardware Installation Guide Documentation for Extreme Networks products is available on the World Wide Web at the following location: http://www.extremenetworks.com/ ExtremeWare 7.5 Command Reference Guide...

  • Page 61: Using Extremeware Publications Online

    Related Publications Using ExtremeWare Publications Online You can access ExtremeWare publications by downloading them from the Extreme Networks World ® Wide Web location or from your ExtremeWare product CD. Publications are provided in Adobe Portable Document Format (PDF). Displaying or printing PDF files requires that your computer be ®...
  • Page 62 Preface Using Adobe Reader Version 6.0. If you are using Adobe Reader version 6.0 or later, or if you are using Reader embedded in Adobe Acrobat version 6.0 or later, follow these steps to ensure proper concurrent viewing and linking of both the user guide and command reference guide PDF files: 1 Double-click a PDF icon to open the Adobe Reader or Adobe Acrobat window.
  • Page 63 This guide does not provide feature descriptions, explanations of the technologies, or configuration examples. For information about the various features and technologies supported by Extreme Networks switches, see the installation and user guides for your product. This guide does not replace the installation and user guides;...
  • Page 64 Command Reference Overview • Protocol Independent Multicast (PIM) concepts (PIM dense mode commands are supported only on the “i” series platforms.) • Internet Packet Exchange (IPX) concepts (IPX-related commands are supported only on the “i” series platforms.) • Server Load Balancing (SLB) concepts (SLB-related commands are supported only on the “i” series platforms.) •...

  • Page 65: Understanding The Command Syntax

    Understanding the Command Syntax Understanding the Command Syntax When entering a command at the prompt, be sure that you have the appropriate privilege level. Most configuration commands require you to have the administrator privilege level. A variety of symbols are shown in this guide as part of the command syntax. These symbols explain how to enter the command, and you do not type them as part of the command itself.

  • Page 66: Command Shortcuts

    Command Reference Overview Abbreviated Syntax Abbreviated syntax is the shortest unambiguous allowable abbreviation of a command or parameter. Typically, this is the first three letters of the command. If you do not enter enough letters to allow the switch to determine which command you mean, the syntax helper will provide a list of the options based on the portion of the command you have entered.
  • Page 67 Line-Editing Keys You can specify all ports on a particular slot. For example, port 3:* indicates all ports on slot 3. You can specify a range of slots and ports. For example, port 2:3-4:5 indicates slot 2, port 3 through slot 4, port 5. Stand-alone Switch Numerical Ranges Commands that require you to enter one or more port numbers on a stand-alone switch use the parameter...

  • Page 68: Command History

    Command Reference Overview Command History ExtremeWare “remembers” the last 49 commands you entered. You can display a list of these commands by using the following command: history ExtremeWare 7.5 Command Reference Guide...

  • Page 69: Commands For Accessing The Switch

    Commands for Accessing the Switch This chapter describes: • Commands used for accessing and configuring the switch including how to set up user accounts, passwords, date and time settings, and software licenses • Commands used for configuring the Domain Name Service (DNS) client •...

  • Page 70: Clear Account Lockout

    Commands for Accessing the Switch clear account lockout clear account [all | <name>] lockout Description Re-enables an account that has been locked out (disabled) for exceeding the permitted number failed login attempts, which was configured by using the configure account password-policy command.

  • Page 71: Clear Session

    clear session clear session clear session <number> Description Terminates a Telnet, SSH, NetLogin, or Console session from the switch. Syntax Description number Specifies a session number from show session output to terminate. Default Usage Guidelines An administrator-level account can disconnect a management session that has been established by way of a Telnet connection.

  • Page 72: Configure Account

    Commands for Accessing the Switch configure account configure account <user account> {encrypted} {<password>} Description Configures a user account password. Syntax Description user account Specifies a user account name. encrypted This option is for use only by the switch when generating an ASCII configuration file. Specifies that the password should be encrypted when the configuration is uploaded to a file.
  • Page 73 configure account Example The following command defines a new password for the account admin: configure account admin The switch responds with a password prompt: password: Your keystrokes will not be echoed as you enter the new password. After you enter the password, the switch will then prompt you to reenter it.

  • Page 74: Configure Account Password-Policy Char-Validation

    Commands for Accessing the Switch configure account password-policy char-validation configure account [all | <name>] password-policy char-validation [none | all-char-groups] Description Requires that the user include an upper-case letter, a lower-case letter, a digit, and a symbol in the password. Syntax Description Specifies all users (and future users).
  • Page 75 configure account password-policy char-validation Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 76: Configure Account Password-Policy History

    Commands for Accessing the Switch configure account password-policy history configure account [all | <name>] password-policy history [<num_passwords> | none] Description Configures the switch to verify the specified number of previous passwords for the account. The user is prevented from changing the password on a user or administrative account to any of these previously saved passwords.

  • Page 77: Configure Account Password-Policy Lockout-On-Login-Failures

    configure account password-policy lockout-on-login-failures configure account password-policy lockout-on-login-failures configure account [all | <name>] password-policy lockout-on-login-failures [on | off] Description Disables an account after the user has 3 consecutive failed login attempts. Syntax Description Specifies all users (and future users). name Specifies an account name.

  • Page 78: Configure Account Password-Policy Maxage

    Commands for Accessing the Switch configure account password-policy maxage configure account [all | <name>] password-policy maxage [<num_days> | none] Description Configures a time limit for the passwords for specified accounts. The passwords for the default admin account and the failsafe account do not age out. Syntax Description Specifies all accounts (and future users).

  • Page 79: Configure Account Password-Policy Min-Pwd-Length

    configure account password-policy min-pwd-length configure account password-policy min-pwd-length configure account [all | <name>] password-policy min-pwd-length [<num_characters> | none] Description Requires a minimum number of characters for passwords. Syntax Description Specifies all accounts (and future users). name Specifies an account name. num_characters Specifies the minimum number of characters required for the password.
  • Page 80 Commands for Accessing the Switch Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 81: Configure Banner

    configure banner configure banner configure banner Description Configures the banner string that is displayed at the beginning of each login prompt of each session. Syntax Description This command has no arguments or variables. Default Usage Guidelines Press [Return] at the beginning of a line to terminate the command and apply the banner. To clear the banner, press [Return] at the beginning of the first line.

  • Page 82: Configure Banner Netlogin

    Commands for Accessing the Switch configure banner netlogin configure banner netlogin Description Configures the network login banner that is displayed at the beginning of each login prompt of each session. Syntax Description This command has no arguments or variables. Default Usage Guidelines The network login banner and the switch banner cannot be used at the same time.

  • Page 83: Configure Dns-Client Add

    configure dns-client add configure dns-client add configure dns-client add <ipaddress> Description Adds a DNS name server to the available server list for the DNS client. Syntax Description ipaddress Specifies an IP address. Default Usage Guidelines Up to three DNS name servers can be configured in ExtremeWare versions prior to 6.2.1. In ExtremeWare 6.2.1 and later, eight DNS name servers can be configured.

  • Page 84: Configure Dns-Client Add Domain-Suffix

    Commands for Accessing the Switch configure dns-client add domain-suffix configure dns-client add domain-suffix <domain_name> Description Adds a domain name to the domain suffix list. Syntax Description domain_name Specifies a domain name. Default Usage Guidelines The domain suffix list can include up to six items. If the use of all previous names fails to resolve a name, the most recently added entry on the domain suffix list will be the last name used during name resolution.

  • Page 85: Configure Dns-Client Add Name-Server

    configure dns-client add name-server configure dns-client add name-server configure dns-client add name-server <ipaddress> Description Adds a DNS name server to the available server list for the DNS client. Syntax Description ipaddress Specifies an IP address. Default Usage Guidelines Up to three DNS name servers can be configured in ExtremeWare versions prior to 6.2.1. In ExtremeWare 6.2.1 and later, eight DNS name servers can be configured.

  • Page 86: Configure Dns-Client Default-Domain

    Commands for Accessing the Switch configure dns-client default-domain configure dns-client default-domain <domain_name> Description Configures the domain that the DNS client uses if a fully qualified domain name is not entered. Syntax Description domain_name Specifies a default domain name. Default Usage Guidelines Sets the DNS client default domain name to .

  • Page 87: Configure Dns-Client Delete

    configure dns-client delete configure dns-client delete configure dns-client delete <ipaddress> Description Removes a DNS name server from the available server list for the DNS client. Syntax Description ipaddress Specifies an IP address. Default Usage Guidelines None Example The following command removes a DNS server from the list: configure dns-client delete 10.1.2.1 History This command was first available in ExtremeWare 4.0.

  • Page 88: Configure Dns-Client Delete Domain-Suffix

    Commands for Accessing the Switch configure dns-client delete domain-suffix configure dns-client delete domain-suffix <domain_name> Description Deletes a domain name from the domain suffix list. Syntax Description domain_name Specifies a domain name. Default Usage Guidelines This command randomly removes an entry from the domain suffix list. If the deleted item was not the last entry in the list, all items that had been added later are moved up in the list.

  • Page 89: Configure Dns-Client Delete Name-Server

    configure dns-client delete name-server configure dns-client delete name-server configure dns-client delete name-server <ipaddress> Description Removes a DNS name server from the available server list for the DNS client. Syntax Description ipaddress Specifies an IP address. Default Usage Guidelines None. Example The following command removes a DNS server from the list: configure dns-client delete name-server 10.1.2.1 History...

  • Page 90: Configure Idletimeouts

    Commands for Accessing the Switch configure idletimeouts configure idletimeouts <minutes> Description Configures the time-out for idle HTTP, console, and Telnet sessions. Syntax Description minutes Specifies the time-out interval, in minutes. Range is 1 to 240 (1 minute to 4 hours). Default Default time-out is 20 minutes.

  • Page 91: Configure Time

    configure time configure time configure time <date> <time> Description Configures the system date and time. Syntax Description date Specifies the date in mm/dd/yyyy format. time Specifies the time in hh:mm:ss format. Default Usage Guidelines The format for the system date and time is as follows: mm/dd/yyyy hh:mm:ss The time uses a 24-hour clock format.

  • Page 92: Configure Timezone

    Commands for Accessing the Switch configure timezone configure timezone {name <std_timezone_ID>} <GMT_offset> {autodst {name <dst_timezone_ID>} {<dst_offset>} {begins [every <floatingday> | on <absoluteday>] {at <time_of_day>} {ends [every <floatingday> | on <absoluteday>] {at <time_of_day>}}} | noautodst} Description Configures the Greenwich Mean Time (GMT) offset and Daylight Saving Time (DST) preference. Syntax Description GMT_offset Specifies a Greenwich Mean Time (GMT) offset, in + or - minutes.
  • Page 93 configure timezone Usage Guidelines Network Time Protocol (NTP) server updates are distributed using GMT time. To properly display the local time in logs and other timestamp information, the switch should be configured with the appropriate offset to GMT based on geographic location. is specified in +/- minutes from the GMT time.
  • Page 94 Commands for Accessing the Switch Table 5: Greenwich Mean Time Offsets (Continued) GMT Offset GMT Offset in Hours in Minutes Common Time Zone References Cities -5:00 -300 EST - Eastern Standard Bogota, Columbia; Lima, Peru; New York, NY, Trevor City, MI USA -6:00 -360 CST - Central Standard...
  • Page 95 configure timezone Example The following command configures GMT offset for Mexico City, Mexico and disables automatic DST: configure timezone -360 noautodst The following four commands are equivalent, and configure the GMT offset and automatic DST adjustment for the US Eastern timezone, with an optional timezone ID of EST: configure timezone name EST -300 autodst name EDT 60 begins every first sunday april at 2:00 ends every last sunday october at 2:00 configure timezone name EST -300 autodst name EDT 60 begins every 1 1 4 at 2:00 ends...

  • Page 96: Create Account

    Commands for Accessing the Switch create account create account [admin | user] <username> {encrypted} {<password>} Description Creates a new user account. Syntax Description admin Specifies an access level for account type admin. user Specifies an access level for account type user. username Specifies a new user account name.
  • Page 97 create account For ExtremeWare 4.x: • User account name specifications are not available. • Passwords must have a minimum of 4 characters and can have a maximum of 12 characters. • The encrypted option should only be used by the switch to generate an ASCII configuration (using command), and parsing a switch-generated configuration (using the upload configuration command).

  • Page 98: Delete Account

    Commands for Accessing the Switch delete account delete account <username> Description Deletes a specified user account. Syntax Description username Specifies a user account name. Default Usage Guidelines Use the command to determine which account you want to delete from the system. The show accounts show accounts output displays the following information in a tabular format: •...
  • Page 99 delete account Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 100: Disable Clipaging

    Commands for Accessing the Switch disable clipaging disable clipaging Description Disables pausing at the end of each show screen. Syntax Description This command has no arguments or variables. Default Enabled Usage Guidelines The command line interface (CLI) is designed for use in a VT100 environment. Most command show output will pause when the display reaches the end of a page.

  • Page 101: Disable Idletimeouts

    disable idletimeouts disable idletimeouts disable idletimeouts Description Disables the timer that disconnects idle sessions from the switch. Syntax Description This command has no arguments or variables. Default Enabled. Timeout 20 minutes. Usage Guidelines When idle time-outs are disabled, console sessions remain open until the switch is rebooted or you logoff.

  • Page 102: Enable Clipaging

    Commands for Accessing the Switch enable clipaging enable clipaging Description Enables the pause mechanism and does not allow the display to print continuously to the screen. Syntax Description This command has no arguments or variables. Default Enabled Usage Guidelines The command line interface (CLI) is designed for use in a VT100 environment. Most command show output will pause when the display reaches the end of a page.

  • Page 103: Enable Idletimeouts

    enable idletimeouts enable idletimeouts enable idletimeouts Description Enables a timer that disconnects Telnet and console sessions after 20 minutes of inactivity. Syntax Description This command has no arguments or variables. Default Enabled. Timeout 20 minutes. Usage Guidelines You can use this command to ensure that a Telnet, HTTP, or console session is disconnected if it has been idle for the required length of time.

  • Page 104: Enable License

    Commands for Accessing the Switch enable license For the “i” series switches: enable license [basic_L3 | advanced_L3 | full_L3 ] <license_key> For the “e” series switches: enable license [advanced-edge] <license_key> Description Enables a particular software feature license. Syntax Description basic_L3 Specifies a basic L3 license.
  • Page 105 enable license This command was added to the “e” series of switches in ExtremeWare 7.1e. Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 106: History

    Commands for Accessing the Switch history history Description Displays a list of the previous 49 commands entered on the switch. Syntax Description This command has no arguments or variables. Default Usage Guidelines ExtremeWare “remembers” the last 49 commands you entered on the switch. Use the history command to display a list of these commands.

  • Page 107: Reboot

    reboot reboot For the “i” series switches: reboot {time <date> <time> | cancel} {slot <slot number> | msm-a | msm-b} For the “e” series switches: reboot {time <date> <time> | cancel}{slot <slot number>} Description Reboots the switch or the module in the specified slot at a specified date and time. Syntax Description date Specifies a reboot date in mm/dd/yyyy format.
  • Page 108 Commands for Accessing the Switch The E1, T1, and T3 command does not support the keywords, so this reboot slot time cancel command can only be executed immediately. Example The following command reboots the switch at 8:00 AM on April 15, 2002: reboot 04/15/2002 08:00:00 On the “i”...

  • Page 109: Show Accounts Password-Policy

    show accounts password-policy show accounts password-policy show accounts password-policy Description Displays password policy information for all users on the switch. Syntax Description This command has no arguments or variables. Default Usage Guidelines To view the password management information, you must have administrator privileges. command displays the following information in a tabular show accounts password-policy format:...
  • Page 110 Commands for Accessing the Switch Output from this command looks similar to the following: --------------------------------------------------------------------------- Accounts global configuration(applied to new accounts on creation) --------------------------------------------------------------------------- Password Max. age : None Password History limit : None Password Min. length : None Password Character Validation : Disabled Accts.

  • Page 111: Show Accounts Pppuser

    show accounts pppuser show accounts pppuser show accounts pppuser Description Displays user account information for all users on the switch. Syntax Description This command has no arguments or variables. Default Usage Guidelines You need to create a user account using the command before you can display user create account account information.
  • Page 112 Commands for Accessing the Switch Platform Availability This command is only available on the “i” series of switches. ExtremeWare 7.5 Command Reference Guide...

  • Page 113: Show Banner

    Use this command to view the banner that is displayed before the login prompt. Example The following command displays the switch banner: show banner Output from this command looks similar to the following: Extreme Networks Summit48i Layer 3 Switch ######################################################### Unauthorized Access is strictly prohibited. Violators will be prosecuted. ######################################################### History This command was first available in ExtremeWare 2.0.

  • Page 114: Show Dns-Client

    Commands for Accessing the Switch show dns-client show dns-client Description Displays the DNS configuration. Syntax Description This command has no arguments or variables. Default Usage Guidelines None. Example The following command displays the DNS configuration: show dns-client Output from this command looks similar to the following: Number of domain suffixes: 2 Domain Suffix 1: njudah.local...

  • Page 115: Show Esrp-Aware

    show esrp-aware show esrp-aware show esrp-aware [vlan <vlan name>] Description Displays ESRP awareness information. Syntax Description vlan name Specifies a VLAN name. Default Without the vlan option, the show command displays all VLAN interfaces receiving ESRP packets. Usage Guidelines The VLANs associated with the ports connecting an ESRP-aware switch to an ESRP-enabled switch must be configured using an 802.1Q tag on the connecting port, or, if only a single VLAN is involved, as untagged.

  • Page 116: Show Switch

    Commands for Accessing the Switch show switch show switch Description Displays the current switch information. Syntax Description This command has no arguments or variables. Default Usage Guidelines Viewing statistics on a regular basis allows you to see how well your network is performing. If you keep simple daily records, you will see trends emerging and notice problems arising before they cause major network faults.
  • Page 117 Example The following command displays current switch information: show switch Output from this command looks similar to the following: SysName: Alpine3804 SysLocation: Extreme Networks HQ SysContact: Carlos_Beronio System MAC: 00:01:30:23:C1:00 License: Full L3 System Mode: 802.1Q EtherType is 8100 (Hex).
  • Page 118 Commands for Accessing the Switch Image Booted: Primary Primary EW Ver: 7.0.0b61 [unknown-ssh] Secondary EW Ver: 7.1.0b34 [non-ssh] Module Image Selected Image Booted ------ -------------- ------------ Secondary Secondary Slot 2 (WM4T1) Secondary Secondary Config Selected: Primary Config Booted: Primary Primary Config: Created by EW Version: 7.1.0 Build 34 [38]...
  • Page 119 show switch 7.2e.0 Build 26 [46] 5990 bytes saved on Wed Jan 12 15:54:31 2056 Secondary Config: Empty * Summit400-48t:3 # History This command was first available in ExtremeWare 2.0. This command was modified in ExtremeWare 6.1.8 to display the mode of switch operation—extended, standard, or auto—for the Alpine 3802.

  • Page 120: Traceroute

    Commands for Accessing the Switch traceroute traceroute <host name | ip_address> {from <source IP address>} {ttl <number>} {port <port number>} Description Enables you to trace the routed path between the switch and a destination endstation. Syntax Description host name Specifies the hostname of the destination endstation. ip_address Specifies the IP address of the destination endstation.

  • Page 121: Commands For Managing The Switch

    Commands for Managing the Switch This chapter describes: • Commands for configuring Simple Network Management Protocol (SNMP) parameters on the switch • Commands for managing the switch using Telnet and web access • Commands for configuring Simple Network Time Protocol (SNTP) parameters on the switch SNMP Any network manager running the Simple Network Management Protocol (SNMP) can manage the switch, if the Management Information Base (MIB) is installed correctly on the management station.

  • Page 122: Simple Network Time Protocol

    Commands for Managing the Switch The following can also be configured on the switch for version 6.0 and higher: • SNMP read access—The ability to read SNMP information can be restricted through the use of an access profile. An access profile permits or denies a named list of IP addresses and subnet masks. •...

  • Page 123: Configure Snmp Access-Profile Readonly

    configure snmp access-profile readonly configure snmp access-profile readonly configure snmp access-profile readonly [<access-profile> | none] Description Assigns an access profile that limits which stations have read-only access to the switch. Syntax Description access-profile Specifies a user defined access profile. none Cancels a previously configured access profile.
  • Page 124 Commands for Managing the Switch Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 125: Configure Snmp Access-Profile Readwrite

    configure snmp access-profile readwrite configure snmp access-profile readwrite configure snmp access-profile readwrite [<access-profile> | none] Description Assigns an access profile that limits which stations have read/write access to the switch. Syntax Description access-profile Specifies a user defined access profile. none Cancels a previously configured access profile.
  • Page 126 Commands for Managing the Switch This command was added to the Summit “e” series of switches in 7.2e. Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 127: Configure Snmp Add Community

    configure snmp add community configure snmp add community configure snmp add community [readonly | readwrite] {encrypted} <alphanumeric string> Description Adds an SNMP read or read/write community string. Syntax Description readonly Specifies read-only access to the system. readwrite Specifies read and write access to the system. encrypted Specifies encryption, for use only by the switch when uploading or downloading a configuration.
  • Page 128 Commands for Managing the Switch • The parameter is included in the command syntax. It is available only in version 2.0. • SNMP community strings can contain up to 127 characters. Example The following command adds a read/write community string with the value extreme: configure snmp add community readwrite extreme History This command was first available in ExtremeWare 6.2.

  • Page 129: Configure Snmp Add Trapreceiver

    Specifies that BGP traps will be sent to the trap receiver. NOTE: This option is only available on the “i” series of switches. extreme-traps Specifies that Extreme Networks specific traps will be sent to the trap receiver. link-up-down-traps Specifies that link state traps will be sent to the trap receiver.
  • Page 130 Commands for Managing the Switch Default Trap receivers are in enhanced mode by default, and the version is SNMPv2c by default. Usage Guidelines The IP address can be unicast, multicast, or broadcast. An authorized trap receiver can be one or more network management stations on your network. Authorized trap receivers must be configured on the switch for the trap receiver to receive switch-generated traps.
  • Page 131 configure snmp add trapreceiver Table 7: SNMP Trap Groups (Continued) Trap Group Notifications MIB Subtree system-traps extremeOverheat 1.3.6.1.4.1.1916.0.6 extremeFanFailed 1.3.6.1.4.1.1916.0.7 extremeFanOK 1.3.6.1.4.1.1916.0.8 extremePowerSupplyFail 1.3.6.1.4.1.1916.0.10 extremePowerSupplyGood 1.3.6.1.4.1.1916.0.11 extremeModuleStateChange 1.3.6.1.4.1.1916.0.15 extremeHealthCheckFailed 1.3.6.1.4.1.1916.4.1.0.1 extremeCpuUtilizationRisingTrap 1.3.6.1.4.1.1916.4.1.0.2 extremeCpuUtilizationFallingTrap 1.3.6.1.4.1.1916.4.1.0.3 coldStart 1.3.6.1.6.3.1.1.5.1 warmStart 1.3.6.1.6.3.1.1.5.2 extreme-traps extremeEsrpStateChange 1.3.6.1.4.1.1916.0.17 extremeEdpNeighborAdded 1.3.6.1.4.1.1916.0.20...
  • Page 132 The following command adds port 9990 at the IP address 10.203.0.22 as a trap receiver with the community string public, and the receiver should be sent standard traps for the trap groups for BGP and Extreme Networks: configure snmp add trapreceiver ipaddress 10.203.0.22 port 9990 community public mode...

  • Page 133: Configure Snmp Community

    configure snmp community configure snmp community configure snmp community [readonly | readwrite] {encrypted} <alphanumeric string> Description Configures the value of the default SNMP read or read/write community string. Syntax Description readonly Specifies read-only access to the system. readwrite Specifies read and write access to the system. encrypted Specifies encryption, for use only by the switch when uploading or downloading a configuration.
  • Page 134 Commands for Managing the Switch History This command was first available in ExtremeWare 1.0. This command was added to the Summit “e” series of switches in 7.1e. This command was modified in ExtremeWare 7.2e to add support for encryption. Platform Availability This command is available on all platforms.

  • Page 135: Configure Snmp Delete Community

    configure snmp delete community configure snmp delete community configure snmp delete community [readonly | readwrite] {encrypted} [all | <alphanumeric string>] Description Deletes an SNMP read or read/write community string. Syntax Description readonly Specifies read-only access to the system. readwrite Specifies read and write access to the system. encrypted Specifies an encrypted option.
  • Page 136 Commands for Managing the Switch Example The following command deletes a read/write community string named extreme: configure snmp delete community readwrite extreme History This command was first available in ExtremeWare 2.0. Support for the parameter was discontinued in ExtremeWare 4.0. This command was added to the Summit “e”...

  • Page 137: Configure Snmp Delete Trapreceiver

    configure snmp delete trapreceiver configure snmp delete trapreceiver configure snmp delete trapreceiver [ip address> | {all}] Description Deletes a specified trap receiver or all authorized trap receivers. Syntax Description ip address Specifies an SNMP trap receiver IP address. Specifies all SNMP trap receiver IP addresses. Default The default port number is 162.
  • Page 138 Commands for Managing the Switch Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 139: Configure Snmp Syscontact

    configure snmp sysContact configure snmp sysContact configure snmp syscontact <alphanumeric string> Description Configures the name of the system contact. Syntax Description alphanumeric string Specifies a system contact name. Default N/A. Usage Guidelines The system contact is a text field that enables you to enter the name of the person(s) responsible for managing the switch.

  • Page 140: Configure Snmp Syslocation

    Commands for Managing the Switch configure snmp sysLocation configure snmp syslocation <alphanumeric string> Description Configures the location of the switch. Syntax Description alphanumeric string Specifies the switch location. Default N/A. Usage Guidelines Use this command to indicate the location of the switch. A maximum of 255 characters is allowed. To view the location of the switch on the switch, use the command.

  • Page 141: Configure Snmp Sysname

    configure snmp sysName configure snmp sysName configure snmp sysname <alphanumeric string> Description Configures the name of the switch. Syntax Description alphanumeric string Specifies a device name. Default The default is the model name of the device (for example, sysname Summit1 Usage Guidelines You can use this command to change the name of the switch.

  • Page 142: Configure Snmpv3 Add Access

    Commands for Managing the Switch configure snmpv3 add access configure snmpv3 add access [hex <hex value> | <group name>] {sec-model [snmpv1 | snmpv2 | usm]} {sec-level [noauth | authnopriv | authpriv]} {read-view [hex <hex value> | <view name>] { write-view [hex <hex value> | <view name>] {notify-view [hex <hex value>...
  • Page 143 configure snmpv3 add access • The default groups defined (permanent) are v1v2c_ro for security names snmpv1 and snmpv2c, v1v2c_rw for security names snmpv1 and snmpv2c, admin for security name admin, and initial for security names initial, initialmd5, initialsha, initialmd5Priv and initialshaPriv. •...

  • Page 144: Configure Snmpv3 Add Community

    Commands for Managing the Switch configure snmpv3 add community configure snmpv3 add community {hex <hex value>} <community index> name {hex <hex value>} <community name> user {hex <hex value>} <user name> {tag {hex <hex value>} <transport tag>} {volatile} Description Add an SNMPv3 community entry. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets.
  • Page 145 configure snmpv3 add community Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 146: Configure Snmpv3 Add Filter

    Commands for Managing the Switch configure snmpv3 add filter configure snmpv3 add filter {hex <hex value>} <profile name> subtree <object identifier> {/<subtree mask>} type [included | excluded] {volatile} Description Add a filter to a filter profile. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets.
  • Page 147 configure snmpv3 add filter Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 148: Configure Snmpv3 Add Filter-Profile

    Commands for Managing the Switch configure snmpv3 add filter-profile configure snmpv3 add filter-profile {hex <hex value>} <profile name> param {hex <hex value>} <param name> {volatile} Description Associate a filter profile with a parameter name. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets.

  • Page 149: Configure Snmpv3 Add Group User

    configure snmpv3 add group user configure snmpv3 add group user configure snmpv3 add group [hex <hex value> | <group name>] user [ hex <hex value} | <user name>] {sec-model [snmpv1| snmpv2 | usm]} {volatile} Description Add a user name (security name) to a group. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets.
  • Page 150 Commands for Managing the Switch History This command was first available in ExtremeWare 7.1.0. This command was added to the Summit “e” series of switches in ExtremeWare 7.2e. Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 151: Configure Snmpv3 Add Mib-View

    configure snmpv3 add mib-view configure snmpv3 add mib-view configure snmpv3 add mib-view [{hex <hex value>} | <view name> subtree <object identifier> {/<subtree mask>} {type [included | excluded]} {volatile} Description Add (and modify) a MIB view. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets.
  • Page 152 Commands for Managing the Switch configure snmpv3 add mib-view vrrpTrapNewMaster 1.3.6.1.2.1.68.0.1/ff8 type excluded volatile History This command was first available in ExtremeWare 7.1.0. This command was added to the Summit “e” series of switches in ExtremeWare 7.2e. Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 153: Configure Snmpv3 Add Notify

    configure snmpv3 add notify configure snmpv3 add notify configure snmpv3 add notify {hex <hex value>} <notify name> tag {hex <hex value>} <tag> {volatile} Description Add an entry to the snmpNotifyTable. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets.

  • Page 154: Configure Snmpv3 Add Target-Addr

    Commands for Managing the Switch configure snmpv3 add target-addr configure snmpv3 add target-addr [{hex <hex value>} | <addr name>] param [{hex <hex value>} | <param name>] ipaddress <ip address> {/<target-addr mask>} {transport-port <port>} {from <source IP address>} {tag-list {hex <hex value>} <tag>, {hex <hex value>} <tag>, ...} {volatile} Description Add and configure an SNMPv3 target address and associate filtering, security, and notifications with that address.
  • Page 155 configure snmpv3 add target-addr History This command was first available in ExtremeWare 7.1.0. This command was added to the Summit “e” series of switches in ExtremeWare 7.2e. Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 156: Configure Snmpv3 Add Target-Params

    Commands for Managing the Switch configure snmpv3 add target-params configure snmpv3 add target-params [hex <hex value> | <param name>] user [hex <hex value> | <user name>] mp-model [snmpv1 | snmpv2c | snmpv3] sec-model [snmpv1 | snmpv2c | usm] {sec-level [noauth | authnopriv | priv]} {volatile} Description Add and configure SNMPv3 target parameters.
  • Page 157 configure snmpv3 add target-params configure snmpv3 add target-params P1 user guest mp-model snmpv2c sec-model snmpv2c sec-level noauth History This command was first available in ExtremeWare 7.1.0. This command was added to the Summit “e” series of switches in ExtremeWare 7.2e. Platform Availability This command is available on all platforms.

  • Page 158: Configure Snmpv3 Add User

    Commands for Managing the Switch configure snmpv3 add user configure snmpv3 add user {hex} <user name> {authentication [md5 | sha] [hex <hex octet> | <password>]} {privacy [hex <hex octet> | <password>]} {volatile} Description Add (and modify) an SNMPv3 user. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets.
  • Page 159 configure snmpv3 add user Use the following command to configure the user authMD5 to use authentication with the password palertyu:· configure snmpv3 add user authMD5 authentication md5 palertyu Use the following command to configure the user authSHApriv to use authentication with the hex key shown below, the privacy password palertyu, and storage: volatile...

  • Page 160: Configure Snmpv3 Add User Clone-From

    Commands for Managing the Switch configure snmpv3 add user clone-from configure snmpv3 add user {hex <hex value>} <user name> clone-from {hex <hex value>} <user name> Description Create a new user by cloning from an existing SNMPv3 user. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets.

  • Page 161: Configure Snmpv3 Delete Access

    configure snmpv3 delete access configure snmpv3 delete access configure snmpv3 delete access [all-non-defaults | {hex <hex value>} | <group name> {sec-model [snmpv1 | snmpv2c | usm] sec-level [noauth | authnopriv | priv]}}] Description Delete access rights for a group. Syntax Description all-non-defaults Specifies that all non-default (non-permanent) security groups are to be deleted.
  • Page 162 Commands for Managing the Switch The following command deletes the group userGroup with the security model and security level snmpv1 of authentication and no privacy ( authnopriv configure snmpv3 delete access userGroup sec-model snmpv1 sec-level authnopriv History This command was first available in ExtremeWare 7.1.0. This command was added to the Summit “e”...

  • Page 163: Configure Snmpv3 Delete Community

    configure snmpv3 delete community configure snmpv3 delete community configure snmpv3 delete community [all-non-defaults | {{hex <hex value>} <community index>} | {name {hex <hex value>} <community name> }] Description Delete an SNMPv3 community entry. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets.

  • Page 164: Configure Snmpv3 Delete Filter

    Commands for Managing the Switch configure snmpv3 delete filter configure snmpv3 delete filter [all | [{hex <hex value>} <profile name> {subtree <object identifier>}]] Description Delete a filter from a filter profile. Syntax Description Specifies all filters. Specifies that the value to follow is to be supplied as a colon separated string of hex octets.

  • Page 165: Configure Snmpv3 Delete Filter-Profile

    configure snmpv3 delete filter-profile configure snmpv3 delete filter-profile configure snmpv3 delete filter-profile [all |[{hex <hex value>}<profile name> {param {hex <hex value>}<param name>}]] Description Remove the association of a filter profile with a parameter name. Syntax Description Specifies all filter profiles. Specifies that the value to follow is to be supplied as a colon separated string of hex octets.

  • Page 166: Configure Snmpv3 Delete Group User

    Commands for Managing the Switch configure snmpv3 delete group user configure snmpv3 delete group {{hex <hex value>} | <group name>} user [all-non-defaults | {{hex <hex value>} |<user name>} {sec-model [snmpv1|snmpv2c|usm]}] Description Delete a user name (security name) from a group. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets.
  • Page 167 configure snmpv3 delete group user Use the following command to delete the user guest from the group userGroup with the security model configure snmpv3 delete group userGroup user guest History This command was first available in ExtremeWare 7.1.0. This command was added to the Summit “e” series of switches in ExtremeWare 7.2e. Platform Availability This command is available on all platforms.

  • Page 168: Configure Snmpv3 Delete Mib-View

    Commands for Managing the Switch configure snmpv3 delete mib-view configure snmpv3 delete mib-view [all-non-defaults | {{hex <hex value>} | <view name> {subtree <object identifier>}] Description Delete a MIB view. Syntax Description all-non-defaults Specifies that all non-default (non-permanent) MIB views are to be deleted. Specifies that the value to follow is to be supplied as a colon separated string of hex octets.
  • Page 169 configure snmpv3 delete mib-view Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 170: Configure Snmpv3 Delete Notify

    Commands for Managing the Switch configure snmpv3 delete notify configure snmpv3 delete notify [{{hex <hex value>} <notify name>} | all-non-defaults] Description Delete an entry from the snmpNotifyTable. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets.

  • Page 171: Configure Snmpv3 Delete Target-Addr

    configure snmpv3 delete target-addr configure snmpv3 delete target-addr configure snmpv3 delete target-addr [{{hex <hex value>} | <addr name>| all}] Description Delete SNMPv3 target addresses. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets.

  • Page 172: Configure Snmpv3 Delete Target-Params

    Commands for Managing the Switch configure snmpv3 delete target-params configure snmpv3 delete target-params [{{hex <hex value>} <param name>} | all] Description Delete SNMPv3 target parameters. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets.

  • Page 173: Configure Snmpv3 Delete User

    configure snmpv3 delete user configure snmpv3 delete user configure snmpv3 delete user [all-non-defaults | {hex <hex value>} <user name>] Description Delete an existing SNMPv3 user. Syntax Description all-non-defaults Specifies that all non-default (non-permanent) users are to be deleted. Specifies that the value to follow is to be supplied as a colon separated string of hex octets.

  • Page 174: Configure Snmpv3 Engine-Boots

    Commands for Managing the Switch configure snmpv3 engine-boots configure snmpv3 engine-boots <(1-2147483647)> Description Configures the SNMPv3 Engine Boots value. Syntax Description (1-2147483647) Specifies the value of engine boots. Default N/A. Usage Guidelines Use this command if the Engine Boots value needs to be explicitly configured. Engine Boots and Engine Time will be reset to zero if the Engine ID is changed.

  • Page 175: Configure Snmpv3 Engine-Id

    Use this command if the needs to be explicitly configured. The first four octets of the ID snmpEngineID are fixed to 80:00:07:7C,which represents Extreme Networks Vendor ID. Once the snmpEngineID changed, default users will be reverted back to their original passwords/keys, while non-default users will be reset to the security level of no authorization, no privacy.

  • Page 176: Configure Snmpv3 Extreme-Target-Addr-Ext

    Commands for Managing the Switch configure snmpv3 extreme-target-addr-ext configure snmpv3 extreme-target-addr-ext {hex <hex value>} <addr name> mode [standard | enhanced] {ignore-mp-model} {ignore-event-community} Description Configure an entry in the extremeTargetAddrExtTable. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets.
  • Page 177 configure snmpv3 extreme-target-addr-ext This command was added to the Summit “e” series of switches in ExtremeWare 7.2e. Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 178: Configure Sntp-Client Server

    Commands for Managing the Switch configure sntp-client server configure sntp-client [primary | secondary] server <host name | ipaddress>] Description Configures an NTP server for the switch to obtain time information. Syntax Description primary Specifies a primary server name. secondary Specifies a secondary server name. host name/ip Specifies a host name.

  • Page 179: Configure Sntp-Client Update-Interval

    configure sntp-client update-interval configure sntp-client update-interval configure sntp-client update-interval <seconds> Description Configures the interval between polls for time information from SNTP servers. Syntax Description seconds Specifies an interval in seconds. Default 64 seconds. Usage Guidelines None. Example The following command configures the interval timer: configure sntp-client update-interval 30 History This command was first available in ExtremeWare 4.0.

  • Page 180: Configure Web Login-Timeout

    Commands for Managing the Switch configure web login-timeout configure web login-timeout <seconds> Description Configures the timeout for user to enter username/password in the pop-up window. Syntax Description seconds Specifies an interval in seconds, where <seconds> can range from 30 seconds to 10 minutes (600 seconds). Default 30 seconds.

  • Page 181: Disable Alt-Queue-Management

    disable alt-queue-management disable alt-queue-management disable alt-queue-management Description Disables the alternate queue management. Syntax Description This command has no arguments or variables. Default Disabled. Usage Guidelines The following command enables alternate queue management: enable alt-queue-management To disable the alternative queue management feature for the next boot, use the following command: disable alt-queue-management Example The following command disables alternate queue management:...

  • Page 182: Disable Dhcp Ports Vlan

    Commands for Managing the Switch disable dhcp ports vlan disable dhcp ports <portlist> vlan <vlan name> Description Disables DHCP on a specified port in a VLAN. Syntax Description portlist Specifies the ports for which DHCP should be disabled. vlan name Specifies the VLAN on whose ports DHCP should be disabled.

  • Page 183: Disable Eapol-Flooding

    disable eapol-flooding disable eapol-flooding disable eapol-flooding Description Disables EAPOL flooding on the switch. Syntax Description This command has no arguments or variables. Default Disabled. Usage Guidelines Per IEEE 802.1D, Summit “e’ series switches do not forward EAPOL frames. Also, if network login is enabled, EAPOL flooding cannot be enabled.

  • Page 184: Disable Snmp Access

    Commands for Managing the Switch disable snmp access disable snmp access {snmp-v1v2c} Description Selectively disables SNMP on the switch. Syntax Description snmp-v1v2c Disables SNMPv1/v2c access only; does not affect SNMPv3 access. Default Enabled. Usage Guidelines Disabling SNMP access does not affect the SNMP configuration (for example, community strings). However, if you disable SNMP access, you will be unable to access the switch using SNMP.

  • Page 185: Disable Snmp Dot1Dtpfdbtable

    disable snmp dot1dTpFdbTable disable snmp dot1dTpFdbTable disable snmp dot1dTpFdbTable Description Disables SNMP GetNext responses for the dot1dTpFdbTable in the BRIDGE-MIB. Syntax Description This command has no arguments or variables. Default Disabled. Usage Guidelines SNMP Get responses are not affected by this command. To view the configuration of the dot1dTpFdb table on the switch, use the command.

  • Page 186: Disable Snmp Traps

    Commands for Managing the Switch disable snmp traps disable snmp traps Description Prevents SNMP traps from being sent from the switch. Syntax Description This command has no arguments or variables. Default Enabled. Usage Guidelines This command does not clear the SNMP trap receivers that have been configured. The command prevents SNMP traps from being sent from the switch even if trap receivers are configured.

  • Page 187: Disable Snmp Traps Exceed-Committed-Rate Ports

    disable snmp traps exceed-committed-rate ports disable snmp traps exceed-committed-rate ports disable snmp traps exceed-committed-rate ports <portlist> {<Ingress QOS Profile>} Description Prevents SNMP traps from being sent from the indicated ports on the switch. Syntax Description “3” portlist Specifies a list of series I/O module ports (in the form 2:*, 2:5, or 2:6-2:8).

  • Page 188: Disable Snmp Traps Mac-Security

    Commands for Managing the Switch disable snmp traps mac-security disable snmp traps mac-security Description Prevents SNMP mac-security traps from being sent from the switch for all ports. Syntax Description This command has no arguments or variables. Default Disabled. Usage Guidelines This command should be used in conjunction with the configure ports <portlist>...

  • Page 189: Disable Snmp Traps Port-Up-Down

    disable snmp traps port-up-down disable snmp traps port-up-down disable snmp traps port-up-down ports [all | mgmt | <portlist>] Description Prevents SNMP port up/down traps (also known as link up and link down traps) from being sent from the switch for the indicated ports. Syntax Description Specifies that no link up/down traps should be sent for all ports.

  • Page 190: Disable Sntp-Client

    Commands for Managing the Switch disable sntp-client disable sntp-client Description Disables the SNTP client. Syntax Description This command has no arguments or variables. Default N/A. Usage Guidelines SNTP can be used by the switch to update and synchronize its internal clock from a Network Time Protocol (NTP) server.

  • Page 191: Disable System-Watchdog

    disable system-watchdog disable system-watchdog disable system-watchdog Description Disables the system watchdog timer. Syntax Description This command has no arguments or variables. Default Enabled. Usage Guidelines The watchdog timer reboots the switch if the CPU becomes trapped in a processing loop. If the watchdog timer is executed, the switch captures information on the cause of the reboot and posts it to the system log.

  • Page 192: Disable Telnet

    Commands for Managing the Switch disable telnet disable telnet Description Disables Telnet services on the system. Syntax Description This command has no arguments or variables. Default Enabled. Usage Guidelines You must be logged in as an administrator to enable or disable Telnet. Example With administrator privilege, the following command disables Telnet services on the switch: disable telnet...

  • Page 193: Disable Web

    disable web disable web disable web Description Disables web access to the switch. Syntax Description This command has no arguments or variables. Default Enabled. Usage Guidelines You can use this command to disable web access to the switch. If you are using ExtremeWare Vista for web access, you must create and configure an access profile before you can use this option.

  • Page 194: Enable Alt-Queue-Management

    Commands for Managing the Switch enable alt-queue-management enable alt-queue-management Description Enables the alternate queue management. Syntax Description This command has no arguments or variables. Default Disabled. Usage Guidelines Use this command to configure the alternative queue management feature for the next boot. Configuring the feature does not affect the queue management current boot.
  • Page 195 enable alt-queue-management Use the following command to disable alternate queue management: disable alt-queue-management Example The following command configures alternate queue management: enable alt-queue-management History This command was available in ExtremeWare 7.2. Platform Availability This command is only available on the “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 196: Enable Dhcp Ports Vlan

    Commands for Managing the Switch enable dhcp ports vlan enable dhcp ports <portlist> vlan <vlan name> Description Enables DHCP on a specified port in a VLAN. Syntax Description portlist Specifies the ports for which DHCP should be enabled. vlan_name Specifies the VLAN on whose ports DHCP should be enabled. Default N/A.

  • Page 197: Enable Eapol-Flooding

    enable eapol-flooding enable eapol-flooding enable eapol-flooding Description Enables EAPOL flooding on the switch. Syntax Description This command has no arguments or variables. Default Disabled. Usage Guidelines Per IEEE 802.1D, Summit “e’ series switches do not forward EAPOL frames. Also, if network login is enabled, EAPOL flooding cannot be enabled.

  • Page 198: Enable Snmp Access

    Commands for Managing the Switch enable snmp access enable snmp access Description Turns on SNMP support for SNMPv3 and v1/v2c on the switch. Syntax Description This command has no arguments or variables. Default Enabled. Usage Guidelines To have access to the SNMP agent residing in the switch, at least one VLAN must have an IP address assigned to it.
  • Page 199 enable snmp access Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 200: Enable Snmp Dot1Dtpfdbtable

    Commands for Managing the Switch enable snmp dot1dTpFdbTable enable snmp dot1dTpFdbTable Description Enables SNMP GetNext responses for the dot1dTpFdbTable in the BRIDGE-MIB. Syntax Description This command has no arguments or variables. Default Disabled. Usage Guidelines SNMP Get responses are not affected by this command. To view the configuration of the dot1dTpFdb table on the switch, use the command.

  • Page 201: Enable Snmp Traps

    enable snmp traps enable snmp traps enable snmp traps Description Turns on SNMP trap support. Syntax Description This command has no arguments or variables. Default Enabled. Usage Guidelines An authorized trap receiver can be one or more network management stations on your network. The switch sends SNMP traps to all trap receivers.

  • Page 202: Enable Snmp Traps Exceed-Committed-Rate Ports

    Commands for Managing the Switch enable snmp traps exceed-committed-rate ports enable snmp traps exceed-committed-rate ports <portlist> {<Ingress QOS Profile>} Description Enables SNMP traps for the condition when ingress traffic has exceeded the configured committed-rate and is either being dropped, or is in danger of being dropped, on the indicated ports. Syntax Description “3”...
  • Page 203 enable snmp traps exceed-committed-rate ports History This command was first available in ExtremeWare 7.2. Platform Availability This command is available on “3” series I/O modules only. ExtremeWare 7.5 Command Reference Guide...

  • Page 204: Enable Snmp Traps Mac-Security

    Commands for Managing the Switch enable snmp traps mac-security enable snmp traps mac-security Description Enables SNMP mac-security traps for all ports to be sent by the switch. Syntax Description This command has no arguments or variables. Default Disabled. Usage Guidelines This command should be used in conjunction with the configure ports <portlist>...

  • Page 205: Enable Snmp Traps Port-Up-Down

    enable snmp traps port-up-down enable snmp traps port-up-down enable snmp traps {port-up-down ports [all | mgmt | <portlist>]} Description Enables SNMP port up/down traps (also known as link up and link down traps) for the indicated ports. Syntax Description Specifies that link up/down traps should be sent for all ports. This does not include the management port which must be explicitly specified.

  • Page 206: Enable Sntp-Client

    Commands for Managing the Switch enable sntp-client enable sntp-client Description Enables the SNTP client. Syntax Description This command has no arguments or variables. Default N/A. Usage Guidelines SNTP can be used by the switch to update and synchronize its internal clock from a Network Time Protocol (NTP) server.

  • Page 207: Enable System-Watchdog

    enable system-watchdog enable system-watchdog enable system-watchdog Description Enables the system watchdog timer. Syntax Description This command has no arguments or variables. Default Enabled. Usage Guidelines The watchdog timer reboots the switch if the CPU becomes trapped in a processing loop. If the watchdog timer is executed, the switch captures information on the cause of the reboot and posts it to the system log.

  • Page 208: Enable Telnet

    Commands for Managing the Switch enable telnet enable telnet {access-profile [<access_profile> | none]} {port <tcp_port_number>} Description Enables Telnet access to the switch. Syntax Description access profile Specifies an access profile. (6.0, 6.1) none Cancels a previously configured access profile. (6.0, 6.1) port Specifies a TCP port number.
  • Page 209 enable telnet History This command was first available in ExtremeWare 2.0. Support for the , and parameters was introduced in ExtremeWare 6.0. access profile none port This command was added to the Summit “e” series of switches in ExtremeWare 7.1e. Platform Availability This command is available on all platforms.

  • Page 210: Enable Web

    Commands for Managing the Switch enable web enable web {access-profile [<access_profile> | none]} {port <tcp_port_number>} Description Enables ExtremeWare Vista web access to the switch. Syntax Description access profile Specifies an access profile. (6.0, 6.1) none Cancels a previously configured access profile. (6.0, 6.1) port Specifies a TCP port number.

  • Page 211: Exit

    exit exit exit Description Logs out the session of a current user for CLI or Telnet. Syntax Description This command has no arguments or variables. Default N/A. Usage Guidelines Use this command to log out of a CLI or Telnet session. Example The following command logs out the session of a current user for CLI or Telnet: exit...

  • Page 212: Logout

    Commands for Managing the Switch logout logout Description Logs out the session of a current user for CLI or Telnet. Syntax Description This command has no arguments or variables. Default N/A. Usage Guidelines Use this command to log out of a CLI or Telnet session. Example The following command logs out the session of a current user for CLI or Telnet: logout...

  • Page 213: Quit

    quit quit quit Description Logs out the session of a current user for CLI or Telnet. Syntax Description This command has no arguments or variables. Default N/A. Usage Guidelines Use this command to log out of a CLI or Telnet session. Example The following command logs out the session of a current user for CLI or Telnet: quit...

  • Page 214: Show Eapol-Flooding

    Commands for Managing the Switch show eapol-flooding show eapol-flooding Description Displays the current EAPOL flooding state. Syntax Description This command has no arguments or variables. Default Usage Guidelines Per IEEE 802.1D, Summit “e” series switches do not forward EAPOL frames. Also, if network login is enabled, EAPOL flooding cannot be enabled.

  • Page 215: Show Management

    show management show management show management Description Displays the SNMP settings configured on the switch. Syntax Description This command has no arguments or variables. Default N/A. Usage Guidelines: The following show management output is displayed: • Enable/disable state for Telnet, SNMP, and web access •...
  • Page 216 Commands for Managing the Switch CLI idle timeouts: disabled CLI Paging: enabled CLI configuration logging: enabled Telnet access: enabled tcp port: 23 Web access: enabled tcp port: 80 Web access login timeout : 30 secs SSH Access: key invalid, disabled tcp port: 22 UDP Echo Server: disabled udp port: 7 SNMP Access:...
  • Page 217 show management Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 218: Show Odometer

    Commands for Managing the Switch show odometer show odometer Description Displays a counter for each component of a switch that shows how long it has been functioning since it was manufactured. Syntax Description This command has no arguments or variables. Default N/A.
  • Page 219 show odometer Slot 2: WM4T1 Oct-25-2002 Slot 3: FM8V Jan-22-2003 Slot 4: GM4X Jan-22-2003 Upper PS: PSU-A Apr-12-2002 Lower PS: PSU-B History This command was first available in ExtremeWare 6.2.1. This command was added to the Summit “e” series of switches in ExtremeWare 7.2e. Platform Availability This command is available on all platforms.

  • Page 220: Show Session

    Commands for Managing the Switch show session show session Description Displays the currently active Telnet, console, and web sessions communicating with the switch. Syntax Description This command has no arguments or variables. Default N/A. Usage Guidelines command displays the username and IP address of the incoming Telnet session, show session whether a console session is currently active, and the login time.
  • Page 221 show session Support for the Auth command field definition was introduced in ExtremeWare 4.0. Support for the CLI Auth command field definition was introduced in ExtremeWare 6.0. This command was added to the Summit “e” series of switches in ExtremeWare 7.1e. Platform Availability This command is available on all platforms.

  • Page 222: Show Snmpv3 Access

    Commands for Managing the Switch show snmpv3 access show snmpv3 access {hex <hex value>} | <group name>} Description Displays SNMPv3 access rights. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets. group name Specifies the name of the group to display.
  • Page 223 show snmpv3 access Row Status : Active Group Name : initial Context Prefix : Security Model : USM Security Level : Authentication No-Privacy Context Match : Exact Read View : defaultUserView Write View : defaultUserView Notify View : defaultNotifyView Storage Type : Permanent Row Status : Active...
  • Page 224 Commands for Managing the Switch Group Name : v1v2cNotifyGroup Context Prefix : Security Model : snmpv1 Security Level : No-Authentication No-Privacy Context Match : Exact Read View Write View Notify View : defaultNotifyView Storage Type : Permanent Row Status : Active Group Name : v1v2cNotifyGroup Context Prefix :...

  • Page 225: Show Snmpv3 Context

    show snmpv3 context show snmpv3 context show snmpv3 context Description Displays information about the SNMPv3 contexts on the switch. Syntax Description This command has no arguments or variables. Default N/A. Usage Guidelines: This command displays the entries in the View-based Access Control Model (VACM) context table (VACMContextTable).

  • Page 226: Show Snmpv3 Counters

    Commands for Managing the Switch show snmpv3 counters show snmpv3 counters Description Displays SNMPv3 counters. Syntax Description This command has no arguments or variables. Default N/A. Usage Guidelines command displays the following SNMPv3 counters: show snmpv3 counters • snmpUnknownSecurityModels • snmpInvalidMessages •...
  • Page 227 show snmpv3 counters History This command was first available in ExtremeWare 7.1.0. This command was added to the Summit “e” series of switches in ExtremeWare 7.2e. Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 228: Show Snmpv3 Engine-Info

    Commands for Managing the Switch show snmpv3 engine-info show snmpv3 engine-info Description Displays information about the SNMPv3 engine on the switch. Syntax Description This command has no arguments or variables. Default N/A. Usage Guidelines: The following show engine-info output is displayed: •...

  • Page 229: Show Snmpv3 Extreme-Target-Addr-Ext

    show snmpv3 extreme-target-addr-ext show snmpv3 extreme-target-addr-ext show snmpv3 extreme-target-addr-ext {hex <hex value>} <addr name> Description Display information about SNMPv3 target addresses enhanced or standard mode. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets.

  • Page 230: Show Snmpv3 Filter

    Commands for Managing the Switch show snmpv3 filter show snmpv3 filter {{hex <hex value>} <profile name> {{subtree} <object identifier>} Description Display the filters that belong a filter profile. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets.

  • Page 231: Show Snmpv3 Filter-Profile

    show snmpv3 filter-profile show snmpv3 filter-profile show snmpv3 filter-profile {{hex <hex value>} <profile name>} {param {hex <hex value>} <param name>} Description Display the association between parameter names and filter profiles. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets.

  • Page 232: Show Snmpv3 Group

    Commands for Managing the Switch show snmpv3 group show snmpv3 group {hex <hex value> | <group name>} {user {hex <hex value>} | <user name>} Description Displays the user name (security name) and security model association with a group name. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets.
  • Page 233 show snmpv3 group Row Status : Active Group Name : v1v2c_rw Security Name : v1v2c_rw Security Model : snmpv2c Storage Type : Permanent Row Status : Active Group Name : admin Security Name : admin Security Model : USM Storage Type : Permanent Row Status : Active...

  • Page 234: Show Snmpv3 Mib-View

    Commands for Managing the Switch show snmpv3 mib-view show snmpv3 mib-view {{hex <hex value>} | <view name>} {subtree <object identifier>} Description Displays a MIB view. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets.
  • Page 235 show snmpv3 mib-view View Name : defaultUserView MIB Subtree : 1.3.6.1.6.3.18 Mask View Type : Excluded Storage Type : Permanent Row Status : Active View Name : defaultUserView MIB Subtree : 1.3.6.1.6.3.15.1.2.2.1.4 Mask View Type : Excluded Storage Type : Permanent Row Status : Active View Name...

  • Page 236: Show Snmpv3 Notify

    Commands for Managing the Switch show snmpv3 notify show snmpv3 notify {{hex <hex value>} <notify name>} Description Display the notifications that are set. This command displays the snmpNotifyTable. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets.

  • Page 237: Show Snmpv3 Target-Addr

    show snmpv3 target-addr show snmpv3 target-addr show snmpv3 target-addr {{hex <hex value>} | <addr name>} Description Display information about SNMPv3 target addresses. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets. addr name Specifies a string identifier for the target address.

  • Page 238: Show Snmpv3 Target-Params

    Commands for Managing the Switch show snmpv3 target-params show snmpv3 target-params [{{hex <hex value>} | <param name>}] Description Display the information about the options associated with the parameter name. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets.

  • Page 239: Show Snmpv3 User

    show snmpv3 user show snmpv3 user show snmpv3 user {{hex <hex value>} <user name>} Description Displays detailed information about the user. Syntax Description Specifies that the value to follow is to be supplied as a colon separated string of hex octets. user name Specifies the user name to display.
  • Page 240 Commands for Managing the Switch This command was added to the Summit “e” series of switches in ExtremeWare 7.2e. Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 241: Show Sntp-Client

    show sntp-client show sntp-client show sntp-client Description Displays the DNS configuration. Syntax Description This command has no arguments or variables. Default N/A. Usage Guidelines Displays configuration and statistics information of SNTP client. Example The following command displays the DNS configuration: show sntp-client Following is the output from this command: SNTP client is enabled...
  • Page 242 Commands for Managing the Switch This command was added to the Summit “e” series of switches in ExtremeWare 7.1e. Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 243: Show Vlan Dhcp-Address-Allocation

    show vlan dhcp-address-allocation show vlan dhcp-address-allocation show vlan <vlan name> dhcp-address-allocation Description Displays DHCP address allocation information about VLANs. Syntax Description vlan name Specifies a VLAN name. Default Summary information for all VLANs on the device. Usage Guidelines Display the IP address, MAC address, and time assigned to each end device. Example The following command displays DHCP address allocation information about VLAN temp: show vlan temp dhcp-address-allocation...

  • Page 244: Show Vlan Dhcp-Config

    Commands for Managing the Switch show vlan dhcp-config show vlan <vlan-name> dhcp-config Description Displays the DHCP configuration for a specified VLAN. Syntax Description vlan-name Specifies the name of the VLAN for which the DHCP configuration is to be displayed. If no VLAN name is specified, summary configuration information is shown for all VLANs on the device.
  • Page 245 show vlan dhcp-config Platform Availability This command is available on the “i” series platform only. ExtremeWare 7.5 Command Reference Guide...

  • Page 246: Telnet

    Commands for Managing the Switch telnet telnet [<ipaddress> | <hostname>] {<port_number>} Description Allows you to Telnet from the current command-line interface session to another host. Syntax Description ipaddress Specifies the IP address of the host. hostname Specifies the name of the host. (4.x and higher) port_number Specifies a TCP port number.
  • Page 247 telnet History This command was first available in ExtremeWare 2.0. This command was modified in ExtremeWare 4.x to support the hostname port number parameters. This command was added to the Summit “e” series of switches in ExtremeWare 7.1e. Platform Availability This command is available on all platforms.

  • Page 248: Unconfigure Management

    Commands for Managing the Switch unconfigure management unconfigure management Description Restores default values to all SNMP-related entries. Syntax Description This command has no arguments or variables. Default N/A. Usage Guidelines None. Example The following command restores default values to all SNMP-related entries on the switch: unconfigure management History This command was first available in ExtremeWare 2.0.

  • Page 249: Commands For Configuring Slots And Ports On A Switch

    If autonegotiation is set to off, flow control is disabled. When autonegotiation is turned on, flow control is enabled. Load sharing with Extreme Networks switches allows you to increase bandwidth and resilience between switches by using a group of ports to carry traffic in parallel between switches. The sharing algorithm allows the switch to use multiple ports as a single logical port.
  • Page 250 Commands for Configuring Slots and Ports on a Switch Load sharing is most useful in cases where the traffic transmitted from the switch to the load-sharing group is sourced from an equal or greater number of ports on the switch. For example, traffic transmitted to a two-port load-sharing group should originate from a minimum of two other ports on the same switch.

  • Page 251: Clear Slot

    clear slot clear slot clear slot <slot> Description Clears a slot of a previously assigned module type. Syntax Description slot Specifies a modular switch slot number. Default Usage Guidelines All configuration information related to the slot and the ports on the module is erased. If a module is present when you issue this command, the module is reset to default settings.

  • Page 252: Configure Backplane-Ls-Policy

    Commands for Configuring Slots and Ports on a Switch configure backplane-ls-policy configure backplane-ls-policy [address-based | port-based | round-robin] Description Selects a load-sharing policy for the backplane on a BlackDiamond switch. Syntax Description address-based Specifies address-based algorithm. port-based Specifies port-based algorithm. round-robin Specifies round-robin algorithm.

  • Page 253: Configure Ip-Mtu Vlan

    configure ip-mtu vlan configure ip-mtu vlan configure ip-mtu <number> vlan <vlan name> Description Sets the maximum transmission unit (MTU) for the VLAN. Syntax Description IP MTU number Specifies the value. Range is from 1500 to 9194. vlan name Specifies a VLAN name. Default The default IP MTU size is 1500.
  • Page 254 Commands for Configuring Slots and Ports on a Switch Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 255: Configure Jumbo-Frame Size

    configure jumbo-frame size configure jumbo-frame size configure jumbo-frame size <number> Description This command sets the maximum jumbo frame size for the switch chassis. Syntax Description number Specifies a maximum transmission unit (MTU) size for a jumbo frame. Default The default setting is 9216. Usage Guidelines Jumbo frames are used between endstations that support larger frame sizes for more efficient transfers of bulk data.
  • Page 256 Commands for Configuring Slots and Ports on a Switch History This command was first available in ExtremeWare 6.0. This command was added to the Summit “e” series of switches in ExtremeWare 7.2e. Platform Availability This command is available on the “i” series platforms and on the Summit 400-48t. ExtremeWare 7.5 Command Reference Guide...

  • Page 257: Configure Mirroring Add

    configure mirroring add configure mirroring add configure mirroring add [<mac_address> | vlan <vlan name> {ports <port number>} | ports <portnumber> {vlan <vlan name>}] Description Adds a particular mirroring filter definition on the switch. Syntax Description mac_address Specifies a MAC address. (Supported in versions 2.0 - 4x only) vlan name Specifies a VLAN name.
  • Page 258 Commands for Configuring Slots and Ports on a Switch For version 2.0 and 4.0: In addition to the physical port, VLAN, and virtual port, the traffic filter can be defined based on the following criteria: • MAC source address/destination address—All data sent to or received from a particular source or destination MAC address is copied to the monitor port.

  • Page 259: Configure Mirroring Delete

    configure mirroring delete configure mirroring delete configure mirroring delete [<mac_address> | vlan <vlan name> {ports <portnumber>} | ports <portnumber> {vlan <vlan name>}] Description Deletes a particular mirroring filter definition on the switch. Syntax Description mac_address Specifies a MAC address. (Supported in versions 4.0 and 6.0 only) vlan name Specifies a VLAN name.
  • Page 260 Commands for Configuring Slots and Ports on a Switch Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 261: Configure Msm-Failover Link-Action

    configure msm-failover link-action configure msm-failover link-action configure msm-failover link-action [keep-links-up {preserve-state [l2 | l2_l3]} | take-links-down] Description Configures external port response when MSM failover occurs. Syntax Description keep-links-up Configures the external ports to not be reset when MSM failover occurs. NOTE: This option is available only on the “i”...
  • Page 262 Commands for Configuring Slots and Ports on a Switch If you enter , you also need to configure ESRP for hitless failover to preserve the ESRP state. l2_l3 Example The following command prevents external ports from being reset when an MSM failover occurs: configure msm-failover link-action keep-links-up History This command was first available in ExtremeWare 6.2.2.

  • Page 263: Configure Msm-Failover Slave-Config

    configure msm-failover slave-config configure msm-failover slave-config configure msm-failover slave-config [inherited | flash] Description Configures the slave MSM-3 to inherit the software configuration from the master MSM-3. Syntax Description inherited Specifies that the slave MSM-3 inherits the software configuration maintained by the current master MSM-3 (this supports hitless failover).

  • Page 264: Configure Msm-Failover Timeout

    Commands for Configuring Slots and Ports on a Switch configure msm-failover timeout configure msm-failover timeout <time> Description Configures the failover timer. Syntax Description time Specifies the failover time. By default, the failover time is 60 seconds, and the range is 30 to 300 seconds.

  • Page 265: Configure Port Aggregate-Bandwidth Percent

    configure port aggregate-bandwidth percent configure port aggregate-bandwidth percent configure port <portnumber> aggregate-bandwidth percent <bandwidth> Description Controls the egress bandwidth of a particular port by restricting it to the specified percentage. Syntax Description portnumber Specifies a port or slot and port. bandwidth Specifies a percentage number (1-99) of restricted aggregate bandwidth.

  • Page 266: Configure Port Interpacket-Gap

    10 Gigabit Ethernet interfaces drop packets when packets are transmitted using a value of 12. Thus, by increasing the Interpacket Gap, packet transmission is slowed and packet loss can be minimized or prevented. The Interpacket Gap value need not be modified when interconnecting Extreme Networks switches over 10 Gigabit Ethernet links.

  • Page 267: Configure Ports

    configure ports configure ports configure ports [<portlist> vlan <vlan name> | all] [limit-learning <number> | lock-learning | unlimited-learning | unlock-learning] Description Configures virtual ports for limited or locked MAC address learning. Syntax Description portlist Specifies one or more ports or slots and ports. On a modular switch, can be a list of slots and ports.
  • Page 268 Commands for Configuring Slots and Ports on a Switch • EDP traffic Traffic from the permanent MAC and any other non-blackholed MACs will still flow from the virtual port. If you configure a MAC address limit on VLANS that have ESRP enabled, you should add an additional back-to-back link (that has no MAC address limit on these ports) between the ESRP-enabled switches.
  • Page 269 configure ports History This command was first available in ExtremeWare 6.2.1. This command was added to the Summit “e” series of switches in ExtremeWare 7.3e. Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 270: Configure Ports Auto-Polarity

    Commands for Configuring Slots and Ports on a Switch configure ports auto-polarity configure ports [<portlist> | all] auto-polarity [off | on] Description Configures the autopolarity detection feature on the specified Ethernet ports. Syntax Description portlist Specifies one or more ports on the switch. May be in the form 1, 2, 3-5. Specifies all of the ports on the switch.

  • Page 271: Configure Ports Auto Off

    configure ports auto off configure ports auto off configure ports [<portlist> | all | mgmt] auto off {speed [10 | 100 | 1000]} duplex [half | full] Description Manually configures port speed and duplex setting configuration on one or more ports on a switch. Syntax Description portlist Specifies one or more ports or slots and ports.
  • Page 272 Commands for Configuring Slots and Ports on a Switch For version 6.1: • The parameter specifies all ports on the switch. • The parameter specifies 1000 Mbps ports. 1000 Example The following example turns autonegotiation off for port 4 (a Gigabit Ethernet port) on a stand-alone switch: configure ports 4 auto off duplex full The following example turns autonegotiation off for slot 2, port 1 on a modular switch:...

  • Page 273: Configure Ports Auto On

    configure ports auto on configure ports auto on configure ports [<portlist> | mgmt | all] auto on Description Enables autonegotiation for the particular port type. Syntax Description portlist Specifies one or more ports or slots and ports. On a modular switch, can be a list of slots and ports. On a stand-alone switch, can be one or more port numbers.
  • Page 274 Commands for Configuring Slots and Ports on a Switch History This command was first available in ExtremeWare 2.0. This command was modified in ExtremeWare 6.1 to support the parameter. This command was modified in ExtremeWare 4.0 to support modular switches. This command was added to the Summit “e”...

  • Page 275: Configure Ports Display-String

    configure ports display-string configure ports display-string configure ports [<portlist> | mgmt] display-string <alphanumeric string> Description Configures a user-defined string for a port or group of ports. Syntax Description portlist Specifies one or more ports or slots and ports. On a modular switch, can be a list of slots and ports.
  • Page 276 Commands for Configuring Slots and Ports on a Switch Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 277: Configure Ports Link-Detection-Level

    configure ports link-detection-level configure ports link-detection-level configure ports <portlist> link-detection-level <link-detection-level> Description Configures the link detection level. Syntax Description portlist Specifies one or more primary ports or slots and ports. On a modular switch, can be a list of slots and ports. On a stand-alone switch, can be one or more port numbers. May be in the form 1, 2, 3-5, 2:*, 2:5, 2:6-2:8.

  • Page 278: Configure Ports Preferred-Medium

    Commands for Configuring Slots and Ports on a Switch configure ports preferred-medium configure ports <nnn> preferred-medium {copper} | {fiber} |[force] Description Configures the primary uplink port to use a preferred medium. Syntax Description Specifies the port number. Valid port numbers are 1X to 4X for fiber and ports 1 to 4 for copper. copper Specifies that the switch should always use the 10/100/1000 connection whenever a link is established, regardless whether a fiber link is also present.
  • Page 279 configure ports preferred-medium Platform Availability This command is only available on Summit 300-24 and Summit 400-48t switches. ExtremeWare 7.5 Command Reference Guide...

  • Page 280: Configure Ports Redundant

    Commands for Configuring Slots and Ports on a Switch configure ports redundant configure ports [<portlist> | <portid>] redundant [<portlist> | <portid>] Description Configures a software-controlled redundant port. Syntax Description portlist Specifies one or more primary ports or slots and ports. On a modular switch, can be a list of slots and ports.
  • Page 281 configure ports redundant • Software redundant ports are not supported on 1000BASE-T ports. Software redundant port only cover failures where both the TX and RX paths fail. If a single strand of fiber is pulled, the software redundant port cannot correctly recover from the failure. Example The following command configures a software-controlled redundant port on a stand-alone switch: configure ports 3 redundant 4...

  • Page 282: Configure Ports Vdsl

    Commands for Configuring Slots and Ports on a Switch configure ports vdsl configure ports <portlist> vdsl [5meg | 10meg | etsi] Description Configures VDSL ports. Syntax Description portlist Specifies one or more slots and ports. Can specify a list of slots and ports, and may be in the form 2:*, 2:5, 2:6-2:8.

  • Page 283: Configure Sharing Address-Based

    configure sharing address-based configure sharing address-based For “i” series switches: configure sharing address-based [L2 | L2_L3 | L2_L3_L4] For ”e” series switches: configure sharing address-based [ip-dest| ip-source| ip-source-dest |mac-dest | mac-source | mac-source-dest] Description Configures the part of the packet examined by the switch when selecting the egress port for transmitting load-sharing data.
  • Page 284 Commands for Configuring Slots and Ports on a Switch • IPX packets—Uses the source and destination MAC address and IPX identifiers. • All other packets—Uses the source and destination MAC address. To verify your configuration, use the command. The show sharing show sharing address-based address-based output displays the addressed-based configurations on the switch.

  • Page 285: Configure Slot

    configure slot configure slot configure slot <slot> module <module name> Description Configures a slot for a particular I/O module in a modular switch. Syntax Description slot Specifies the slot number. module name Specifies the type of module for which the slot should be configured. The list of modules you can enter will vary depending on the type of switch and version of ExtremeWare you are running.
  • Page 286 Commands for Configuring Slots and Ports on a Switch wm4t1—Specifies a T1 WAN module. (6.1 or later) wm4e1—Specifies an E1 WAN module. wm1t3—Specifies a T3 WAN module. Default If a slot has not been configured for a particular type of I/O module, then any type of module is accepted in that slot, and a default port and VLAN configuration is automatically generated.
  • Page 287 configure slot Platform Availability This command is available on modular switches only. ExtremeWare 7.5 Command Reference Guide...

  • Page 288: Disable Card-Scan

    Commands for Configuring Slots and Ports on a Switch disable card-scan disable card-scan Description Disables the card-scan feature on MSM slots in the BlackDiamond switch. Syntax Description This command has no arguments or variables. Default By default, card-scan is enabled. Usage Guidelines On certain BlackDiamond switches running earlier releases of ExtremeWare, hot insertion of a slave MSM causes one or more of the following conditions:...

  • Page 289: Disable Edp Ports

    Numerical Ranges” or “Stand-alone Switch Numerical Ranges” in Chapter 1. You can use the command to disable EDP on one or more ports when you no disable edp ports longer need to locate neighbor Extreme Networks switches. For version 6.1: • The parameter specifies all ports on the switch.
  • Page 290 Commands for Configuring Slots and Ports on a Switch History This command was first available in ExtremeWare 2.0. This command was modified in ExtremeWare 4.0 to support modular switches. This command was modified in ExtremeWare 6.1 to support the parameter. This command was added to the Summit “e”...

  • Page 291: Disable Flooding Ports

    disable flooding ports disable flooding ports disable flooding ports <portlist> Description Disables packet flooding on one or more ports. Syntax Description portlist Specifies one or more ports or slots and ports. On a modular switch, can be a list of slots and ports. On a stand-alone switch, can be one or more port numbers.

  • Page 292: Disable Jumbo-Frame Ports

    Commands for Configuring Slots and Ports on a Switch disable jumbo-frame ports disable jumbo-frame ports [<portlist> | all] Description Disables jumbo frame support on a port. For PoS modules. This command applies to PoS ports when disabling jumbo-frame support changes the negotiated maximum receive unit (MRU) size.

  • Page 293: Disable Lbdetect Port

    disable lbdetect port disable lbdetect port disable lbdetect port <portlist> Description Disables the detection of loops between ports. Syntax Description portlist Specifies one or more ports or slots and ports to be grouped to the master port. On a modular switch, can be a list of slots and ports.

  • Page 294: Disable Learning Ports

    Commands for Configuring Slots and Ports on a Switch disable learning ports disable learning ports <portlist> Description Disables MAC address learning on one or more ports for security purposes. Syntax Description portlist Specifies one or more ports or slots and ports. On a modular switch, can be a list of slots and ports. On a stand-alone switch, can be one or more port numbers.

  • Page 295: Disable Mirroring

    disable mirroring disable mirroring disable mirroring Description Disables port-mirroring. Syntax Description This command has no arguments or variables. Default Enabled Usage Guidelines Use the command to stop configured copied traffic associated with one or more disable mirroring ports. Example The following command disables port-mirroring: disable mirroring History This command was first available in ExtremeWare 2.0.

  • Page 296: Disable Ports

    Commands for Configuring Slots and Ports on a Switch disable ports disable ports [<portlist> | all |{vlan} <vlan name>] Description Disables one or more ports on the switch. For PoS modules. Brings down the PPP link on the specified port and changes the port status LED to blinking green.
  • Page 297 disable ports The command was modified in ExtremeWare 7.3 and ExtremeWare 7.3e to support the option. vlan Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 298: Disable Sharing

    Commands for Configuring Slots and Ports on a Switch disable sharing disable sharing [<port>] Description Disables a load-sharing group of ports. Syntax Description port Specifies the master port of a load-sharing group. On a modular switch, is a combination of the slot and port number, in the format <slot>:<port>.

  • Page 299: Disable Slot

    disable slot disable slot disable slot [all | msm-a | msm-b | <slot number>] Description Disables one or all slots on a BlackDiamond or Alpine switch, and leaves the module in a power-down state. Syntax Description Species that all slots in the device should be disabled. msm-a Specifies that MSM-A should be disabled.

  • Page 300: Disable Smartredundancy

    For a detailed explanation of port specification, see “Modular Switch Numerical Ranges” or “Stand-alone Switch Numerical Ranges” in Chapter 1. Use with Extreme Networks switches that support privacy and backup uplinks. When smartredundancy is disabled, the switch changes the active link only when the current active link becomes inoperable.

  • Page 301: Enable Card-Scan

    enable card-scan enable card-scan enable card-scan Description Enables the card-scan function on MSM slots in the BlackDiamond switch. Syntax Description This command has no arguments or variables. Default By default, card-scan is enabled. Usage Guidelines On certain BlackDiamond switches running earlier releases of ExtremeWare, hot insertion of a slave MSM causes one or more of the following conditions: •...

  • Page 302: Enable Edp Ports

    EDP is useful when Extreme Networks switches are attached to a port. The EDP is used to locate neighbor Extreme Networks switches and exchange information about switch configuration. When running on a normal switch port, EDP is used to by the switches to exchange topology information with each other.
  • Page 303 enable edp ports History This command was first available in ExtremeWare 2.0. This command was modified in ExtremeWare 4.0 to support modular switches. This command was added to the Summit “e” series of switches in ExtremeWare 7.1e Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 304: Enable Flooding Ports

    Commands for Configuring Slots and Ports on a Switch enable flooding ports enable flooding ports <portlist> Description Enables packet flooding on one or more ports. Syntax Description portlist Specifies one or more ports or slots and ports. On a modular switch, can be a list of slots and ports. On a stand-alone switch, can be one or more port numbers.

  • Page 305: Enable Jumbo-Frame Ports

    enable jumbo-frame ports enable jumbo-frame ports enable jumbo-frame ports [<portlist> | all] Description Enables support on the physical ports that will carry jumbo frames. For PoS modules. Enables jumbo-frame support to specific PoS ports when jumbo-frame support changes the negotiated maximum receive unit (MRU) size. Syntax Description portlist Specifies one or more ports or slots and ports.

  • Page 306: Enable Lbdetect Port

    Commands for Configuring Slots and Ports on a Switch enable lbdetect port enable lbdetect port <portlist> [retry-timeout<seconds>] Description Enables the system to detect loops between ports. If a port is looped, it disables the port. Every n seconds, it re-enables the port and tries again, unless “none” is specified Syntax Description portlist Specifies one or more ports or slots and ports to be grouped to the master port.

  • Page 307: Enable Learning Ports

    enable learning ports enable learning ports enable learning ports <portlist> Description Enables MAC address learning on one or more ports. Syntax Description portlist Specifies one or more ports or slots and ports. On a modular switch, can be a list of slots and ports. On a stand-alone switch, can be one or more port numbers.

  • Page 308: Enable Mirroring To Port

    Commands for Configuring Slots and Ports on a Switch enable mirroring to port enable mirroring to port [<port>] [tagged | untagged] Description Dedicates a port on the switch to be the mirror output port. Syntax Description port Specifies the port to be the mirror output port. tagged Configures the port as tagged.
  • Page 309 enable mirroring to port Example The following example selects port 3 as a tagged mirror port on a stand-alone switch: enable mirroring to port 3 tagged The following example selects slot 1, port 3 as the mirror port on a modular switch: enable mirroring to port 1:3 History This command was first available in ExtremeWare 2.0.

  • Page 310: Enable Ports

    Commands for Configuring Slots and Ports on a Switch enable ports enable ports [<portlist> | all | {vlan} <vlan name>] Description Enables a port. For PoS modules. Enables the PPP link on the specified port, and changes the port status LED to solid green (if no other problems exist).
  • Page 311 enable ports Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 312: Enable Sharing Grouping

    Load sharing must be enabled on both ends of the link, or a network loop will result. While LACP is based on industry standard, this feature is supported between Extreme Networks switches only. However, it may be compatible with third-party “trunking” or sharing algorithms. Check with an Extreme Networks technical representative for more information.
  • Page 313 This feature is supported between Extreme Networks switches only, but may be compatible with third-party trunking or link-aggregation algorithms. Check with an Extreme Networks technical representative for more information. Load-sharing algorithms allow you to select the distribution technique used by the load-sharing group to determine the output port selection.
  • Page 314 Commands for Configuring Slots and Ports on a Switch • Round-robin—When the switch receives a stream of packets, it forwards one packet out of each physical port in the load-sharing group using a round-robin scheme. The round-robin algorithm is available only on “i” series switches. Using the round-robin algorithm, packet sequencing between clients is not guaranteed.

  • Page 315: Enable Slot

    enable slot enable slot enable slot [all | msm-a | msm-b | <slot number>] Description Enables one or all slots on a BlackDiamond or Alpine switch. Syntax Description Species that all slots in the device should be enables. msm-a Specifies that MSM-A should be enabled. msm-b Specifies that MSM-B should be enabled.

  • Page 316: Enable Smartredundancy

    Commands for Configuring Slots and Ports on a Switch enable smartredundancy enable smartredundancy <portlist> Description Enables the Smart Redundancy feature on the redundant Gigabit Ethernet port. Syntax Description portlist Specifies one or more ports or slots and ports. On a modular switch, can be a list of slots and ports. On a stand-alone switch, can be one or more port numbers.

  • Page 317: Restart Ports

    restart ports restart ports restart ports [<portlist> Description Resets autonegotiation for one or more ports by resetting the physical link. For PoS modules. Causes the PPP link to be renegotiated. Syntax Description portlist Specifies one or more ports or slots and ports. On a modular switch, can be a list of slots and ports. On a stand-alone switch, can be one or more port numbers.

  • Page 318: Run Msm-Failover

    Commands for Configuring Slots and Ports on a Switch run msm-failover run msm-failover Description Causes a user-specified MSM failover. Syntax Description This command has no arguments or variables. Default Usage Guidelines None Example The following command causes a user-specified MSM failover: run msm-failover History This command was first available in ExtremeWare 6.2.2.

  • Page 319: Show Edp

    This is most effective show edp with Extreme Networks switches. Example The following command displays the connectivity and configuration of neighboring Extreme Networks switches: show edp Following is the output from this command:...
  • Page 320 Commands for Configuring Slots and Ports on a Switch History This command was first available in ExtremeWare 2.0. This command was modified in ExtremeWare 4.0 to support modular switches. This command was added to the Summit “e” series of switches in ExtremeWare 7.1e. Platform Availability This command is available on all platforms.

  • Page 321: Show Mirroring

    show mirroring show mirroring show mirroring Description Displays the port-mirroring configuration on the switch. Syntax Description This command has no arguments or variables. Default Usage Guidelines You must configure mirroring on the switch to display mirroring statistics. Use the show mirroring command to configure mirroring.

  • Page 322: Show Msm-Failover

    — ready—The subsystem has received its state download. In the ready state, it may receive updates to its internal states. — failed—The subsystem encountered a failure. To clear the failure, reboot the slave MSM. — unknown—If this state is displayed, contact Extreme Networks ® Technical Support.
  • Page 323 show msm-failover After a reboot or insertion of a slave MSM-3, use this command to ensure that the slave is ready before initiating a hitless failover. History This command was first available in ExtremeWare 7.1.1. Platform Availability This command is available on the BlackDiamond switch only. ExtremeWare 7.5 Command Reference Guide...

  • Page 324: Show Ports Vlan Stats

    Commands for Configuring Slots and Ports on a Switch show ports vlan stats show ports <portlist> | vlan <vlan_name> vlan stats Description Displays port VLAN statistics. Syntax Description portlist Specifies one or more ports or slots and ports. Can be one or more port numbers.

  • Page 325: Show Ports Collisions

    show ports collisions show ports collisions show ports {mgmt | <portlist>} collisions Description Displays real-time collision statistics. Syntax Description mgmt Specifies the management port. Supported only for switches that provide a management port. portlist Specifies one or more ports or slots and ports. On a modular switch, can be a list of slots and ports. On a stand-alone switch, can be one or more port numbers.
  • Page 326 Commands for Configuring Slots and Ports on a Switch ============================================================================== Link Status: A-Active R-Ready D-Disabled NP-Not Present LB-Loopback 0->Clear Counters U->page up D->page down ESC->exit History This command was first available in ExtremeWare 2.0. This command was modified in ExtremeWare 4.0 to support modular switches. This command was added to the Summit “e”...

  • Page 327: Show Ports Configuration

    show ports configuration show ports configuration show ports {mgmt | <portlist>| vlan <vlan name>} configuration Description Displays port configuration statistics. Syntax Description mgmt Specifies the management port. Supported only for switches that provide a management port. portlist Specifies one or more ports or slots and ports. On a modular switch, can be a list of slots and ports. On a stand-alone switch, can be one or more port numbers.
  • Page 328 Commands for Configuring Slots and Ports on a Switch Following is the output from this command: Port Configuration Monitor Thu Oct 24 16:22:08 2002 Port Port Link Auto Speed Duplex Flow Ld Share Media State Status Neg Cfg Actual Cfg Actual Ctrl Master Pri ENABLED R...

  • Page 329: Show Ports Info

    show ports info show ports info show ports {mgmt | <portlist>| vlan <vlan name>} info {detail} Description Displays detailed system-related information. For PoS modules. Displays port information that includes new DiffServ and RED configuration parameters. “3” series module. If you specify the keyword, the output displays the flow control state detail and the ingress QoS profile, ingress IPTOS replacement, and egress rate limiting configurations.
  • Page 330 Commands for Configuring Slots and Ports on a Switch — Flooding — QoS profiles If you do not specify a port number or range of ports, detailed system-related information is displayed for all ports. The data is displayed in a table format. On a modular switch, can be a list of slots and ports.
  • Page 331 show ports info (D) Port Disabled, (dy) Dynamic Load Sharing (e) Extreme Discovery Protocol Enabled, (E) Port Enabled (f) Flooding Enabled, (g) Egress TOS Enabled, (G) SLB GoGo Mode (h) Hardware Redundant Phy, (j) Jumbo Frame Enabled (l) Load Sharing Enabled, (m) MAC Learning Enabled (n) Ingress TOS Enabled, (o) Dot1p Vlan Priority Replacement Enabled (p) Load Sharing Algorithm port-based, (P) Software Primary Port (q) Background QOS Monitoring Enabled...
  • Page 332 Commands for Configuring Slots and Ports on a Switch 16->QP3 17->QP3 18->QP3 19->QP3 20->QP3 21->QP3 22->QP3 23->QP3 24->QP4 25->QP4 26->QP4 27->QP4 28->QP4 29->QP4 30->QP4 31->QP4 32->QP5 33->QP5 34->QP5 35->QP5 36->QP5 37->QP5 38->QP5 39->QP5 40->QP6 41->QP6 42->QP6 43->QP6 44->QP6 45->QP6 46->QP6 47->QP6 48->QP7 49->QP7 50->QP7 51->QP7 52->QP7 53->QP7 54->QP7 55->QP7 56->QP8 57->QP8 58->QP8 59->QP8 60->QP8 61->QP8 62->QP8 63->QP8 Egress IPTOS:...

  • Page 333: Show Ports Packet

    show ports packet show ports packet show ports {mgmt | <portlist>| vlan <vlan name>} packet Description Displays a histogram of packet statistics. Syntax Description mgmt Specifies the management port Supported only for switches that provide a management port, such as the Summit 400. portlist Specifies one or more ports or slots and ports.
  • Page 334 Commands for Configuring Slots and Ports on a Switch =====Link Status: A-Active R-Ready D-Disabled NP-Not Present LB-Loopback 0->Clear Counters U->page up D->page down ESC->exit The following command displays packet statistics for slot 1, ports 1 through 8, slot 2, ports 1 through 8, and slot 3, port 1 on a modular switch: show ports 1:1-1:8, 2:1-2:8, 3:1 packet Following is the output from this command:...

  • Page 335: Show Ports Redundant

    show ports redundant show ports redundant show ports redundant Description Displays detailed information about redundant ports. Syntax Description This command does not have any parameters or variables. Default Usage Guidelines An asterisk appears when an individual link is active and an exclamation point when the link is disabled.

  • Page 336: Show Ports Sharing

    Commands for Configuring Slots and Ports on a Switch show ports sharing show ports <portlist> sharing Description Displays port loadsharing groups. Syntax Description portlist Specifies one or more ports or slots and ports. On a modular switch, can be a list of slots and ports. On a stand-alone switch, can be one or more port numbers.
  • Page 337 show ports sharing Ld Share Type: (a) address based, (dy) dynamic The following command displays the port loadsharing group configured for port 5:4; the current master has shifted to port 7:4 since both ports 5:4 and 5:5 of the group are not active links: show ports 5:4 sharing The following is the output from this command: * admin:3 # sh port 5:4 sharing...

  • Page 338: Show Ports Utilization

    Commands for Configuring Slots and Ports on a Switch show ports utilization show ports {mgmt | <portlist>| vlan <vlan name>} utilization Description Displays real-time port utilization information. Syntax Description mgmt Specifies the management port. Supported only for switches that provide a management port, such as the Summit 400.
  • Page 339 show ports utilization The following examples show the output from the show ports utilization command for all ports on the switch. The three displays show the information presented when you use the spacebar to toggle through the display types. The first display shows utilization in terms of packets: Link Utilization Averages Wed Jan 23 21:29:45 2004 Port...
  • Page 340 Commands for Configuring Slots and Ports on a Switch spacebar->toggle screen U->page up D->page down ESC->exit History This command was first available in ExtremeWare 2.0. This command was modified in ExtremeWare 4.0 to support modular switches. This command was added to the Summit “e” series of switches in ExtremeWare 7.1e. Platform Availability This command is available on all platforms.

  • Page 341: Show Ports Vlan Info

    show ports vlan info show ports vlan info show ports <portlist> | vlan <vlan_name> vlan info Description Displays port VLAN information. Syntax Description portlist Specifies one or more ports or slots and ports. Can be one or more port numbers. May be in the form 1, 2, 3-5, 1:*, 1:5, 1:6-1:8.
  • Page 342 Commands for Configuring Slots and Ports on a Switch Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 343: Show Sharing Address-Based

    show sharing address-based show sharing address-based show sharing address-based Description Displays the address-based load sharing configuration. Syntax Description This command has no arguments or variables. Default Usage Guidelines This feature is available using the address-based load-sharing algorithm only. The address-based load-sharing algorithm uses addressing information to determine which physical port in the load-sharing group to use for forwarding traffic out of the switch.

  • Page 344: Show Slot

    Commands for Configuring Slots and Ports on a Switch show slot show slot <slot number> Description Displays slot-specific information. For ARM, ATM, MPLS, PoS, and WAN modules. Displays information that includes data about the software images loaded on the module, as well as status information on the module’s processors. For stacked switches.
  • Page 345 show slot Field Description Secondary ExtremeWare Version Stacked Switches only: ExtremeWare version of the secondary software image. Image Selected Stacked Switches only: The image selected on the switch. Image Booted Stacked Switches only: The running image of the switch. Configuration Selected Stacked Switches only: The configuration selected for the switch.
  • Page 346 Commands for Configuring Slots and Ports on a Switch When the GPP subsystem completes its initialization cycle and the subsystem state is OPERATIONAL, use the command to check the results of the show diagnostics {<slot>} module power-on self test (POST). If the STATUS LED on the ARM, ATM, MPLS or PoS module turns amber and blinks, use the show command to display the slot status information.
  • Page 347 show slot HW Module Type: G8Xi Configured Type: Not configured Gigabit ports available: Link Active: Link Down: GBIC missing: 02 03 04 05 06 07 08 Slot 3 information: State: Operational Serial number: 701020-11-0032F51006 HW Module Type: G12SXi Configured Type: Not configured Gigabit ports available: Link Active:...
  • Page 348 Commands for Configuring Slots and Ports on a Switch 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 Slot 6 information: State:...
  • Page 349 show slot • • • Slot 8 information: State: Operational Serial number: HW Module Type: S400-24P Slave: 00:04:96:1F:A7:3F Primary EW Ver: 7.4e.0.28 [non-ssh] Secondary EW Ver: 7.4e.0.10 branch-McastExtn_v74e0b10-r2 [non-ssh] Image Selected: Primary Image Booted: Primary Config Selected: Primary Config Booted: Primary Primary Config: Empty...
  • Page 350 Commands for Configuring Slots and Ports on a Switch As the module progresses through its initialization, the command displays the show slot <slot> general purpose processor (GPP) subsystem change state to OPERATIONAL, and then each of the network processors will change state to OPERATIONAL. When the GPP subsystem completes its initialization cycle and the subsystem state is OPERATIONAL, use the command to check the results of the...
  • Page 351 show slot Gigabit ports available: Link Active: Link Down: 01 02 03 04 05 06 07 08 09 10 11 12 Slot 4 information: State: Operational Network Processor 1 : Operational Network Processor 2 : Operational General Purpose Proc: Operational Serial number: 701039-04-0128F07843 HW Module Type:...
  • Page 352 Commands for Configuring Slots and Ports on a Switch HW Module Type: Empty Configured Type: Not configured Slot 8 information: State: Empty HW Module Type: Empty Configured Type: Not configured History This command was first available in ExtremeWare 4.0. This command was modified in ExtremeWare 6.1 to support PoS modules. This command was modified in ExtremeWare 7.0.0 to support WAN modules.

  • Page 353: Unconfigure Msm-Failover

    unconfigure msm-failover unconfigure msm-failover unconfigure msm-failover Description Disables hitless failover. Syntax Description This command has no arguments or variables. Default Usage Guidelines The following occurs after you execute this command: • The external ports are reset when an MSM failover occurs •...

  • Page 354: Unconfigure Port Aggregate-Bandwidth

    Commands for Configuring Slots and Ports on a Switch unconfigure port aggregate-bandwidth unconfigure port <portnumber> aggregate-bandwidth Description Restores the egress bandwidth of a particular port to 100%. Syntax Description portnumber Specifies a port or slot and port. Default None Usage Guidelines None Example The following command restores the egress bandwidth of port 3 on slot 1 to 100%.

  • Page 355: Unconfigure Ports Display String

    unconfigure ports display string unconfigure ports display string unconfigure ports <portlist> display-string Description Clears the user-defined display string from one or more ports. Syntax Description portlist Specifies one or more ports or slots and ports. On a modular switch, can be a list of slots and ports. On a stand-alone switch, can be one or more port numbers.

  • Page 356: Unconfigure Ports Redundant

    Commands for Configuring Slots and Ports on a Switch unconfigure ports redundant unconfigure ports [<portlist> | <port id>] redundant Description Clears a previously configured software-controlled redundant port. Syntax Description portlist Specifies one or more ports or slots and ports. On a modular switch, can be a list of slots and ports. On a stand-alone switch, can be one or more port numbers.

  • Page 357: Unconfigure Slot

    unconfigure slot unconfigure slot unconfigure slot <slot number> Description Clears a slot of a previously assigned module type. Syntax Description slot number Specifies a slot on a modular switch. Default Usage Guidelines None Example The following command clears slot 4 of a previously assigned module type: unconfigure slots 4 History This command was first available in ExtremeWare 4.0.
  • Page 358 Commands for Configuring Slots and Ports on a Switch ExtremeWare 7.5 Command Reference Guide...

  • Page 359: Vlan Commands

    VLAN Commands This chapter describes the following commands: • Commands for creating and deleting VLANs and performing basic VLAN configuration • Commands for defining protocol filters for use with VLANs • Commands for enabling or disabling the use of Generic VLAN Registration Protocol (GVRP) information on a switch and its ports VLANs can be created according to the following criteria: •...

  • Page 360: Configure Dot1Q Ethertype

    Use this command if you need to communicate with a switch that supports 802.1Q, but uses an Ethertype value other than 8100. This feature is useful for VMAN tunneling. Extreme Networks recommends the use of IEEE registered Ethertype 0x88a8 for deploying vMANs.

  • Page 361: Configure Gvrp Port

    configure gvrp port configure gvrp port configure gvrp {listen | send | both | none} port <portlist> Description Configures the sending and receiving of Generic VLAN Registration Protocol (GVRP) information on a port. NOTE This command is available only on “i” series switches running ExtremeWare version 6.0 or earlier. Syntax Description listen Enables the receipt of GVRP packets on the specified port(s).
  • Page 362 VLAN Commands History This command was first available in ExtremeWare 2.0. This command exists but is not supported in ExtremeWare version 6.1 and later. Platform Availability This command is available only on the “i” series platforms running ExtremeWare version 6.0 or earlier. ExtremeWare 7.5 Command Reference Guide...

  • Page 363: Configure Mac-Vlan Add Mac-Address

    configure mac-vlan add mac-address configure mac-vlan add mac-address configure mac-vlan add mac-address [any | <mac_address>] mac-group [any | <group_number>] vlan <vlan name> Description Adds a MAC address as a potential member of a MAC-based VLAN. Syntax Description mac_address The MAC address to be added to the specified VLAN. Specified in the form nn:nn:nn:nn:nn:nn.
  • Page 364 VLAN Commands The following command sets up the end-station 00:00:00:00:00:02 to participate in VLAN engineering through the ports in group 10 (ports 11 or 12) or through ports 16 or 17 (enabled for any mac-group): configure mac-vlan add mac-address 00:00:00:00:00:02 mac-group 10 vlan engineering History This command was first available in ExtremeWare 6.0.

  • Page 365: Configure Mac-Vlan Delete

    configure mac-vlan delete configure mac-vlan delete configure mac-vlan delete [all | mac-address [<mac_address> | any]] Description Removes a MAC address from any MAC-based VLANs with which it was associated. Syntax Description Indicates that all MAC addresses should be removed from all VLANs. mac_address The MAC address to be removed.

  • Page 366: Configure Ports Monitor Vlan

    VLAN Commands configure ports monitor vlan configure ports <portlist> monitor vlan <vlan name> Description Configures VLAN statistic monitoring on a per-port basis. NOTE This command is available only on the “i” series switches. Syntax Description portlist Specifies one or more ports. May be in the form 1, 2, 3-5, 2:5, 2:6-2:8. vlan name Specifies a VLAN name.

  • Page 367: Configure Protocol Add

    configure protocol add configure protocol add configure protocol <protocol_name> add <protocol_type> <hex_value> {<protocol_type> <hex_value>} ... Description Configures a user-defined protocol filter. NOTE This command is available only on the “i” series switches and the Summit 400-48t. Syntax Description protocol_name Specifies a protocol filter name. protocol_type Specifies a protocol type.
  • Page 368 VLAN Commands Platform Availability This command is available on the “i” series platforms and the Summit 400-48t. ExtremeWare 7.5 Command Reference Guide...

  • Page 369: Configure Protocol Delete

    configure protocol delete configure protocol delete configure protocol <protocol_name> delete <protocol_type> <hex_value> {<protocol_type> <hex_value>} ... Description Deletes the specified protocol type from a protocol filter. Syntax Description protocol_name Specifies a protocol filter name. protocol_type Specifies a protocol type. Supported protocol types include: •...

  • Page 370: Configure Vlan Add Member-Vlan

    VLAN Commands configure vlan add member-vlan configure vlan <translation vlan name> add member-vlan <vlan name> Description Adds a member VLAN to a translation VLAN. NOTE This command is available only on the “i” series switches. Syntax Description translation vlan name Specifies a translation VLAN.

  • Page 371: Configure Vlan Add Ports

    configure vlan add ports configure vlan add ports For “i” series switches: configure vlan <vlan name> add ports <portlist> {tagged | untagged} {nobroadcast} {soft-rate-limit} For “e” series switches: configure vlan <vlan name> add ports <portlist> {tagged | untagged} Description Adds one or more ports in a VLAN. Syntax Description vlan name Specifies a VLAN name.
  • Page 372 VLAN Commands History This command was first available in ExtremeWare 1.0. This command was added to the Summit “e” series of switches in ExtremeWare 7.1e. This command was modified in ExtremeWare 7.2e to support rate limiting with the soft-rate-limit keyword. Platform Availability This command is available on all platforms.

  • Page 373: Configure Vlan Add Ports Loopback-Vid

    configure vlan add ports loopback-vid configure vlan add ports loopback-vid configure vlan <vlan name> add ports <portlist> loopback-vid <vlan-id> Description Adds a loopback port to a VLAN. NOTE This command is available only on the “i” series switches. Syntax Description vlan name Specifies a VLAN name.
  • Page 374 VLAN Commands History This command was first available in ExtremeWare 6.0. Platform Availability This command is available only on the “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 375: Configure Vlan Add Secondary-Ip

    configure vlan add secondary-ip configure vlan add secondary-ip configure vlan <vlan-name> add secondary-ip <sec-ip-address> {<sec-ip-mask> | <mask-length>} Description Configures the secondary IP address for the selected VLAN. NOTE This command is available only on the “i” series switches. Syntax Description vlan-name Specifies the name of the VLAN to be configured.
  • Page 376 VLAN Commands History This command was enhanced for multinetting and made available in ExtremeWare 7.3.0. In earlier releases of ExtremeWare the secondary IP addresses must fall in the same subnet as the primary IP address. With ExtremeWare 7.3.0, secondary IP addresses specify local subnets in the switch and must be unique.

  • Page 377: Configure Vlan Delete Member-Vlan

    configure vlan delete member-vlan configure vlan delete member-vlan configure vlan <translation vlan name> delete member-vlan [<vlan name> | all] Description Deletes a member VLAN from a translation VLAN. NOTE This command is available only on the “i” series switches. Syntax Description translation vlan name Specifies a translation VLAN.

  • Page 378: Configure Vlan Delete Port

    VLAN Commands configure vlan delete port configure vlan <vlan name> delete port [all | <portlist>] Description Deletes one or more ports in a VLAN. Syntax Description vlan name Specifies a VLAN name. portlist A list of ports or slots and ports. May be in the form 1, 2, 3-5, 2:5, 2:6-2:8. Default Usage Guidelines None...

  • Page 379: Configure Vlan Delete Secondary-Ip

    configure vlan delete secondary-ip configure vlan delete secondary-ip configure vlan <vlan-name> delete secondary-ip {<sec-ip-address> | all} Description Deletes a secondary IP address from the specified VLAN. NOTE This command is available only on the “i” series switches. Syntax Description vlan-name Specifies the name of the VLAN to be configured.

  • Page 380: Configure Vlan Ipaddress

    VLAN Commands configure vlan ipaddress configure vlan <vlan name> ipaddress <ipaddress> {<netmask> | <mask length> Description Assigns an IP address and an optional subnet mask to the VLAN. Syntax Description vlan name Specifies a VLAN name. ipaddress Specifies an IP address. netmask Specifies a subnet mask in dotted-quad notation (for example, 255.255.255.0).

  • Page 381: Configure Vlan Name

    configure vlan name configure vlan name configure vlan <old_name> name <new_name> Description Renames a previously configured VLAN. Syntax Description old_name Specifies the current (old) VLAN name. new_name Specifies a new name for the VLAN. Default Usage Guidelines You cannot change the name of the default VLAN Default. Example The following command renames VLAN vlan1 to engineering: configure vlan vlan1 name engineering...

  • Page 382: Configure Vlan Protocol

    VLAN Commands configure vlan protocol configure vlan <vlan name> protocol [<protocol_name> | any] Description Configures a VLAN to use a specific protocol filter. Syntax Description vlan name Specifies a VLAN name. protocol_name Specifies a protocol filter name. This can be the name of a predefined protocol filter or one you have defined.

  • Page 383: Configure Vlan Tag

    configure vlan tag configure vlan tag configure vlan <vlan name> tag <vlan tag> Description Assigns a unique 802.1Q tag to the VLAN. Syntax Description vlan name Specifies a VLAN name. vlan tag Specifies a value to use as an 802.1Q tag. The valid range is from 2 to 4,095. Default The default VLAN uses an 802.1Q tag (and an internal VLANid) of 1.

  • Page 384: Create Protocol

    VLAN Commands create protocol create protocol <protocol_name> Description Creates a user-defined protocol filter. NOTE This command is available only on the “i” series switches and the Summit 400-48t. Syntax Description protocol_name Specifies a protocol filter name. The protocol filter name can have a maximum of 31 characters.

  • Page 385: Create Vlan

    create vlan create vlan create vlan <vlan name> Description Creates a named VLAN. Syntax Description vlan name Specifies a VLAN name (up to 32 characters). Default A VLAN named Default exists on all new or initialized Extreme switches: • It initially contains all ports on a new or initialized switch, except for the management port(s), if there are any.
  • Page 386 VLAN Commands Example The following command creates a VLAN named accounting: create vlan accounting History This command was first available in ExtremeWare 1.0. This command was added to the Summit “e” series of switches in ExtremeWare 7.1e. Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 387: Delete Protocol

    delete protocol delete protocol delete protocol <protocol_name> Description Deletes a user-defined protocol. Syntax Description protocol_name Specifies a protocol name. Default Usage Guidelines If you delete a protocol that is in use by a VLAN, the protocol associated with that VLAN becomes “none.”...

  • Page 388: Delete Vlan

    VLAN Commands delete vlan delete vlan <vlan name> Description Deletes a VLAN. Syntax Description vlan name Specifies a VLAN name. Default Usage Guidelines If you delete a VLAN that has untagged port members, and you want those ports to be returned to the default VLAN, you must add them back explicitly using the command.

  • Page 389: Disable Gvrp

    disable gvrp disable gvrp disable gvrp Description Disables the Generic VLAN Registration Protocol (GVRP). NOTE This command is available only on the “i” series switches running ExtremeWare version 6.0 or earlier. Syntax Description This command has no arguments or variables. Default Disabled Usage Guidelines...

  • Page 390: Disable Mac-Vlan Port

    VLAN Commands disable mac-vlan port disable mac-vlan port <portlist> Description Disables a port from using the MAC-based VLAN algorithm. Syntax Description portlist A list of ports or slots and ports. May be in the form 1, 2, 3-5, 2:5, 2:6-2:8. Default Usage Guidelines Disabling a port removes it from the MacVlanDiscover VLAN, but does not automatically return it to...

  • Page 391: Enable Gvrp

    enable gvrp enable gvrp enable gvrp Description Enables the Generic VLAN Registration Protocol (GVRP). NOTE This command is available only on the “i” series switches running ExtremeWare version 6.0 or earlier. Syntax Description This command has no arguments or variables. Default Disabled Usage Guidelines...

  • Page 392: Enable Mac-Vlan Mac-Group Port

    VLAN Commands enable mac-vlan mac-group port enable mac-vlan mac-group [any | <group_number>] port <portlist> Description Enables a port to use the MAC-based VLAN algorithm. Syntax Description group_number A group number that should be associated with a specific set of ports. Specified as an integer. any indicates that these ports can be considered members of any MAC group.
  • Page 393 enable mac-vlan mac-group port Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 394: Show Gvrp

    VLAN Commands show gvrp show gvrp Description Displays the current configuration and status of GVRP. NOTE This command is available only on the “i” series switches running ExtremeWare 6.0 or earlier. Syntax Description This command has no arguments or variables. Default Usage Guidelines GVRP is not supported in ExtremeWare version 6.1 or later.

  • Page 395: Show Mac-Vlan

    show mac-vlan show mac-vlan show mac-vlan {configuration | database} Description Displays the MAC-based VLAN configuration and MAC address database content. Syntax Description configuration Specifies display of the MAC-based VLAN configuration only. database Specifies display of the MAC address database content only. Default Shows both configuration and database information.

  • Page 396: Show Protocol

    VLAN Commands show protocol show protocol {<protocol>} Description Displays protocol filter definitions. Syntax Description protocol Specifies a protocol filter name. Default Displays all protocol filters. Usage Guidelines Displays the defined protocol filter(s) with the types and values of its component protocols. Example The following is an example of the command:...

  • Page 397: Show Vlan

    show vlan show vlan For the “i” series platforms: show vlan {[<vlan name>} | detail | stats <vlan-name>]} For the “e” series platforms: show vlan {<vlan name> | detail} Description Displays configuration information about specified VLANs. Syntax Description vlan-name Specifies the name of the VLAN whose configuration is to be displayed. detail Specifies that detailed information should be displayed for each VLAN.
  • Page 398 VLAN Commands Examples The following is an example of the command: show vlan MSM64:1 # show vlan Name Protocol Addr Flags Proto Ports Default 0.0.0.0 /BP -----T-------- ANY MacVlanDiscover 4095 ------------------ ------ Mgmt 4094 10.5.4.80 /24 -------------- ANY 4093 192.168.11.1 /24 ------f------- ANY 4092 192.168.12.1 /24 ------f------- ANY...
  • Page 399 show vlan The following example shows the detail information for VLAN, called “v2,” which contains a port for a load-sharing group that spans multiple modules: show vlan detail VLAN Interface[3-201] with name “v2” created by user Tagging: 802.1Q Tag 2 Priority: 802.1P Priority 7 10.222.0.2/255.255.255.0...

  • Page 400: Unconfigure Ports Monitor Vlan

    VLAN Commands unconfigure ports monitor vlan unconfigure ports <portlist> monitor vlan <vlan name> Description Removes port-based VLAN monitoring. NOTE This command is available only on the “i” series switches. Syntax Description portlist Specifies one or more ports. May be in the form 1, 2, 3-5, 2:5, 2:6-2:8. vlan name Specifies a VLAN name.

  • Page 401: Unconfigure Vlan Ipaddress

    unconfigure vlan ipaddress unconfigure vlan ipaddress unconfigure vlan <vlan name> ipaddress Description Removes the primary IP address of a VLAN. Syntax Description vlan-name Specifies the name of the VLAN for which the primary IP address is to be unconfigured. Default Usage Guidelines Use this command to remove the primary IP address on a VLAN.
  • Page 402 VLAN Commands ExtremeWare 7.5 Command Reference Guide...

  • Page 403: Chapter 6 Fdb Commands

    FDB Commands This chapter describes commands for: • Configuring FDB entries • Displaying FDB entries • Configuring and enabling FDB scanning The switch maintains a database of all media access control (MAC) addresses received on all of its ports. It uses the information in this database to decide whether a frame should be forwarded or filtered. Each FDB entry consists of the MAC address of the device, an identifier for the port on which it was received, and an identifier for the VLAN to which the device belongs.

  • Page 404: Clear Fdb

    FDB Commands clear fdb On the “i” series of switches: clear fdb {<mac_address> | blackhole | ports <portlist> | remap | vlan <vlan name>} On the “e” series of switches: clear fdb {<mac_address> | blackhole | ports <portlist> | vlan <vlan name>} Description Clears dynamic FDB entries that match the filter.
  • Page 405 clear fdb You can also display FDB scan statistics using the following command: show diagnostics sys-health-check Example The following command clears any FDB entries associated with ports 3-5: clear fdb ports 3-5 The following command clears any FDB entries associated with VLAN corporate: clear fdb vlan corporate On the “i”...

  • Page 406: Configure Fdb Agingtime

    FDB Commands configure fdb agingtime configure fdb agingtime <seconds> Description Configures the FDB aging time for dynamic entries. Syntax Description seconds Specifies the aging time in seconds. Range is 15 through 1,000,000. A value of 0 indicates that the entry should never be aged out. Default 300 seconds Usage Guidelines...

  • Page 407: Configure Fdb-Scan Failure-Action

    configure fdb-scan failure-action configure fdb-scan failure-action configure fdb-scan failure-action [log | sys-health-check] Description Configures the action the switch takes if too many failures are detected within the specified FDB scan period. Syntax Description Specifies that messages are sent to the syslog. sys-health-check Specifies the configured system health check action is taken.
  • Page 408 FDB Commands This command was not supported in ExtremeWare 7.0. This command is supported in ExtremeWare 7.1.0. Platform Availability This command is available on the “i” series platform only. ExtremeWare 7.5 Command Reference Guide...

  • Page 409: Configure Fdb-Scan Period

    Do you wish to do this? (yes, no, cancel) 06/19/2003 10:29.28 <INFO:SYST> serial admin: configure fdb-scan period 1 Extreme Networks recommends an interval period of at least 15 seconds. This setting is independent of and does not affect the system health check configurations.

  • Page 410: Create Fdbentry Secure-Mac

    FDB Commands create fdbentry secure-mac create fdbentry secure-mac <mac_address> vlan <vlan name> ports <port-list> Description Specifies an authorized set of ports on which the specified MAC address will be permitted. Syntax Description mac_address Specifies a device MAC address, using colon-separated bytes. vlan name Specifies a VLAN name associated with a MAC address.

  • Page 411: Create Fdbentry Vlan Blackhole

    create fdbentry vlan blackhole create fdbentry vlan blackhole create fdbentry <mac_address> vlan <vlan name> blackhole {source-mac | dest-mac | both} Description Creates a blackhole FDB entry. Syntax Description mac_address Specifies a device MAC address, using colon-separated bytes. vlan name Specifies a VLAN name associated with a MAC address. blackhole Configures the MAC address as a blackhole entry.
  • Page 412 FDB Commands This command was added to the Summit “e” series of switches in ExtremeWare 7.1e. Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 413: Create Fdbentry Vlan Dynamic

    create fdbentry vlan dynamic create fdbentry vlan dynamic For “i” series switches: create fdbentry [<mac_address> | broadcast-mac | any-mac] vlan <vlan name> dynamic [qosprofile <qosprofile> {ingress-qosprofile <inqosprofile>} | ingress-qosprofile <inqosprofile> {qosprofile <qosprofile>}] For “e” series switches: create fdbentry [<mac_address> | any-mac] vlan <vlan name> dynamic [ingress-qosprofile <qosprofile>...
  • Page 414 FDB Commands • A port is disabled. • A port enters blocking state. • A port QoS setting is changed. • A port goes down (link down). Using the keyword, you can enable traffic from a QoS VLAN to have higher priority than any-mac 802.1p traffic.

  • Page 415: Create Fdbentry Vlan Ports

    create fdbentry vlan ports create fdbentry vlan ports create fdbentry <mac_address> vlan <vlan name> ports [<portlist> | all] {qosprofile <qosprofile>} {ingress-qosprofile <inqosprofile>} Description Creates a permanent static FDB entry, and optionally associates it with an ingress and/or egress QoS profile. Syntax Description mac_address Specifies a device MAC address, using colon-separated bytes.
  • Page 416 FDB Commands Permanent static entries are designated by “spm” in the flags field of the output. You can use show fdb command to display permanent FDB entries, including their QoS profile show fdb permanent associations. Example The following example adds a permanent, static entry to the FDB for MAC address is 00 E0 2B 12 34 56, in VLAN marketing on port 4: create fdbentry 00:E0:2B:12:34:56 vlan marketing port 4 History...

  • Page 417: Delete Fdbentry

    delete fdbentry delete fdbentry delete fdbentry [[<mac_address> | broadcast-mac] vlan <vlan name> | all] Description Deletes one or all permanent FDB entries. Syntax Description mac_address Specifies a device MAC address, using colon-separated bytes. broadcast-mac Specifies the broadcast MAC address. May be used as an alternate to the colon-separated byte form of the address ff:ff:ff:ff:ff:ff.

  • Page 418: Disable Fdb-Scan

    FDB Commands disable fdb-scan disable fdb-scan [all | slot {{backplane} | <slot number> | msm-a | msm-b}] Description Disables FDB scanning on a stand-alone switch or on a per slot or backplane basis on a modular switch. Syntax Description Specifies all of the slots in the chassis. NOTE: This is available on modular switches only.
  • Page 419 disable fdb-scan The following command disables FDB scanning on all of the slots of a modular switch: disable fdb-scan all History This command was first available in ExtremeWare 6.2.2b108. The default for this command was changed to disabled in ExtremeWare 6.2.2b134. This command was not supported in ExtremeWare 7.0.

  • Page 420: Enable Fdb-Scan

    FDB Commands enable fdb-scan enable fdb-scan [all | slot {{backplane} | <slot number> | msm-a | msm-b}] Description Enables FDB scanning on a stand-alone switch or on a per slot or backplane basis on a modular switch. Syntax Description Specifies all of the slots in the chassis. NOTE: This option is available on modular switches only.
  • Page 421 enable fdb-scan The following command enables FDB scanning on all of the slots of a modular switch: enable fdb-scan all History This command was first available in ExtremeWare 6.2.2b108. The default for this command was changed to disabled in ExtremeWare 6.2.2b134 This command was not supported in ExtremeWare 7.0.

  • Page 422: Run Fdb-Check

    FDB Commands run fdb-check run fdb-check [index <bucket> <entry> | [<mac_address> | broadcast-mac] {<vlan name>}] {extended} {detail} Description Checks MAC FDB entries for consistency. Syntax Description bucket Specifies the bucket portion of the FDB hash index. entry Specifies the entry portion of the FDB hash index. mac-address Specifies a MAC address (hex octet).
  • Page 423 run fdb-check This command was modified in ExtremeWare 6.2.1 to support the keyword. broadcast-mac Platform Availability This command is available on the “i” series platform. option is available on the Black Diamond 6800 chassis-based system only. extended ExtremeWare 7.5 Command Reference Guide...

  • Page 424: Show Fdb

    FDB Commands show fdb On “i” series of switches: show fdb {<mac_address> | broadcast-mac | permanent | ports <portlist> | remap | vlan <vlan name>} On “e” series of switches: show fdb {<mac_address> | permanent | ports <portlist> | vlan <vlan name>} Description Displays FDB entries.
  • Page 425 show fdb Flags Flags that define the type of entry: • B - Egress Blackhole • b - Ingress Blackhole • d - Dynamic • s - Static • p - Permanent • m - MAC • S - secure MAC •...
  • Page 426 FDB Commands Total: 33 Static: 16 Perm: 0 Locked: 0 Secure: 0 Dynamic: 17 Dropped: 0 Questionable: 0 Remapped: 0 FDB Aging time: 300 seconds NOTE IPX information only shows in “i” series switch output. The following command displays information about the permanent entries in the FDB: show fdb permanent It produces output similar to the following: EQP IQP Index...

  • Page 427: Unconfigure Fdb-Scan Failure-Action

    unconfigure fdb-scan failure-action unconfigure fdb-scan failure-action unconfigure fdb-scan failure-action Description Returns the switch to its default of sending FDB scan messages to the syslog if too many failures are detected within the specified scan period. Syntax Description The command has no arguments or variables. Default Usage Guidelines This setting is independent of and does not affect the system health check configurations.

  • Page 428: Unconfigure Fdb-Scan Period

    FDB Commands unconfigure fdb-scan period unconfigure fdb-scan period Description Returns the FDB scan interval to the factory default of 30 seconds. Syntax Description This command has no arguments or variables. Default Usage Guidelines This setting is independent of and does not affect the system health check configurations. Example The following command returns the FDB scan interval to 30 seconds: unconfigure fdb-scan period...

  • Page 429: Chapter 7 Qos Commands

    QoS Commands This chapter describes the following commands: • Commands for configuring Quality of Service (QoS) profiles • Commands creating traffic groupings and assigning the groups to QoS profiles • Commands for configuring, enabling and disabling explicit class-of-service traffic groupings (802.1p and DiffServ) •...
  • Page 430 QoS Commands To configure QoS, you define how your switch responds to different categories of traffic by creating and configuring QoS profiles. The service that a particular type of traffic receives is determined by assigning a QoS profile to a traffic grouping or classification. The building blocks are defined as follows: •...

  • Page 431: Clear Dlcs

    clear dlcs clear dlcs clear dlcs Description Clears all learned DLCS data. NOTE This command is available only on the “i” series switches. Syntax Description This command has no arguments or variables. Default Usage Guidelines If the IP address of an end-station changes, and the end-station is not immediately rebooted, the old host-to-IP mapping is not deleted.

  • Page 432: Configure Diffserv Examination Code-Point Qosprofile Ports

    QoS Commands configure diffserv examination code-point qosprofile ports configure diffserv examination code-point <code_point> qosprofile <qosprofile> ports [<portlist> | all] {low-drop-probability | high-drop-probability} Description Configures the default mapping of ingress DiffServ code points (DSCP) to QoS profiles. NOTE This command is available only on the “i” series switches. Syntax Description code_point Specifies a DiffServ code point (a 6-bit value in the IP-TOS byte in the IP header).
  • Page 433 configure diffserv examination code-point qosprofile ports For the BlackDiamond Switches. The low-drop-probability high-drop-probability keywords are applicable only to SONET ports. The low-drop-probability keywords are useful in conjunction with the weighted RED (WRED) high-drop-probability implementation provided by SONET ports. This implementation supports two different drop probabilities;...

  • Page 434: Configure Diffserv Replacement Priority Code-Point Ports

    QoS Commands configure diffserv replacement priority code-point ports configure diffserv replacement priority <value> code-point <code_point> ports [<portlist> | all] Description Configures the default egress DiffServ replacement mapping. NOTE This command is available only on the “i” series switches. Syntax Description value Specifies the 802.1p priority value.
  • Page 435 configure diffserv replacement priority code-point ports Example The following command specifies that a code point value of 25 should be used to replace the TOS bits in packets with an 802.1p priority of 2 for ports 5-9: configure diffserv replacement priority 2 code-point 25 ports 5-9 History This command was first available in ExtremeWare 6.0.

  • Page 436: Configure Dot1P Type

    QoS Commands configure dot1p type configure dot1p type <dot1p_priority> qosprofile <qosprofile> Description Configures the default QoS profile to 802.1p priority mapping. NOTE This command is available only on the “i” series switches. Syntax Description dot1p_priority Specifies the 802.1p priority value. The value is an integer between 0 and 7. qosprofile Specifies a QoS profile.
  • Page 437 configure dot1p type Platform Availability This command is available on the “i” series platforms only. ExtremeWare 7.5 Command Reference Guide...

  • Page 438: Configure Ports Qosprofile

    QoS Commands configure ports qosprofile configure ports <portlist> qosprofile <qosprofile> Description Configures one or more ports to use a particular QoS profile. NOTE This command is available only on the “i” series switches. Syntax Description portlist Specifies a list of ports or slots and ports. May be in the form 1, 2, 3-5, 2:5, 2:6-2:8. qosprofile Specifies a QoS profile.

  • Page 439: Configure Qosprofile

    configure qosprofile configure qosprofile configure qosprofile <qosprofile> minbw <min_percent> maxbw <max_percent> priority <level> {[minbuf <percent> maxbuf <number> [K | M] | maxbuff <number> [K | M] | <portlist>]} Description Modifies the default QoS profile parameters. NOTE This command is available only on the “i” series switches. Syntax Description qosprofile Specifies a QoS profile name.
  • Page 440 QoS Commands parameter unless specific situations and application behavior indicate. You must reboot the switch for changes to this parameter to take effect. For ExtremeWare 4.0: • Only four priority levels are available (low, normal, medium, and high). Examples The following command configures the QoS profile parameters of QoS profile qp5 for specific ports on an “i”...

  • Page 441: Configure Qostype Priority

    configure qostype priority configure qostype priority configure qostype priority [source-mac | dest-mac | access-list | vlan | diffserv | dot1p] <priority> Description Configures the priority of the specified QoS traffic grouping. NOTE This command is available only on the “i” series switches. Syntax Description source-mac Specifies the priority of traffic groupings based on FDB source MAC addresses.
  • Page 442 QoS Commands Platform Availability This command is available on the “i” series platforms only. ExtremeWare 7.5 Command Reference Guide...

  • Page 443: Configure Red Drop-Probability

    configure red drop-probability configure red drop-probability configure red drop-probability <percent> Description Configures the random early detect (RED) drop probability. NOTE This command is available only on the “i” series switches. Syntax Description percent Specifies the RED drop probability as a percentage. Range is 0 -100. Default Usage Guidelines When the switch detects that traffic is filling up any of the eight hardware queues, it performs a random...

  • Page 444: Configure Vlan Priority

    QoS Commands configure vlan priority configure vlan <vlan name> priority <priority> Description Configures the 802.1p priority value for traffic generated on the switch. Syntax Description vlan name Specifies a VLAN name. priority Specifies the 802.1p priority value. The value is an integer between 0 and 7. Default Usage Guidelines The 802.1p priority field is placed in the 802.1Q tag when a packet is generated by the switch.

  • Page 445: Configure Vlan Qosprofile

    configure vlan qosprofile configure vlan qosprofile configure vlan <vlan name> qosprofile <qosprofile> Description Configures a VLAN to use a particular QoS profile. NOTE This command is available only on the “i” series switches. Syntax Description vlan name Specifies a VLAN name. qosprofile Specifies a QoS profile.

  • Page 446: Disable Diffserv Examination Ports

    QoS Commands disable diffserv examination ports disable diffserv examination ports [<portlist> | all] Description Disables the examination of the DiffServ field in an IP packet. Syntax Description portlist Specifies a list of ports or slots and ports to which the parameters apply. May be in the form 1, 2, 3-5, 2:5, 2:6-2:8.

  • Page 447: Disable Diffserv Replacement Ports

    disable diffserv replacement ports disable diffserv replacement ports disable diffserv replacement ports [<portlist> | all] Description Disables the replacement of diffserv code points in packets transmitted by the switch. NOTE This command is available only on the “i” series switches. Syntax Description portlist Specifies a list of ports or slots and ports to which the parameters apply.

  • Page 448: Disable Dlcs

    QoS Commands disable dlcs disable dlcs {fast-ethernet-ports | ports [all | <port_number>]} Description This command disables Windows internet Naming Service (WINS) snooping for ports on this switch. NOTE This command is available only on the “i” series switches. Syntax Description fast-ethernet-ports Specifies that WINS packet snooping should be disabled on all Fast Ethernet ports.

  • Page 449: Disable Dot1P Replacement Ports

    disable dot1p replacement ports disable dot1p replacement ports disable dot1p replacement ports [<portlist> | all] Description Disables the ability to overwrite 802.1p priority values for a given set of ports. NOTE This command is available only on the “i” series switches. Syntax Description portlist Specifies a list of ports or slots and ports to which the parameters apply.

  • Page 450: Disable Qosmonitor

    QoS Commands disable qosmonitor disable qosmonitor Description Disables the QoS monitoring capability. NOTE This command is available only on the “i” series switches. Syntax Description This command has no arguments or variables. Default Disabled Usage Guidelines The QoS monitor is a utility on “i” series switches that monitors the eight hardware queues (QP1-QP8) associated with any port(s).

  • Page 451: Disable Red Ports

    disable red ports disable red ports disable red ports <portlist> Description Disables random early detection (RED) on the specified ports. NOTE This command is available only on the “i” series switches. Syntax Description portlist Specifies the port number(s). May be in the form 1, 2, 3-5, 2:5, 2:6-2:8. Default Disabled Usage Guidelines...

  • Page 452: Enable Diffserv Examination Ports

    QoS Commands enable diffserv examination ports enable diffserv examination ports [<portlist> | all] Description Enables examination of the DiffServ field of an ingress IP packet in order to select a QoS profile. Syntax Description portlist Specifies a list of ports or slots and ports to which the parameters apply. May be in the form 1, 2, 3-5, 2:5, 2:6-2:8.

  • Page 453: Enable Diffserv Replacement Ports

    enable diffserv replacement ports enable diffserv replacement ports enable diffserv replacement ports [<portlist> | all] Description Enables the DiffServ code point to be overwritten in packets transmitted by the switch. NOTE This command is available only on the “i” series switches. Syntax Description portlist Specifies a list of ports or slots and ports to which the parameters apply.

  • Page 454: Enable Dlcs

    QoS Commands enable dlcs enable dlcs {fast-etherenable dlcs net-ports | ports [all | <port_number>]} Description This command enables Windows Internet Naming Service (WINS) snooping for ports on the switch. NOTE This command is available only on the “i” series switches. Syntax Description fast-ethernet-ports Specifies that WINS packets should be snooped on all Fast Ethernet ports.
  • Page 455 enable dlcs Platform Availability This command is available on the “i” series platforms only. ExtremeWare 7.5 Command Reference Guide...

  • Page 456: Enable Dot1P Replacement Ports

    QoS Commands enable dot1p replacement ports enable dot1p replacement ports [<portlist> | all] Description Allows the 802.1p priority field to be overwritten on egress according to the QoS profile-to-802.1p priority mapping for a given set of ports. NOTE This command is available only on the “i” series switches. Syntax Description portlist Specifies a list of ports or slots and ports.
  • Page 457 enable dot1p replacement ports History This command was available in ExtremeWare 6.0. Platform Availability This command is available on the “i” series platforms only. ExtremeWare 7.5 Command Reference Guide...

  • Page 458: Enable Qosmonitor

    QoS Commands enable qosmonitor enable qosmonitor {port <port>} Description Enables the QoS monitoring capability on the switch. NOTE This command is available only on the “i” series switches. Syntax Description port Specifies a port. Default Disabled Usage Guidelines When no port is specified, the QoS monitor automatically samples all the ports and records the sampled results.

  • Page 459: Enable Red Ports

    enable red ports enable red ports enable red ports <portlist> Description Enables random early detection (RED) on a port. NOTE This command is available only on the “i” series switches. Syntax Description portlist Specifies a list of ports or slots and ports. May be in the form 1, 2, 3-5, 2:5, 2:6-2:8. Default Disabled Usage Guidelines...

  • Page 460: Show Dlcs

    QoS Commands show dlcs show dlcs Description Displays the status of DLCS (enabled or disabled) and the status of ports that are snooping WINS packets. NOTE This command is available only on the “i” series switches. Syntax Description This command has no arguments or variables. Default Usage Guidelines None...

  • Page 461: Show Dot1P

    show dot1p show dot1p show dot1p Description Displays the 802.1p-to-QoS profile mappings. NOTE This command is available only on the “i” series switches. Syntax Description This command has no arguments or variables. Default Usage Guidelines None Example The following command displays the current 802.1p-to-QoS mappings on the switch: show dot1p Following is the output from this command: 802.1p Priority Value...

  • Page 462: Show Ports Qosmonitor

    QoS Commands show ports qosmonitor For the “i” series switches: show ports {mgmt | <portlist>} qosmonitor {egress | ingress} {discards} For the “e” series switches: show ports {mgmt | <portlist>} qosmonitor} Description Displays real-time QoS statistics for egress packets on one or more ports. Syntax Description mgmt Specifies the management port.
  • Page 463 show ports qosmonitor Following is sample output from this command: Qos Monitor Egress Queue Summary Mon Oct 21 20:35:21 2002 Port Xmts Xmts Xmts Xmts Xmts Xmts Xmts Xmts ================================================================================ ================================================================================ 0->Clear Counters U->page up D->page down R->rate screen ESC->exit History This command was available in ExtremeWare 2.0.

  • Page 464: Show Qosprofile

    QoS Commands show qosprofile show qosprofile {<qosprofile>} {port <portlist>} Description Displays QoS information for the switch. Syntax Description <qosprofile> Specifies a QoS profile name. portlist Specifies a list of ports or slots and ports. May be in the form 1, 2, 3-5, 2:5, 2:6-2:8. Default Displays QoS information for all profiles.
  • Page 465 show qosprofile Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 466: Show Qostype Priority

    QoS Commands show qostype priority show qostype priority Description Displays priority settings for QoS traffic groupings. NOTE This command is available only on the “i” series switches. Syntax Description This command has no arguments or variables. Default Usage Guidelines None Example The following command displays the QoS traffic grouping priority settings for this switch: show qostype priority...

  • Page 467: Unconfigure Diffserv Examination Ports

    unconfigure diffserv examination ports unconfigure diffserv examination ports unconfigure diffserv examination ports [<portlist> | all] Description Removes the DiffServ examination code point from a port. Syntax Description portlist Specifies a list of ports or slots and ports. May be in the form 1, 2, 3-5, 2:5, 2:6-2:8. Specifies that DiffServ examination code points should be removed from all ports.

  • Page 468: Unconfigure Diffserv Replacement Ports

    QoS Commands unconfigure diffserv replacement ports unconfigure diffserv replacement ports [<portlist> | all] Description Removes the DiffServ replacement mapping from a port. NOTE This command is available only on the “i” series switches. Syntax Description portlist Specifies a list of ports or slots and ports. May be in the form 1, 2, 3-5, 2:5, 2:6-2:8. Specifies that DiffServ replacement mapping should be removed from all ports.

  • Page 469: Unconfigure Qostype Priority

    unconfigure qostype priority unconfigure qostype priority unconfigure qostype priority Description Resets all traffic grouping priority values to their defaults. NOTE This command is available only on the “i” series switches. Syntax Description This command has no arguments or variables. Default Usage Guidelines Resets the traffic grouping priorities to the following: access-list = 11...
  • Page 470 QoS Commands ExtremeWare 7.5 Command Reference Guide...

  • Page 471: Nat Commands

    IP addresses, typically public Internet IP addresses. This conversion is done transparently by having a NAT device (for example, any Extreme Networks switch) rewrite the source IP address and layer 4 port of the packets.

  • Page 472: Clear Nat

    NAT Commands clear nat clear nat [connections | stats} Description Clears NAT connections or statistics. Syntax Description connections Specifies the current NAT connections table. stats Specifies the statistics counter. Default Usage Guidelines None Example The following command clears NAT connections: clear nat connections History This command was first available in ExtremeWare 6.2.

  • Page 473: Configure Nat Add Vlan Map

    configure nat add vlan map configure nat add vlan map configure nat add vlan <vlan name> map source [any | <source_ipaddress>/<mask>] {l4-port [any | <port> {- <port>}]} {destination [any | <dest_ipaddress>/<mask>] {l4-port [any | <port> {- <port>}]}} to <nat_ip address> [/<mask> | - <ip address>] {[tcp | udp | both] [portmap {<min>...
  • Page 474 NAT Commands Usage Guidelines Four different modes are used to determine how the outside IP addresses and layer 4 ports are assigned: • Static mapping Dynamic mapping • • Port mapping • Auto-constraining Static and Dynamic Mapping. When static mapping is used, each inside IP address uses a single outside IP address.
  • Page 475 configure nat add vlan map Using Layer 4 Port Numbers. The addition of the optional keyword allows the NAT rule to l4-port be applied to only packets with a specific layer 4 source or destination port. If you use the layer 4-port command after the source IP/mask, the rule matches only if the port(s) specified are the source layer 4-ports.
  • Page 476 NAT Commands Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 477: Configure Nat Delete

    configure nat delete configure nat delete configure nat delete [all | vlan <vlan name> map source [any | <source_ip address>/<mask>] {l4-port [any | <port> {- <port>}]} {destination <dest_ip address>/<mask> {l4-port [any | <port> {- <port>}]}} to <nat_ip address> [/<mask> | - <ip address>] [tcp | udp | both] [portmap {<min>...
  • Page 478 NAT Commands Example The following command deletes a portmap translation rule: configure nat delete out_vlan_2 map source 192.168.2.128/25 to 216.52.8.64/28 tcp portmap 1024 - 8192 History This command was first available in ExtremeWare 6.2. This command was added to the Summit “e” series of switches in ExtremeWare 7.1e. Platform Availability This command is available on all platforms.

  • Page 479: Configure Nat Finrst-Timeout

    configure nat finrst-timeout configure nat finrst-timeout configure nat finrst-timeout <seconds> Description Configures the timeout for a TCP session that has been torn down or reset. Syntax Description seconds Specifies the number of seconds to wait before the session table entry times out. Default Default timeout is 60 seconds.

  • Page 480: Configure Nat Icmp-Timeout

    NAT Commands configure nat icmp-timeout configure nat icmp-timeout <seconds> Description Configures the timeout for an ICMP packet. Syntax Description seconds Specifies the number of seconds to wait before the session table entry times out. Default Default timeout is 3 seconds. Usage Guidelines Setting the timeout to zero specifies that session table entries should not be timed out.

  • Page 481: Configure Nat Syn-Timeout

    configure nat syn-timeout configure nat syn-timeout configure nat syn-timeout <seconds> Description Configures the timeout for an entry with an unacknowledged TCP SYN state. Syntax Description seconds Specifies the number of seconds to wait before the session table entry times out. Default Default timeout is 60 seconds.

  • Page 482: Configure Nat Tcp-Timeout

    NAT Commands configure nat tcp-timeout configure nat tcp-timeout <seconds> Description Configures the timeout for a fully set up TCP SYN session. Syntax Description seconds Specifies the number of seconds to wait before the session table entry times out. Default Default timeout is 120 seconds. Usage Guidelines Setting the timeout to zero specifies that session table entries should not be timed out.

  • Page 483: Configure Nat Timeout

    configure nat timeout configure nat timeout configure nat timeout <seconds> Description Configures the timeout for any IP packet that is not TCP, UDP, or ICMP. Syntax Description seconds Specifies the number of seconds to wait before the session table entry times out. Default Default timeout is 600 seconds.

  • Page 484: Configure Nat Udp-Timeout

    NAT Commands configure nat udp-timeout configure nat udp-timeout <seconds> Description Configures the timeout for a UDP session. Syntax Description seconds Specifies the number of seconds to wait before the session table entry times out. Default Default timeout is 120 seconds. Usage Guidelines Setting the timeout to zero specifies that session table entries should not be timed out.

  • Page 485: Configure Nat Vlan

    configure nat vlan configure nat vlan configure nat vlan <vlan name> [inside | outside | none] Description Configures a VLAN to participate in NAT. Syntax Description vlan name Specifies a VLAN name. inside Specifies that the VLAN is an inside VLAN. outside Specifies that the VLAN is an outside VLAN.

  • Page 486: Disable Nat

    NAT Commands disable nat disable nat Description Disables network address translation on the switch. Syntax Description This command has no arguments or variables. Default Disabled Usage Guidelines None Example The following command disables NAT functionality on the switch: disable nat History This command was first available in ExtremeWare 6.2.

  • Page 487: Enable Nat

    enable nat enable nat enable nat Description Enables network address translation on the switch. Syntax Description This command has no arguments or variables. Default Disabled Usage Guidelines None Example The following command enables NAT functionality on the switch: enable nat History This command was first available in ExtremeWare 6.2.

  • Page 488: Show Nat

    NAT Commands show nat show nat {timeout | stats | connections | rules {vlan <outside_vlan>}} Description Displays NAT settings. Syntax Description timeout Specifies the display of NAT timeout settings. stats Specifies the display of statistics for NAT traffic. connections Specifies the display of the current NAT connection table. rules Specifies the display of NAT rules, optionally for a specific VLAN.
  • Page 489 show nat Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...
  • Page 490 NAT Commands ExtremeWare 7.5 Command Reference Guide...
  • Page 491 SLB Commands—“i” Series Switches Only This chapter discusses server load balancing (SLB) and flow redirection commands. SLB distributes client requests transparently among several servers. The main use for SLB is for web hosting (using redundant servers to increase the performance and reliability of busy websites). You can use SLB to manage and balance traffic for client equipment such as web servers, cache servers, routers, and proxy servers.

  • Page 492: Clear Slb Connections

    SLB Commands—“i” Series Switches Only clear slb connections clear slb connections {ipaddress <ip address> : <port> | vip <vip name>} Description Clears all existing SLB connections. Syntax Description ip address Specifies an IP address. port Specifies a port. vip name Specifies a virtual server.

  • Page 493: Clear Slb Persistence Vip

    clear slb persistence vip clear slb persistence vip clear slb persistence vip <vip name> Description Clears the connection information in the persistence table. Syntax Description vip name Specifies a virtual server. Default Usage Guidelines Use this command only during testing. Clearing persistence disables applications, such as shopping carts, that require persistence.

  • Page 494: Configure Flow-Redirect Add Next-Hop

    SLB Commands—“i” Series Switches Only configure flow-redirect add next-hop configure flow-redirect <flow redirect> add next-hop <ip address> Description Adds the next hop host (gateway) that is to receive the packets that match the flow redirection policy. Syntax Description flow redirect Specifies a flow redirection policy.

  • Page 495: Configure Flow-Redirect Delete Next-Hop

    configure flow-redirect delete next-hop configure flow-redirect delete next-hop configure flow-redirect <flow redirect> delete next-hop <ip address> Description Deletes the next hop host (gateway). Syntax Description flow redirect Specifies a flow redirection policy. ip address Specifies an IP address. Default Usage Guidelines None Example The following command deletes the next hop of 10.2.1.20 from the flow redirection policy named...

  • Page 496: Configure Flow-Redirect Service-Check Ftp

    SLB Commands—“i” Series Switches Only configure flow-redirect service-check ftp configure flow-redirect <flow redirect> service-check ftp user <user name> <password> Description Configures the flow redirection FTP check. Syntax Description flow redirect Specifies a flow redirection policy. user name Specifies the user name for logging in to the FTP service. password Specifies the password for logging in to the FTP service.

  • Page 497: Configure Flow-Redirect Service-Check Http

    5000 bytes. Extreme Networks recommends that you create a specific URL dedicated to this check. Do not include “http://” in the URL. To check a URL beyond the root directory, include the path in the specified URL.

  • Page 498: Configure Flow-Redirect Service-Check L4-Port

    SLB Commands—“i” Series Switches Only configure flow-redirect service-check L4-port configure flow-redirect <flow redirect> service-check L4-port Description Configures the flow redirection layer 4 port check. Syntax Description flow redirect Specifies a flow redirection policy. Default Usage Guidelines This command automatically enables layer 4 port check. The layer 4 port check opens and closes the layer 4 port specified in the flow redirection policy.

  • Page 499: Configure Flow-Redirect Service-Check Nntp

    configure flow-redirect service-check nntp configure flow-redirect service-check nntp configure flow-redirect <flow redirect> service-check nntp <newsgroup> Description Configures the flow redirection NNTP check. Syntax Description flow redirect Specifies a flow redirection policy. newsgroup Specifies the news group to be checked. Default Usage Guidelines This command automatically enables NNTP check.

  • Page 500: Configure Flow-Redirect Service-Check Ping

    SLB Commands—“i” Series Switches Only configure flow-redirect service-check ping configure flow-redirect <flow redirect> service-check ping Description Configures the flow redirection ping check. Syntax Description flow redirect Specifies a flow redirection policy. Default Usage Guidelines This command automatically enables ping check. Ping check is also automatically enabled when you add a next hop using the following command: configure flow-redirect add next-hop In ExtremeWare 6.2.0 and prior, the frequency of the ping check is 10 seconds, the timeout of the ping...

  • Page 501: Configure Flow-Redirect Service-Check Pop3

    configure flow-redirect service-check pop3 configure flow-redirect service-check pop3 configure flow-redirect <flow redirect> service-check pop3 user <user name> <password> Description Configures the flow redirection POP3 check. Syntax Description flow redirect Specifies a flow redirection policy. user name Specifies the user name for logging in to the POP3 service. password Specifies the password for logging in to the POP3 service.

  • Page 502: Configure Flow-Redirect Service-Check Smtp

    SLB Commands—“i” Series Switches Only configure flow-redirect service-check smtp configure flow-redirect <flow redirect> service-check smtp <dns domain> Description Configures the flow redirection SMTP check. Syntax Description flow redirect Specifies a flow redirection policy. dns domain Specifies the DNS domain of the mail server. Default Usage Guidelines This command automatically enables SMTP check.

  • Page 503: Configure Flow-Redirect Service-Check Telnet

    configure flow-redirect service-check telnet configure flow-redirect service-check telnet configure flow-redirect <flow redirect> service-check telnet user <user name> <password> Description Configures the flow redirection telnet check. Syntax Description flow redirect Specifies a flow redirection policy. user name Specifies the user name for logging in to the telnet service. password Specifies the password for logging in to the telnet service.

  • Page 504: Configure Flow-Redirect Timer Ping-Check

    SLB Commands—“i” Series Switches Only configure flow-redirect timer ping-check configure flow-redirect timer ping-check frequency <seconds> timeout <seconds> Description Configures the frequency and timeout for the flow redirection ping check. Syntax Description frequency Specifies the ping check frequency. The range is 1 to 60. timeout Specifies the ping check timeout.

  • Page 505: Configure Flow-Redirect Timer Service-Check

    configure flow-redirect timer service-check configure flow-redirect timer service-check configure flow-redirect timer service-check frequency <seconds> timeout <seconds> Description Configures the frequency and timeout for the flow redirection service check. Syntax Description frequency Specifies the service-check frequency. The range is 15 to 300. timeout Specifies the service-check timeout.

  • Page 506: Configure Flow-Redirect Timer Tcp-Port-Check

    SLB Commands—“i” Series Switches Only configure flow-redirect timer tcp-port-check configure flow-redirect timer tcp-port-check frequency <seconds> timeout <seconds> Description Configures the frequency and timeout for the flow redirection TCP port check. Syntax Description frequency Specifies the tcp-port-check frequency. The range is 5 to 120. timeout Specifies the tcp-port-check timeout.

  • Page 507: Configure Slb Esrp Vlan

    To set the unit number of a virtual server, use the following command: configure slb vip For simplicity, Extreme Networks recommends that you put client, server, and virtual server VLANs in the same ESRP group. Example The following command configures ESRP VLAN “servers”...

  • Page 508: Configure Slb Failover Alive-Frequency

    The default timeout is 3 seconds. Usage Guidelines The frequency must be less than the timeout. Extreme Networks recommends that you set the timeout greater than an even multiple of the frequency. To enable active-active operation, use the following command:...

  • Page 509: Configure Slb Failover Dead-Frequency

    configure slb failover dead-frequency configure slb failover dead-frequency configure slb failover dead-frequency <seconds> Description Configures the frequency at which the local switch attempts to re-establish communication with an unresponsive remote switch. Syntax Description dead-frequency The frequency at which the local switch attempts to re-establish communication with an unresponsive remote switch.

  • Page 510: Configure Slb Failover Failback-Now

    SLB Commands—“i” Series Switches Only configure slb failover failback-now configure slb failover failback-now Description Configures the local SLB device to release the remote SLB resources if the remote SLB is alive. Syntax Description This command has no arguments or variables. Default Usage Guidelines When an active SLB unit fails and recovers, and manual failback is enabled, use this command to force...

  • Page 511: Configure Slb Failover Ping-Check

    configure slb failover ping-check configure slb failover ping-check configure slb failover ping-check <ip address> {frequency <seconds> timeout <seconds>} Description Configures the SLB device to actively determine if a remote gateway is reachable by performing a ping. Syntax Description ip address Specifies the IP address of the remote gateway.

  • Page 512: Configure Slb Failover Unit

    To enable active-active operation, use the following command: enable slb failover Extreme Networks recommends that you use a dedicated layer 2 VLAN to connect the two active-active switches. Example The following command configures the local SLB switch (with an IP address of 10.10.10.22) to direct unit 2 virtual servers to failover to the SLB switch with an IP address of 10.10.10.21:...

  • Page 513: Configure Slb Global Connection-Block

    configure slb global connection-block configure slb global connection-block configure slb global connection-block <number> Description Configures the number of SLB connections to allocate in memory; this allocation can improve performance. Syntax Description number Specifies the number of connection blocks. The range is 100 to 20,000. Default The default is 10,000.

  • Page 514: Configure Slb Global Connection-Timeout

    SLB Commands—“i” Series Switches Only configure slb global connection-timeout configure slb global connection-timeout <seconds> Description Configures the connection timeout for transparent and translation modes. Syntax Description seconds Specifies the number of seconds. The range is 1 to 180. Default The default is one second. Usage Guidelines None Example...

  • Page 515: Configure Slb Global Ftp

    For both user and password, the default value is anonymous. Usage Guidelines If you do not enter a password, you are prompted for the password twice. Extreme Networks recommends that you use a password. The FTP service check provides a more thorough check than ping check, because the FTP service check logs in to the service.

  • Page 516: Configure Slb Global Http

    The HTTP service check provides a more thorough check than ping check, because the HTTP service check connects to a specific URL and checks for a specific text string. Extreme Networks recommends that you create a specific URL dedicated to this check.
  • Page 517 configure slb global http Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 518: Configure Slb Global Nntp

    SLB Commands—“i” Series Switches Only configure slb global nntp configure slb global nntp <newsgroup> Description Configures the default parameters for layer 7 NNTP service checking. Syntax Description newsgroup Specifies a newsgroup. Default The default newsgroup is ebusiness. Usage Guidelines The NNTP service check provides a more thorough check than ping check, because the NNTP service check logs in to the service.

  • Page 519: Configure Slb Global Persistence-Level

    configure slb global persistence-level configure slb global persistence-level configure slb global persistence-level [any-vip | same-vip-any-port | same-vip-same-port] Description Configures the persistence level globally. Syntax Description any-vip Specifies that an entry can match any port on any virtual server. same-vip-any-port Specifies that an entry must match the virtual server and can be any port. same-vip-same-port Specifies that an entry must match both virtual server and port for persistence.

  • Page 520: Configure Slb Global Persistence-Method

    SLB Commands—“i” Series Switches Only configure slb global persistence-method configure slb global persistence-method [per-packet | per-session] Description Configures the behavior of the persistence timer. Syntax Description per-packet Resets the persistence timer at the receipt of each packet. per-session Resets the persistence timer at the beginning of the session. When the timer expires, persistence for the session ends.

  • Page 521: Configure Slb Global Ping-Check

    configure slb global ping-check configure slb global ping-check configure slb global ping-check frequency <seconds> timeout <seconds> Description Configures the default health checking frequency and timeout period using layer 3-based pinging of the physical node. Syntax Description frequency Specifies the frequency of the ping check. The range is 1 to 60 seconds. timeout Specifies the timeout of the ping check.

  • Page 522: Configure Slb Global Pop3

    For both user and password, the default value is anonymous. Usage Guidelines If you do not enter a password, you are prompted for the password twice. Extreme Networks recommends that you use a password. The POP3 service check provides a more thorough check than ping check, because the POP3 service check logs in to the service.

  • Page 523: Configure Slb Global Service-Check

    configure slb global service-check configure slb global service-check configure slb global service-check frequency <seconds> timeout <seconds> Description Configures the default health checking frequency and timeout period using layer 7-based application-dependent checking. Syntax Description frequency Specifies the frequency of the service check. The range is 15 to 300 seconds. timeout Specifies the timeout of the service check.

  • Page 524: Configure Slb Global Smtp

    SLB Commands—“i” Series Switches Only configure slb global smtp configure slb global smtp <dns domain> Description Configures the default parameters for layer 7 SMTP service checking. Syntax Description dns domain Specifies the domain to check. Default The default value for is the switch domain.

  • Page 525: Configure Slb Global Synguard

    configure slb global synguard configure slb global synguard configure slb global synguard max-unacknowledged-SYNs <number> Description Configures the SYN-guard feature. Syntax Description max-unacknowledged-SYNs Specifies the number of half-open connections that the switch allows. The range is 10 to 4000. Default The default value is 50. Usage Guidelines If the number of half-open connections exceeds the number specified, the switch immediately ages out the half-open connections.

  • Page 526: Configure Slb Global Tcp-Port-Check

    SLB Commands—“i” Series Switches Only configure slb global tcp-port-check configure slb global tcp-port-check frequency <seconds> timeout <seconds> Description Configures the default health checking frequency and timeout period using layer 4-based TCP port testing. Syntax Description frequency Specifies the frequency of the TCP port check. The range is 5 to 120 seconds. timeout Specifies the timeout of the TCP port check.

  • Page 527: Configure Slb Global Telnet

    For both user and password, the default value is anonymous. Usage Guidelines If you do not enter a password, you are prompted for the password twice. Extreme Networks recommends that you use a password. The telnet service check provides a more thorough check than ping check, because the telnet service check logs in to the service.

  • Page 528: Configure Slb Gogo-Mode Health-Check

    SLB Commands—“i” Series Switches Only configure slb gogo-mode health-check configure slb gogo-mode <port number> health-check <ip address> Description Configures the health checker with the common IP addresses of the GoGo mode servers in this group. Syntax Description port number Specifies the GoGo mode master port. ip address Specifies an IP address.

  • Page 529: Configure Slb Gogo-Mode Ping-Check

    configure slb gogo-mode ping-check configure slb gogo-mode ping-check configure slb gogo-mode <port number> ping-check frequency <seconds> timeout <seconds> Description Overrides the global default ping check frequency and timeout values for this GoGo mode group. Syntax Description port number Specifies the GoGo mode master port. frequency Specifies the frequency of the ping check.
  • Page 530 SLB Commands—“i” Series Switches Only Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 531: Configure Slb Gogo-Mode Service-Check Ftp

    configure slb gogo-mode service-check ftp configure slb gogo-mode service-check ftp configure slb gogo-mode <port number> service-check ftp {L4-port <L4-port>} {user <user> | password {encrypted} <password>} Description Configures the FTP service check parameters for a GoGo mode group. Syntax Description port number Specifies the GoGo mode master port.

  • Page 532: Configure Slb Gogo-Mode Service-Check Http

    This command accesses the specified URL and checks for the specified alphanumeric string in the first 1000 bytes. Extreme Networks recommends that you create a specific URL dedicated to this check. Do not include “http://” in the URL. To check a URL beyond the root directory, include the path in the specified URL.
  • Page 533 configure slb gogo-mode service-check http Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 534: Configure Slb Gogo-Mode Service-Check Pop3

    SLB Commands—“i” Series Switches Only configure slb gogo-mode service-check pop3 configure slb gogo-mode <port number> service-check pop3 {L4-port <L4-port>} {userid <userid> | password {encrypted} <password>} Description Configures the service check parameters for a GoGo mode group. Syntax Description port number Specifies the GoGo mode master port.

  • Page 535: Configure Slb Gogo-Mode Service-Check Smtp

    configure slb gogo-mode service-check smtp configure slb gogo-mode service-check smtp configure slb gogo-mode <port number> service-check smtp {L4-port <L4-port>} {<dns domain>} Description Configures the service check parameters for a GoGo mode group. Syntax Description port number Specifies the GoGo mode master port. L4-port Specifies a layer 4 port.

  • Page 536: Configure Slb Gogo-Mode Service-Check Telnet

    SLB Commands—“i” Series Switches Only configure slb gogo-mode service-check telnet configure slb gogo-mode <port number> service-check telnet {L4-port <L4-port>} {user <user name> | password {encrypted} <password>} Description Configures the service check parameters for a GoGo mode group. Syntax Description port number Specifies the GoGo mode master port.

  • Page 537: Configure Slb Gogo-Mode Service-Check Timer

    configure slb gogo-mode service-check timer configure slb gogo-mode service-check timer configure slb gogo-mode <port number> service-check timer [all | ftp | http | telnet | smtp | nntp | pop3 | <TCP port number>] frequency <seconds> timeout <seconds> Description Overrides the global frequency and timeout values for the service check. Syntax Description port number Specifies the GoGo mode master port.
  • Page 538 SLB Commands—“i” Series Switches Only Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 539: Configure Slb Gogo-Mode Tcp-Port-Check Add

    configure slb gogo-mode tcp-port-check add configure slb gogo-mode tcp-port-check add configure slb gogo-mode <port number> tcp-port-check add [ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | www | <TCP port number>] Description Adds the specified layer 4 port.
  • Page 540 SLB Commands—“i” Series Switches Only Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 541: Configure Slb Gogo-Mode Tcp-Port-Check Delete

    configure slb gogo-mode tcp-port-check delete configure slb gogo-mode tcp-port-check delete configure slb gogo-mode <port number> tcp-port-check delete [ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | www | <TCP port number>] Description Deletes the specified layer 4 port.
  • Page 542 SLB Commands—“i” Series Switches Only Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 543: Configure Slb Gogo-Mode Tcp-Port-Check Timer

    configure slb gogo-mode tcp-port-check timer configure slb gogo-mode tcp-port-check timer configure slb gogo-mode <port number> tcp-port-check timer [ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | www | <TCP port number>] frequency <seconds>...
  • Page 544 SLB Commands—“i” Series Switches Only Example The following command configures GoGo mode FTP TCP port check for the group with port 29 as the master port with a frequency of 15 seconds and a timeout of 45 seconds: configure slb gogo-mode 29 tcp-port-check timer ftp frequency 15 timeout 45 History This command was first available in ExtremeWare 6.1.5.

  • Page 545: Configure Slb L4-Port

    configure slb L4-port configure slb L4-port configure slb L4-port [ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | wildcard | www | <TCP or UDP port number>] [treaper-timeout <seconds>...
  • Page 546 SLB Commands—“i” Series Switches Only History This command was first available in ExtremeWare 6.1. Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 547: Configure Slb Node Max-Connections

    configure slb node max-connections configure slb node max-connections configure slb node <ip address>:[ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | wildcard | www | <TCP or UDP port number>] max-connections <number>...
  • Page 548 SLB Commands—“i” Series Switches Only History This command was first available in ExtremeWare 6.1. Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 549: Configure Slb Node Ping-Check

    configure slb node ping-check configure slb node ping-check configure slb node <ip address> ping-check frequency <seconds> timeout <seconds> Description Overrides the global default frequency and timeout values for this node. Syntax Description ip address Specifies the IP address of the node. frequency Specifies the frequency of the ping check.

  • Page 550: Configure Slb Node Tcp-Port-Check

    SLB Commands—“i” Series Switches Only configure slb node tcp-port-check configure slb node <ip address>:[ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | wildcard | www | <TCP or UDP port number>] tcp-port-check frequency <seconds>...
  • Page 551 configure slb node tcp-port-check Example The following command sets the FTP TCP port check for the node with an IP address of 10.2.1.2 to a frequency of 30 seconds and a timeout of 90 seconds: configure slb node 10.2.1.2 : ftp tcp-port-check frequency 30 timeout 90 History This command was first available in ExtremeWare 6.1.

  • Page 552: Configure Slb Pool Add

    SLB Commands—“i” Series Switches Only configure slb pool add configure slb pool <pool name> add <ip address>:[ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | wildcard | www | <TCP or UDP port number>] {ratio <number>...
  • Page 553 configure slb pool add configure the ratio, use the smallest common denominator. For example, to configure a ratio of 25% and 75%, use ratios of 1 and 3, instead of 25 and 75. To configure a pool to use the ratio load balancing method, use the following command: configure slb pool <pool name>...

  • Page 554: Configure Slb Pool Delete

    SLB Commands—“i” Series Switches Only configure slb pool delete configure slb pool <pool name> delete <ip address>:[ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | wildcard | www | <TCP or UDP port number>] Description Deletes a node from a pool.
  • Page 555 configure slb pool delete History This command was first available in ExtremeWare 6.1. Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 556: Configure Slb Pool Lb-Method

    SLB Commands—“i” Series Switches Only configure slb pool lb-method configure slb pool <pool name> lb-method [least-connections | priority | ratio | round-robin] Description Configures the SLB load balancing method. Syntax Description pool name Specifies a pool. least-connections Specifies the least connections load balancing method. priority Specifies the priority load balancing method.

  • Page 557: Configure Slb Pool Member

    configure slb pool member configure slb pool member configure slb pool <pool name> member <ip address>:[ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | www | <TCP or UDP port number>] [ratio <number>...
  • Page 558 SLB Commands—“i” Series Switches Only Example The following command changes the priority of the FTP node with an IP address of 10.2.1.2 in the pool “ftp” to 2: configure slb pool ftp member 10.2.1.2 : ftp priority 2 History This command was first available in ExtremeWare 6.1. Platform Availability This command is available on all “i”...

  • Page 559: Configure Slb Proxy-Client-Persistence

    configure slb proxy-client-persistence configure slb proxy-client-persistence configure slb proxy-client-persistence [add | delete] <ip address>/<netmask> Description Configures a client subnet that should be treated as one persistent entity. Syntax Description ip address/netmask Specifies an IP address and netmask. Default Usage Guidelines Use this command to force all clients from the specified proxy array to connect to the same physical server.

  • Page 560: Configure Slb Vip

    SLB Commands—“i” Series Switches Only configure slb vip configure slb vip <vip name> unit [number] Description Configures the unit number for active-active failover. Syntax Description vip name Specifies a virtual server. unit Specifies a unit identifier on a virtual server. The range is 1 to 16. Default The default unit is 1.

  • Page 561: Configure Slb Vip Client-Persistence-Timeout

    The default is 3600. client-persistence-timeout Usage Guidelines Extreme Networks recommends that you specify a short client persistence timeout, because longer timeout values consume more memory. Example The following command configures the virtual server “ftp” with a client persistence timeout of 3000...

  • Page 562: Configure Slb Vip Max-Connections

    SLB Commands—“i” Series Switches Only configure slb vip max-connections configure slb vip <vip name> max-connections <number> Description Configures the maximum connections allowed to a particular virtual server. Syntax Description vip name Specifies a virtual server. max-connections Specifies the maximum number of connections allowed to a virtual server. The range is 0 to 999,999,999.

  • Page 563: Configure Slb Vip Service-Check Frequency

    configure slb vip service-check frequency configure slb vip service-check frequency configure slb vip <vip name> service-check frequency <seconds> timeout <seconds> Description Configures the layer 7 service check frequency and timeout for a particular virtual server. Syntax Description vip name Specifies a virtual server. frequency Specifies the frequency of the service check.

  • Page 564: Configure Slb Vip Service-Check Ftp

    Usage Guidelines This command automatically enables service checking. If you do not enter a password, you are prompted for the password twice. Extreme Networks recommends that you use a password. The FTP service check provides a more thorough check than ping check, because the FTP service check logs in to the service.

  • Page 565: Configure Slb Vip Service-Check Http

    The HTTP service check provides a more thorough check than ping check, because the HTTP service check connects to a specific URL and checks for a specific text string. Extreme Networks recommends that you create a specific URL dedicated to this check.
  • Page 566 SLB Commands—“i” Series Switches Only Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 567: Configure Slb Vip Service-Check Nntp

    configure slb vip service-check nntp configure slb vip service-check nntp configure slb vip <vip name> service-check nntp <newsgroup> Description Configures layer 7 NNTP service checking for a specific virtual server. Syntax Description vip name Specifies a virtual server. newsgroup Specifies a newsgroup. Default Usage Guidelines This command automatically enables service checking.

  • Page 568: Configure Slb Vip Service-Check Pop3

    Usage Guidelines This command automatically enables service checking. If you do not enter a password, you are prompted for the password twice. Extreme Networks recommends that you use a password. The POP3 service check provides a more thorough check than ping check, because the POP3 service check logs in to the service.

  • Page 569: Configure Slb Vip Service-Check Smtp

    configure slb vip service-check smtp configure slb vip service-check smtp configure slb vip <vip name> service-check smtp {<dns domain>} Description Configures layer 7 SMTP service checking for a specific virtual server. Syntax Description vip name Specifies a virtual server. dns domain Specifies the domain to check.

  • Page 570: Configure Slb Vip Service-Check Telnet

    Usage Guidelines This command automatically enables service checking. If you do not enter a password, you are prompted for the password twice. Extreme Networks recommends that you use a password. The telnet service check provides a more thorough check than ping check, because the telnet service check logs in to the service.

  • Page 571: Configure Vlan Slb-Type

    configure vlan slb-type configure vlan slb-type configure vlan <vlan name> slb-type [both | client | none | server] Description Marks a VLAN as either a server VLAN or a client VLAN. Syntax Description both Configures the VLAN as both a server and a client VLAN. client Configures the VLAN as a client VLAN.

  • Page 572: Create Flow-Redirect

    SLB Commands—“i” Series Switches Only create flow-redirect create flow-redirect <flow redirect> [any | tcp | tup | udp] destination [<ip address> / <mask> [ip-port <number> | src-ip-port <number>] | any] source [<ip address> / <mask> | any] Description Creates a flow redirection policy. Syntax Description flow redirect Specifies a flow redirection policy.
  • Page 573 create flow-redirect Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 574: Create Slb Pool

    SLB Commands—“i” Series Switches Only create slb pool create slb pool <pool name> {lb-method [least-connections | priority | ratio | round-robin]} Description Creates a server pool and optionally assigns a load-balancing method to the pool. Syntax Description pool name Specifies a pool. lb-method Specifies the load-balancing method.

  • Page 575: Create Slb Vip

    create slb vip create slb vip create slb vip <vip name> pool <pool name> mode [transparent | translation | port-translation] <ip address> {- <upper range>} : <L4 port> {unit <number>} Description Creates one or more new virtual servers. Syntax Description vip name Specifies a virtual server.

  • Page 576: Delete Flow-Redirect

    SLB Commands—“i” Series Switches Only delete flow-redirect delete flow-redirect <flow redirect> Description Deletes a flow redirection policy. Syntax Description flow redirect Specifies a flow redirection policy. Default Usage Guidelines To rename or modify a flow redirection policy, you must delete and recreate the flow redirection policy. Example The following command deletes a flow redirection policy named http: delete flow-redirect http...

  • Page 577: Delete Slb Pool

    delete slb pool delete slb pool delete slb pool [<pool name> | all] Description Deletes a server pool. Syntax Description pool name Specifies a pool. Specifies all pools. Default Usage Guidelines You must first delete all virtual servers before deleting the pool. To delete a virtual server, use the following command: delete slb vip Example...

  • Page 578: Delete Slb Vip

    SLB Commands—“i” Series Switches Only delete slb vip delete slb vip [<vip name> | all] Description Deletes one or all virtual servers. Syntax Description vip name Specifies a virtual server. Specifies all virtual servers. Default Usage Guidelines You must use this command to delete all virtual servers from a pool before deleting the pool. Example The following command deletes the virtual server named http_vip: delete slb vip http_vip...

  • Page 579: Disable Flow-Redirect

    disable flow-redirect disable flow-redirect disable flow-redirect [all | <flow redirect>] Description Disables flow redirection. Syntax Description Specifies all flow policies. flow redirect Specifies a single flow redirection policy. Default The default parameter is all. Flow redirection is disabled by default. Usage Guidelines When you create a new flow redirection policy, flow redirection is automatically enabled.

  • Page 580: Disable Slb

    SLB Commands—“i” Series Switches Only disable slb disable slb Description Disables SLB processing. Syntax Description This command has no arguments or variables. Default SLB is disabled by default. Usage Guidelines Disabling SLB causes the following to occur: • Closes all connections. •...

  • Page 581: Disable Slb 3Dns

    disable slb 3dns disable slb 3dns disable slb 3dns iquery-client Description Disables 3DNS support. Syntax Description This command has no arguments or variables. Default 3DNS is disabled by default. Usage Guidelines To enable 3DNS, use the following command: enable slb 3dns Example The following command disables 3DNS: disable slb 3dns iquery-client...

  • Page 582: Disable Slb Failover

    SLB Commands—“i” Series Switches Only disable slb failover disable slb failover Description Disables the SLB failover mechanism. Syntax Description This command has no arguments or variables. Default SLB failover is disabled by default. Usage Guidelines To enable SLB failover, use the following command: enable slb failover Example The following command disables SLB failover:...

  • Page 583: Disable Slb Failover Manual-Failback

    disable slb failover manual-failback disable slb failover manual-failback disable slb failover manual-failback Description Disables manual failback. Syntax Description This command has no arguments or variables. Default Manual failback is disabled by default. Usage Guidelines To enable manual failback, use the following command: enable slb failover manual-failback Example The following command disables manual failback:...

  • Page 584: Disable Slb Failover Ping-Check

    SLB Commands—“i” Series Switches Only disable slb failover ping-check disable slb failover ping-check Description Disables ping check to an external gateway. Syntax Description This command has no arguments or variables. Default Ping check is disabled by default. Usage Guidelines To enable ping check, use the following command: enable slb failover ping-check Example The following command disables ping check:...

  • Page 585: Disable Slb Global Synguard

    disable slb global synguard disable slb global synguard disable slb global synguard Description Disables the TCP SYN-guard feature. Syntax Description This command has no arguments or variables. Default SYN-guard is disabled by default. Usage Guidelines To enable SYN-guard, use the following command: enable slb global synguard Example The following command disables SYN-guard:...

  • Page 586: Disable Slb Gogo-Mode

    SLB Commands—“i” Series Switches Only disable slb gogo-mode disable slb gogo-mode <port number> {all} Description Disables GoGo mode processing. Syntax Description port number Specifies the GoGo mode master port. Disables all health checking. Default GoGo mode is disabled by default. Usage Guidelines Before you disable GoGo mode, disconnect the servers;...

  • Page 587: Disable Slb Gogo-Mode Ping-Check

    disable slb gogo-mode ping-check disable slb gogo-mode ping-check disable slb gogo-mode <port number> ping-check Description Disables layer 3 ping check for this GoGo mode group. Syntax Description port number Specifies the GoGo mode master port. Default GoGo mode ping check is disabled by default. Usage Guidelines To enable ping check for a GoGo mode group, use the following command: enable slb gogo-mode ping-check...

  • Page 588: Disable Slb Gogo-Mode Service-Check

    SLB Commands—“i” Series Switches Only disable slb gogo-mode service-check disable slb gogo-mode <port number> service-check [all | ftp | http | nntp | pop3 | smtp | telnet | <TCP port number>] Description Disables layer 7 service check for this GoGo mode group. Syntax Description port number Specifies the GoGo mode master port.

  • Page 589: Disable Slb Gogo-Mode Tcp-Port-Check

    disable slb gogo-mode tcp-port-check disable slb gogo-mode tcp-port-check disable slb gogo-mode <port number> tcp-port-check [all | ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | www | <TCP port number>] Description Disables layer 4 TCP port check for this GoGo mode group.
  • Page 590 SLB Commands—“i” Series Switches Only Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 591: Disable Slb L4-Port

    disable slb L4-port disable slb L4-port disable slb L4-port [all | ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | wildcard | www | <TCP or UDP port number>] Description Disables one or all SLB ports.
  • Page 592 SLB Commands—“i” Series Switches Only Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 593: Disable Slb Node

    disable slb node disable slb node disable slb node [all | <ip address> : [ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | wildcard | www | <TCP or UDP port number>]] {close-connections-now} Description Disables one or all nodes.
  • Page 594 SLB Commands—“i” Series Switches Only Example The following command disables all nodes and immediately closes all open connections: disable slb node all close-connections-now History This command was first available in ExtremeWare 6.1. Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 595: Disable Slb Node Ping-Check

    disable slb node ping-check disable slb node ping-check disable slb node [all | <ip address>] ping-check Description Disables layer 3 ping check. Syntax Description Specifies all nodes. ip address Specifies the IP address of the node. Default Ping check is disabled by default. Usage Guidelines Ping check is automatically enabled when a node is added to a pool.

  • Page 596: Disable Slb Node Tcp-Port-Check

    SLB Commands—“i” Series Switches Only disable slb node tcp-port-check disable slb node [all | <ip address> : [ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | wildcard | www | <TCP or UDP port number>]] tcp-port-check Description Disables layer 4 TCP port checking.
  • Page 597 disable slb node tcp-port-check Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 598: Disable Slb Proxy-Client-Persistence

    SLB Commands—“i” Series Switches Only disable slb proxy-client-persistence disable slb proxy-client-persistence Description Disables proxy client persistence. Syntax Description This command has no arguments or variables. Default Proxy client persistence is disabled by default. Usage Guidelines To enable proxy client persistence, use the following command: enable slb proxy-client-persistence Example The following command disables proxy client persistence:...

  • Page 599: Disable Slb Vip

    disable slb vip disable slb vip disable slb vip [all | <vip name> | ipaddress <ip address> : [ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | wildcard | www | <TCP or UDP port number>]] {close-connections-now} Description Disables one or all virtual servers.
  • Page 600 SLB Commands—“i” Series Switches Only Example The following command disables the virtual server named ftp_vip and closes all open connections: disable slb vip ftp_vip close-connections-now History This command was first available in ExtremeWare 6.1. Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 601: Disable Slb Vip Client-Persistence

    disable slb vip client-persistence disable slb vip client-persistence disable slb vip [all | <vip name>] client-persistence Description Disables client persistence. Syntax Description Specifies all virtual servers. vip name Specifies a virtual server. Default Client persistence is disabled by default. Usage Guidelines To enable client persistence, use the following command: enable slb vip client-persistence Example...

  • Page 602: Disable Slb Vip Service-Check

    SLB Commands—“i” Series Switches Only disable slb vip service-check disable slb vip [all | <vip name>] service-check Description Disables layer 7 service check. Syntax Description Specifies all virtual servers. vip name Specifies a virtual server. Default Service check is disabled by default. Usage Guidelines To enable service check, use the following command: enable slb vip service-check...

  • Page 603: Disable Slb Vip Sticky-Persistence

    disable slb vip sticky-persistence disable slb vip sticky-persistence disable slb vip [all | <vip name>] sticky-persistence Description Disables sticky persistence. Syntax Description Specifies all virtual servers. vip name Specifies a virtual server. Default Sticky persistence is disabled by default. Usage Guidelines Sticky persistence is available only on wildcard virtual servers;...

  • Page 604: Disable Slb Vip Svcdown-Reset

    SLB Commands—“i” Series Switches Only disable slb vip svcdown-reset disable slb vip [all | <vip name>] svcdown-reset Description Disables the svcdown-reset feature. Syntax Description Specifies all virtual servers. vip name Specifies a virtual server. Default The svcdown-reset feature is disabled by default. Usage Guidelines The svcdown-reset feature configures the switch to send TCP RST packets to both the clients and the virtual server if the virtual server fails a health-check.

  • Page 605: Enable Flow-Redirect

    enable flow-redirect enable flow-redirect enable flow-redirect [all | <flow redirect>] Description Enables flow redirection. Syntax Description Specifies all flow redirection policies. flow redirect Specifies a single flow redirection policy. Default The default parameter is all. Flow redirection is disabled by default. Usage Guidelines When you create a new flow redirection policy, flow redirection is automatically enabled.

  • Page 606: Enable Slb

    SLB Commands—“i” Series Switches Only enable slb enable slb Description Enables SLB processing. Syntax Description This command has no arguments or variables. Default SLB is disabled by default. Usage Guidelines This command activates the following functions for transparent, translational, and port translation modes: •...

  • Page 607: Enable Slb 3Dns

    enable slb 3dns enable slb 3dns enable slb 3dns iquery-client Description Enables 3DNS support. Syntax Description This command has no arguments or variables. Default 3DNS is disabled by default. Usage Guidelines The following 3DNS global balance modes are supported: • completion •...

  • Page 608: Enable Slb Failover

    SLB Commands—“i” Series Switches Only enable slb failover enable slb failover Description Enables SLB failover. Syntax Description This command has no arguments or variables. Default Failover is disabled by default. Usage Guidelines When SLB failover is enabled, the primary SLB switch automatically resumes primary status when it becomes active.

  • Page 609: Enable Slb Failover Manual-Failback

    enable slb failover manual-failback enable slb failover manual-failback enable slb failover manual-failback Description Enables manual failback. Syntax Description This command has no arguments or variables. Default Manual failback is disabled by default. Usage Guidelines When manual failback is enabled, the primary SLB switch does not automatically resume primary status until you use the following command: configure slb failover failback-now To disable manual failback, use the following command:...

  • Page 610: Enable Slb Failover Ping-Check

    SLB Commands—“i” Series Switches Only enable slb failover ping-check enable slb failover ping-check Description Enables ping check. Syntax Description This command has no arguments or variables. Default Ping check is disabled by default. Usage Guidelines To disable ping check, use the following command: disable slb failover ping-check Example The following command enables ping check:...

  • Page 611: Enable Slb Global Synguard

    enable slb global synguard enable slb global synguard enable slb global synguard Description Enables the TCP SYN-guard feature. Syntax Description This command has no arguments or variables. Default SYN-guard is disabled by default. Usage Guidelines To disable SYN-guard, use the following command: disable slb global synguard Example The following command enables SYN-guard:...

  • Page 612: Enable Slb Gogo-Mode

    SLB Commands—“i” Series Switches Only enable slb gogo-mode enable slb gogo-mode <port number> grouping <port list> Description Enables GoGo mode processing for a group of ports. Syntax Description port number Specifies the GoGo mode master port. port list Specifies a range or list of ports assigned to the group. Default GoGo mode is disabled by default.

  • Page 613: Enable Slb Gogo-Mode Ping-Check

    enable slb gogo-mode ping-check enable slb gogo-mode ping-check enable slb gogo-mode <port number> ping-check <ip address> Description Enables layer 3 ping check for the GoGo mode group. Syntax Description port number Specifies the GoGo mode master port. ip address Specifies an IP address to be pinged. Default GoGo mode ping check is disabled by default.

  • Page 614: Enable Slb Gogo-Mode Service-Check

    SLB Commands—“i” Series Switches Only enable slb gogo-mode service-check enable slb gogo-mode <port number> service-check [all | ftp | http | nntp | pop3 | smtp | telnet | <TCP port number>] Description Enables layer 7 service checking for the GoGo mode group. Syntax Description port number Specifies the GoGo mode master port.

  • Page 615: Enable Slb Gogo-Mode Tcp-Port-Check

    enable slb gogo-mode tcp-port-check enable slb gogo-mode tcp-port-check enable slb gogo-mode <port number> tcp-port-check [all | ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | www | <TCP port number>] Description Enables layer 4 TCP port check for the GoGo mode group.
  • Page 616 SLB Commands—“i” Series Switches Only Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 617: Enable Slb L4-Port

    enable slb L4-port enable slb L4-port enable slb L4-port [ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | wildcard | www | <TCP or UDP port number>] Description Enables an SLB port.
  • Page 618 SLB Commands—“i” Series Switches Only Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 619: Enable Slb Node

    enable slb node enable slb node enable slb node [all | <ip address> : [ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | wildcard | www | <TCP or UDP port number>]] Description Enables one or all nodes.
  • Page 620 SLB Commands—“i” Series Switches Only History This command was first available in ExtremeWare 6.1. Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 621: Enable Slb Node Ping-Check

    enable slb node ping-check enable slb node ping-check enable slb node [all | <ip address>] ping-check Description Enables layer 3 ping check. Syntax Description Specifies all nodes. ip address Specifies the IP address of the node. Default Ping check is enabled by default. Usage Guidelines Ping check is automatically enabled when a node is added to a pool.

  • Page 622: Enable Slb Node Tcp-Port-Check

    SLB Commands—“i” Series Switches Only enable slb node tcp-port-check enable slb node [all | <ip address> : [ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | wildcard | www | <TCP or UDP port number>]] tcp-port-check Description Enables layer 4 TCP port check.
  • Page 623 enable slb node tcp-port-check Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 624: Enable Slb Proxy-Client-Persistence

    SLB Commands—“i” Series Switches Only enable slb proxy-client-persistence enable slb proxy-client-persistence Description Enables proxy client persistence. Syntax Description This command has no arguments or variables. Default Proxy client persistence is disabled by default. Usage Guidelines To disable proxy client persistence, use the following command: disable slb proxy-client-persistence Example The following command enables proxy client persistence:...

  • Page 625: Enable Slb Vip

    enable slb vip enable slb vip enable slb vip [all | <vip name> | ipaddress <ip address> : [ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | wildcard | www | <TCP or UDP port number>]] Description Enables one or all virtual servers.
  • Page 626 SLB Commands—“i” Series Switches Only History This command was first available in ExtremeWare 6.1. Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 627: Enable Slb Vip Client-Persistence

    enable slb vip client-persistence enable slb vip client-persistence enable slb vip [all | <vip name>] client-persistence {netmask <netmask>} Description Enables client persistence. Syntax Description Specifies all virtual servers. vip name Specifies a virtual server. netmask Specifies a netmask. Default The default is disabled. Usage Guidelines To disable client persistence, use the following command: disable slb vip client-persistence...

  • Page 628: Enable Slb Vip Service-Check

    SLB Commands—“i” Series Switches Only enable slb vip service-check enable slb vip [all | <vip name>] service-check Description Enables layer 7 service check. Syntax Description Specifies all virtual servers. vip name Specifies a virtual server. Default Service check is disabled by default. Usage Guidelines The service checks are based on the following information: •...

  • Page 629: Enable Slb Vip Sticky-Persistence

    enable slb vip sticky-persistence enable slb vip sticky-persistence enable slb vip [all | ipaddress <ip address> | <vip name>] sticky-persistence {netmask <netmask>} Description Enables the sticky persistence feature and specifies the client address mask. Syntax Description Specifies all virtual servers. ip address Specifies an IP address.

  • Page 630: Enable Slb Vip Svcdown-Reset

    SLB Commands—“i” Series Switches Only enable slb vip svcdown-reset enable slb vip [all | <vip name>] svcdown-reset Description Enables svcdown-reset. Syntax Description Specifies all virtual servers. vip name Specifies a virtual server. Default The svcdown-reset feature is disabled by default. Usage Guidelines The svcdown-reset feature configures the switch to send TCP RST packets to both the clients and the virtual server if the virtual server fails a health-check.

  • Page 631: Show Flow-Redirect

    show flow-redirect show flow-redirect show flow-redirect <flow redirect> Description Displays the current configuration and statistics for flow redirection. Syntax Description flow redirect Specifies a flow redirection policy. Default Usage Guidelines If you do not specify a flow redirection policy, configuration and statistics for all flow redirection policies are displayed.
  • Page 632 SLB Commands—“i” Series Switches Only Service Checking: Displays the configured service check type. • • http • L4-port • nntp • ping • pop3 • smtp • telnet IP Address Displays the IP address of the next hop. State Displays the status of the next hop, either up or down. Flow Info Displays hardware mapping information.

  • Page 633: Show Slb 3Dns Members

    show slb 3dns members show slb 3dns members show slb 3dns members Description Displays the current connection information between the switch and the 3DNS query. Syntax Description This command has no arguments or variables. Default N/A. Usage Guidelines None. Example The following command displays the current 3DNS information: show slb 3dns members IP Address...

  • Page 634: Show Slb Connections

    SLB Commands—“i” Series Switches Only show slb connections show slb connections [ipaddress <ip address>: [ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | wildcard | www | <TCP or UDP port number>] | vip <vip name>] Description Displays information about current connections.
  • Page 635 show slb connections Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 636: Show Slb Esrp

    SLB Commands—“i” Series Switches Only show slb esrp show slb esrp Description Displays SLB configuration for ESRP. Syntax Description This command has no arguments or variables. Default Usage Guidelines None Example The following command displays the current ESRP configuration: show slb esrp Following is the output from this command: VLAN Name SLB Unit Status SLB Unit(s)

  • Page 637: Show Slb Failover

    show slb failover show slb failover show slb failover Description Displays SLB failover configuration and status. Syntax Description This command has no arguments or variables. Default Usage Guidelines command also displays SLB failover configuration and status. show slb global Example The following command displays the current SLB failover configuration and status: show slb failover Following is the output from this command:...
  • Page 638 SLB Commands—“i” Series Switches Only Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 639: Show Slb Global

    show slb global show slb global show slb global Description Displays the current SLB global configuration information. Syntax Description This command has no arguments or variables. Default Usage Guidelines Displays the following: • Global enable/disable mode • Global modes • Default settings for health checker •...
  • Page 640 SLB Commands—“i” Series Switches Only Password: (not shown) SMTPDomain: "mydomain.com" NNTP Newsgroup: "ebusiness" User: anonymous Password: (not shown) POP3User: anonymous Password: (not shown) SLB Failover Configuration: Failover: Enabled Local unit ID: 1 Local IP address: 10.1.1.1 Remote IP address: 10.1.1.2 TCP port number: 1028 Remote Alive frequency: 1 Remote Dead frequency: 2...

  • Page 641: Show Slb Gogo-Mode

    show slb gogo-mode show slb gogo-mode show slb gogo-mode <port number> {configuration} Description Displays GoGo mode ping check, TCP port check, and service check status. Syntax Description port number Specifies the GoGo mode master port. configuration Displays configuration instead of status. Default Usage Guidelines If you do not specify a master port, status is displayed for all GoGo mode groups with health checks...

  • Page 642: Show Slb L4-Port

    SLB Commands—“i” Series Switches Only show slb L4-port show slb L4-port [ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | wildcard | www | <TCP or UDP port number>] Description Displays the SLB configuration for the active layer 4 ports.
  • Page 643 show slb L4-port Platform Availability This command is available on all “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 644: Show Slb Node

    SLB Commands—“i” Series Switches Only show slb node show slb node {<ip address> [ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | wildcard | www | <TCP or UDP port number>]} Description Displays node configuration and status.
  • Page 645 show slb node Flags: E - Enable, U - Up, R - IP Route Up, H - Health check enabled, P - Health check passed, ! - VLAN not configured with "slb-type" History This command was first available in ExtremeWare 6.1. Platform Availability This command is available on all “i”...

  • Page 646: Show Slb Persistence

    SLB Commands—“i” Series Switches Only show slb persistence show slb persistence Description Displays persistence status of existing clients. Syntax Description This command has no arguments or variables. Default Usage Guidelines None Example The following command displays the current persistence status: show slb persistence History This command was first available in ExtremeWare 6.1.

  • Page 647: Show Slb Pool

    show slb pool show slb pool show slb pool <pool name> Description Displays the current SLB pool configuration and status. Syntax Description pool name Specifies a pool. Default Usage Guidelines If you do not specify a pool, configuration and status for all pools is displayed. Example The following command displays the current pool configuration and statistics for all pools, currently “rr_pool”...

  • Page 648: Show Slb Stats

    SLB Commands—“i” Series Switches Only show slb stats show slb stats [pool <pool name> | vip <vip name>] Description Displays the current SLB pool connection status. Syntax Description pool name Specifies a pool. vip name Specifies a virtual server. Default Usage Guidelines If you specify but do not specify a specific pool, status for all pools is displayed.

  • Page 649: Show Slb Vip

    show slb vip show slb vip show slb vip [<vip name> | ipaddress <ip address> : [ftp | http | https | imap4 | ldap | nntp | pop3 | smtp | socks | telnet | tftp | web | wildcard | www | <TCP or UDP port number>]] {detail} Description Displays the current virtual server configuration and statistics.
  • Page 650 SLB Commands—“i” Series Switches Only ratio_vip 4.1.1.100 EUA-----ratio_po0/3 rr_vip 10.1.1.10 EUA----!rr_pool0/3 Modes: TP - Transparent, TL - Translational, PT - Port Translational Automatically Exported via: PA - Proxy Arp, HR - Host Route, SR - Subnet Route Flags: E - Enable, U - Up, A - Active Unit, H - Health-Check Enabled,...

  • Page 651: Unconfigure Slb All

    unconfigure slb all unconfigure slb all unconfigure slb all Description Resets SLB global defaults and clears the SLB configuration. Syntax Description This command has no arguments or variables. Default Usage Guidelines This command does not delete nodes, pools, or virtual servers. To delete all nodes and pools, use the following command: delete slb pool all To delete all virtual servers, use the following command:...

  • Page 652: Unconfigure Slb Gogo-Mode Health-Check

    SLB Commands—“i” Series Switches Only unconfigure slb gogo-mode health-check unconfigure slb gogo-mode <port number> health-check Description Disables and deletes all the ping check, TCP port check, and service check configurations for this GoGo mode group. Syntax Description port number Specifies the GoGo mode master port. Default Usage Guidelines None...

  • Page 653: Unconfigure Slb Gogo-Mode Service-Check

    unconfigure slb gogo-mode service-check unconfigure slb gogo-mode service-check unconfigure slb gogo-mode <port number> service-check [all | ftp | http | nntp | pop3 | smtp | telnet | <TCP port number>] Description Disables and deletes the GoGo mode service check configuration. Syntax Description port number Specifies the GoGo mode master port.

  • Page 654: Unconfigure Slb Vip Service-Check

    SLB Commands—“i” Series Switches Only unconfigure slb vip service-check unconfigure slb vip [all | <vip name>] service-check Description Disables and deletes the service check configuration. Syntax Description Specifies all virtual servers. vip name Specifies a virtual server. Default Usage Guidelines None Example The following command disables and deletes the FTP service-check configurations for the virtual server...
  • Page 655 Commands for Status Monitoring and Statistics This chapter describes commands for: • Configuring and managing the Event Management System and logging • Enabling and disabling NetFlow flow statistics collection (“i” series platforms only) • Configuring flow-collection port and filtering options (“i” series platforms only) •...
  • Page 656 Commands for Status Monitoring and Statistics display or telnet session. In addition to maintaining an internal log, the switch supports remote logging by way of the UNIX syslog host facility. NetFlow Statistics—“i” Series Platforms Only NetFlow flow statistics provide a way for a switch to capture and export traffic classification or precedence information as data traverses, or flows across, portions of a network.

  • Page 657: Clear Counters

    clear counters clear counters clear counters Description Clears all switch statistics and port counters, including port packet statistics, bridging statistics, IP statistics, log event counters, and MPLS statistics. Syntax Description This command has no arguments or variables. Default Usage Guidelines You should view the switch statistics and port counters before you clear them.

  • Page 658: Clear Log

    Commands for Status Monitoring and Statistics clear log For the “i” series switches: clear log {diag-status | error-led | static | messages [memory-buffer | nvram]} For the “e” series switches: clear log {diag-status | static | messages [memory-buffer | nvram]} Description Clears the log database.
  • Page 659 clear log Example The following command clears all log messages, from the NVRAM: clear log static History This command was first available in ExtremeWare 2.0. option was added in ExtremeWare 7.0.0. diag-status option was added in ExtremeWare 7.1.0 error-led option was added in ExtremeWare 7.1.0 messages This command was added to the Summit “e”...

  • Page 660: Clear Log Counters

    Commands for Status Monitoring and Statistics clear log counters clear log counters {<event condition> | [all | <event component>] {severity <severity> {only}}} Description Clears the incident counters for events. Syntax Description event condition Specifies the event condition counter to clear. Specifies that all events counters are to be cleared.
  • Page 661 clear log counters History This command was first available in ExtremeWare 7.1.0. This command was added to the Summit “e” series of switches in ExtremeWare 7.2e. Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 662: Clear Log Diag Error

    Specifies the slot where the I/O module is installed. Default Usage Guidelines Use this command only at the direction of Extreme Networks personnel. Extreme Networks support personnel can clear the Alpine diagnostics failures from the NVRAM using the following command: clear log diag error <slot number>...

  • Page 663: Clear Log Diag Remap

    Specifies the slot where the I/O module is installed. Default Usage Guidelines Use this command only at the direction of Extreme Networks personnel. Extreme Networks support personnel can clear the packet memory diagnostics failures from the EEPROM using the following command: clear log diag remap <slot number>...

  • Page 664: Clear Transceiver-Test

    Commands for Status Monitoring and Statistics clear transceiver-test clear transceiver-test Description Clears (resets) the transceiver test statistics. NOTE This command is available only on the “i” series modular switches. Syntax Description This command has no arguments or variables. Default Usage Guidelines To display the transceiver test statistics, use the command.
  • Page 665 clear transceiver-test Platform Availability This command is available on “i” series modular switches only. ExtremeWare 7.5 Command Reference Guide...

  • Page 666: Configure Flowstats Export Add Port

    Commands for Status Monitoring and Statistics configure flowstats export add port configure flowstats export <group#> add [<ipaddress> | <hostname>] <udp_port> Description Adds a flow-collector device to an export group to which NetFlow datagrams are exported. NOTE This command is available only on the “i” series switches. Syntax Description group# Specifies the export group to which the specified flow-collector device should be added.
  • Page 667 configure flowstats export add port History This command was first available in ExtremeWare 6.2. Platform Availability This command is available only on the “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 668: Configure Flowstats Export Delete Port

    Commands for Status Monitoring and Statistics configure flowstats export delete port configure flowstats export <group#> delete [<ipaddress> | <hostname>] <udp_port> Description Removes a flow-collector device from an export group to which NetFlow datagrams are exported. NOTE This command is available only on the “i” series switches. Syntax Description group# Specifies the export group to which the specified flow-collector device belongs.

  • Page 669: Configure Flowstats Filter Ports

    configure flowstats filter ports configure flowstats filter ports configure flowstats filter <filter#> {aggregation} {export <group#>} ports <portlist> [ingress | egress] <filterspec> Description Configures a flow record filter for the specified ports. NOTE This command is available only on the “i” series switches. Syntax Description filter# The filter# parameter is an integer in the range from 1 to 8 that identifies the filter being...
  • Page 670 Commands for Status Monitoring and Statistics Each Ethernet port supports up to eight filters for ingress flows. Conceptually, the filters work by ANDing the contents of each of the five components of a forwarded flow with the associated masks from the first defined filter (filter #1). Statistics are maintained if the results of the AND operations match the configured filter values for all fields of the sequence.

  • Page 671: Configure Flowstats Source

    configure flowstats source configure flowstats source configure flowstats source ipaddress <ipaddress> Description Configures the IP address that is to be used as the source IP address for NetFlow datagrams to be exported. NOTE This command is available only on the “i” series switches. Syntax Description ipaddress Specifies the IP address of a VLAN to be used as the source address for the NetFlow datagrams.

  • Page 672: Configure Flowstats Timeout Ports

    Commands for Status Monitoring and Statistics configure flowstats timeout ports configure flowstats timeout <minutes> ports [<portlist> | all] Description Configures the timeout value for flow records on the specified ports. NOTE This command is available only on the “i” series switches. Syntax Description minutes Specifies the number of minutes to use in deciding when to export flow records.

  • Page 673: Configure Log Display

    configure log display configure log display configure log display {<severity>} Description Configures the real-time log display. Syntax Description severity Specifies a message severity. Severities include critical, error, warning, notice, info, debug-summary, debug-verbose, and debug-data. Default If not specified, messages of all severities are displayed on the console display. Usage Guidelines You must enable the log display before messages are displayed on the log display.
  • Page 674 Commands for Status Monitoring and Statistics Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 675: Configure Log Filter Events

    configure log filter events configure log filter events configure log filter <filter name> [add | delete] {exclude} events [<event condition> | [all | <event component>] {severity <severity> {only}}] Description Configures a log filter by adding or deleting a specified set of events. Syntax Description filter name Specifies the filter to configure.
  • Page 676 Commands for Status Monitoring and Statistics depending on whether the keyword was used. Subsequent filter items on the list are compared exclude if necessary. If the list of filter items has been exhausted with no match, the incident is excluded. Events, Components, and Subcomponents.
  • Page 677 configure log filter events As another example, a new exclude filter item may not need to be added if no current include filter items contain any of the events described in the exclude statement. To illustrate, suppose a new filter were created and configured as follows: create log filter myFilter configure log filter myFilter add events bgp.keepalive severity error only...

  • Page 678: Configure Log Filter Events Match

    Commands for Status Monitoring and Statistics configure log filter events match configure log filter <filter name> [add | delete] {exclude} events [<event condition> | [all | <event component>] {severity <severity> {only}}] [match | strict-match] <type> <value> {and <type> <value> ...} Description Configures a log filter by adding or deleting a specified set of events and specific set of match parameter values.
  • Page 679 configure log filter events match definitions (the event text and parameter types). The syntax for the parameter types (represented by <type> in the command syntax above) is: [bgp [neighbor | routerid] <ip address> | eaps <eaps domain name> | {destination | source} [ipaddress <ip address> | L4-port | mac-address ] | {egress | ingress} [slot <slot number>...
  • Page 680 Commands for Status Monitoring and Statistics Multiple Match Commands. Multiple commands are logically configure log add events match ORed together. For example, the following commands define a filter that allows layer 2 bridging incidents with a source MAC address of one of three possible values: create log filter bridgeFilter configure log bridgeFilter add events bridge severity notice match source mac-address 00:11:12:13:14:15...
  • Page 681 configure log filter events match To see a list of event condition definitions, use the following command: show log events To see the current configuration of a filter, use the following command: show log configuration filter <filter name> Example By default, all log targets are associated with the built-in filter called DefaultFilter. Therefore, the most straightforward way to send additional messages to a log target is to modify DefaultFilter.

  • Page 682: Configure Log Filter Set Severity

    Commands for Status Monitoring and Statistics configure log filter set severity configure log filter <filter name> set severity <severity> events [<event component> | all ] Description Sets the severity level of an existing filter item. Syntax Description filter name Specifies the filter to configure. severity Specifies the severity level to send.
  • Page 683 configure log filter set severity To see the current configuration of a filter, use the following command: show log configuration filter Example To change the severity level of the filter item added with this command: configure log filter bgpFilter2 add events bgp.keepalive severity notice use the following command: configure log filter bgpFilter2 set severity info events bgp.keepalive History...

  • Page 684: Configure Log Filter Set Severity Match

    Commands for Status Monitoring and Statistics configure log filter set severity match configure log filter <filter name> set severity <severity> events [<event condition> | [all | <event component>]] [match | strict-match] <type> <value> {and <type> <value> ...} Description Sets the severity level of an existing filter item. Syntax Description filter name Specifies the filter to configure.
  • Page 685 configure log filter set severity match source ipaddress 10.1.2.0/24 Using the single command eliminates the possibility of missing an event of interest between the separate commands. delete See the command on page 775 for a detailed description of severity levels. show log To see the current configuration of a target, use the following command: show log configuration target {console-display | memory-buffer | nvram | session |...

  • Page 686: Configure Log Target Filter

    Commands for Status Monitoring and Statistics configure log target filter configure log target [console-display | memory-buffer | nvram | session | syslog [<host name/ip> {: <udp-port>} [local0 ... local7]]] filter <filter name> {severity <severity> {only}} Description Associates a filter to a target. Syntax Description target Specifies the device to send the log entries.
  • Page 687 configure log target filter Table 14: Default Target Log Characteristics Target Enabled Severity Level Pre-7.1.0 Command to Set Log Severity console display no info configure log display {<severity>} memory buffer debug-data NVRAM warning session info syslog debug-data configure syslog add <host name/ip> {: <udp-port>} [local0...

  • Page 688: Configure Log Target Format

    Commands for Status Monitoring and Statistics configure log target format configure log target [console-display | memory-buffer | nvram | session | syslog [<host name/ip> {:<udp-port>} [local0 ... local7]]] format [date [dd-mm-yyyy | dd-Mmm-yyyy | mm-dd-yyyy | Mmm-dd | yyyy-mm-dd | none] | host-name [on | off] | event-name [component | condition | none | subcomponent] | priority [on | off] | process-id [on | off] | process-name [on | off] | sequence-number [on | off] | severity [on | off] |...
  • Page 689 configure log target format • severity—on • event-name—condition • host-name—off • priority—off • tag-id—off • tag-name—off • sequence-number—off • process-name—off • process-id—off • source-function—off • source-line—off The following defaults apply to syslog targets (per RFC 3164): • timestamp—seconds • date—mmm-dd •...
  • Page 690 Commands for Status Monitoring and Statistics Timestamps. A timestamp refers to the time an event occurred. Timestamps can be output either in seconds, as described in RFC 3164 (for example, “13:42:56”), or in hundredths of a second (for example, “13:42:56.98”). They can also be suppressed altogether. To display timestamps as hh:mm:ss, use the keyword;...
  • Page 691 configure log target format Process Name. For providing detailed information to technical support, the (internal) ExtremeWare task names of the applications detecting the events can be displayed by specifying process-name on suppressed by specifying . The default setting is process-name off process-name off Process ID.

  • Page 692: Configure Log Target Match

    Commands for Status Monitoring and Statistics configure log target match configure log target [console-display | memory-buffer | nvram | session | syslog [<host name/ip> {: <udp-port>} [local0 ... local7]]] match [any |<match-expression>] Description Associates a match expression to a target. Syntax Description console-display Specifies the console display.
  • Page 693 configure log target match Example The following command sends log messages to the current session if they pass the current filter and severity level and contain the string “user5”: configure log target session match user5 History This command was first available in ExtremeWare 7.1.0. This command was added to the Summit “e”...

  • Page 694: Configure Log Target Severity

    Commands for Status Monitoring and Statistics configure log target severity configure log target [console-display | memory-buffer | nvram | session | syslog [<host name/ip> {: <udp-port>} [local0 ... local7]]] {severity <severity> {only}} Description Sets the severity level of messages sent to the target. Syntax Description console-display Specifies the console display.
  • Page 695 configure log target severity Example The following command sends log messages to the current session that pass the current filter at a severity level of info or greater: configure log target session severity info History This command was first available in ExtremeWare 7.1.0. This command was added to the Summit “e”...

  • Page 696: Configure Packet-Mem-Scan-Recovery-Mode

    Commands for Status Monitoring and Statistics configure packet-mem-scan-recovery-mode configure packet-mem-scan-recovery-mode [offline | online] [msm-a | msm-b | <slot number>] Description Configures packet memory scanning and the recovery mode setting on a BlackDiamond module. NOTE This command is available only on the BlackDiamond switches. Syntax Description offline Specifies that a faulty BlackDiamond module is taken offline and kept offline if one of the...
  • Page 697 configure packet-mem-scan-recovery-mode Example The following command enables packet memory scanning on slot 1, and specifies that the module be taken offline: configure packet-mem-scan-recovery mode offline slot 1 The following command enables packet memory scanning on the MSM module in slot B, and specifies that the module be kept online configure packet-mem-scan-recovery mode online slot msm-b History...

  • Page 698: Configure Sflow Agent

    Commands for Status Monitoring and Statistics configure sflow agent configure sflow agent <ip-address> Description Configures the sFlow agent source IP address used in the sFlow UDP datagrams sent to the sFlow collector. NOTE This command is available only on the “i” series switches. Syntax Description ip-address Specifies the IP address from which sFlow data is sent on the switch.

  • Page 699: Configure Sflow Backoff-Threshold

    configure sflow backoff-threshold configure sflow backoff-threshold configure sflow backoff-threshold <rate> Description Configures the maximum number of packets sent to the sFlow collector per second. NOTE This command is available only on the “i” series switches. Syntax Description rate Specifies the maximum number of packets sent to the sFlow collector per second. The range is 100 - 5000 Default The default is 50.
  • Page 700 Commands for Status Monitoring and Statistics Platform Availability This command is available only on the “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 701: Configure Sflow Collector

    configure sflow collector configure sflow collector configure sflow collector <ip-address> port <udp-port> Description Configures the IP address and UDP port number identifying the sFlow collector. NOTE This command is available only on the “i” series switches. Syntax Description ip-address Specifies the IP address to send the sFlow data. udp-port Specifies the UDP port number to send the sFlow data.
  • Page 702 Commands for Status Monitoring and Statistics Platform Availability This command is available only on the “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 703: Configure Sflow Poll-Interval

    configure sflow poll-interval configure sflow poll-interval configure sflow poll-interval <seconds> Description Configures the sFlow counter polling interval at which the statistics counter values are sent to the sFlow collector. NOTE This command is available only on the “i” series switches. Syntax Description seconds Specifies the number of seconds between polling each counter.

  • Page 704: Configure Sflow Sample-Rate

    Commands for Status Monitoring and Statistics configure sflow sample-rate configure sflow sample-rate <number> Description Configures the sample rate at which the sFlow agent collects network traffic samples. NOTE This command is available only on the “i” series switches. Syntax Description number Specifies the fraction (1/number) of packets to be sampled.

  • Page 705: Configure Sys-Health-Check Alarm-Level

    configure sys-health-check alarm-level configure sys-health-check alarm-level configure sys-health-check alarm-level [log | system-down | traps | default] Description Configures the alarm response for the system health checker. NOTE This command is available only on the Alpine and the Summit “i” series switches. Syntax Description Posts a CRIT message to the log.
  • Page 706 Commands for Status Monitoring and Statistics option configures the number of times the system health checker attempts to auto-recovery automatically reset a faulty module and bring it online. If the system health checker fails more than the configured number of attempts, it sets the module to card-down. NOTE This threshold applies only to BlackDiamond I/O modules.
  • Page 707 configure sys-health-check alarm-level To view the failure messages, use the command. show diagnostics If you configure the system health check mode to and no new errors are detected, the device offline scanned now remains online. This behavior is identical to the current behavior if you use the command.

  • Page 708: Configure Sys-Health-Check Auto-Recovery

    Commands for Status Monitoring and Statistics configure sys-health-check auto-recovery configure sys-health-check auto-recovery <number> [offline | online] Description Configures the auto-recovery function of the system health checker. NOTE This command is available only on the “i” series switches. Syntax Description number Specifies the number of times that the health checker attempts to auto-recover a faulty module.
  • Page 709 configure sys-health-check auto-recovery In the BlackDiamond switches, the option configures the number of times the system auto-recovery health checker attempts to automatically reset a faulty module and bring it online. If the system health checker fails more than the configured number of attempts, it sets the module to card-down. This threshold applies only to BlackDiamond I/O modules.
  • Page 710 Commands for Status Monitoring and Statistics If the faulty module is a master MSM, the slave MSM automatically becomes the master and sets the faulty MSM to . The new master MSM re-initializes and brings up all the I/O modules. card-down If the faulty module is a master MSM and there is no slave MSM, the system continues operation in a “limited commands”...

  • Page 711: Configure Sys-Health-Check Scan Recovery

    Reset module and run diagnostics (remap). Usage Guidelines Extreme Networks support personnel can configure the action taken by the system health check if diagnostics are run or if checksum errors trigger diagnostics. If diagnostics are run or triggered in previous releases of ExtremeWare, the module is reset and diagnostics are run. Support personnel can...
  • Page 712 Commands for Status Monitoring and Statistics History This command was first available in ExtremeWare 7.2.0b25. Platform Availability This command is only available on “i” series switches. ExtremeWare 7.5 Command Reference Guide...

  • Page 713: Configure Sys-Recovery-Level

    configure sys-recovery-level configure sys-recovery-level For the “i” series switches: configure sys-recovery-level [none | [all | critical] [msm-failover | reboot | shutdown | system-dump [maintenance-mode | msm-failover | reboot | shutdown]] For the “e” series switches: configure sys-recovery-level [none | [all | critical] [reboot ] Description Configures a recovery option for instances where an exception occurs in ExtremeWare.
  • Page 714 Commands for Status Monitoring and Statistics For ExtremeWare 6.1, the system always reboots after a task exception when the system recovery level is specified as critical For ExtremeWare 6.2 or later, you must specify whether the system should shut down or reboot upon a task exception if the recovery level is critical For BlackDiamond Switches.

  • Page 715: Configure Syslog Add

    configure syslog add configure syslog add configure syslog {add} <host name/ip> {: <udp-port>} [local0 ... local7] {<severity>} Description Configures the remote syslog server host address, and filters messages to be sent to the remote syslog target. Syntax Description host name/ip Specifies the remote syslog server host name or IP address.
  • Page 716 Commands for Status Monitoring and Statistics History This command was first available in ExtremeWare 2.0. This command was added to the Summit “e” series of switches in ExtremeWare 7.1e. Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 717: Configure Syslog Delete

    configure syslog delete configure syslog delete configure syslog delete <host name/ip> {: <udp-port>} [local0 ... local7] Description Deletes a remote syslog server address. Syntax Description host name/ip Specifies the remote syslog server host name or IP address. udp-port Specifies the UDP port number for the syslog target. local0 ...

  • Page 718: Configure Transceiver-Test Failure-Action

    Commands for Status Monitoring and Statistics configure transceiver-test failure-action configure transceiver-test failure-action [log | sys-health-check] Description Configures the action the switch takes if too many failures are detected within the specified window. NOTE This command is available only on modular switches. Syntax Description Specifies that messages are sent to the syslog.
  • Page 719 configure transceiver-test failure-action The default for this command was changed to in ExtremeWare 6.2.2b134. This command was not supported in ExtremeWare 7.0. This command is supported in ExtremeWare 7.1.0. Platform Availability This command is available only on modular switches. ExtremeWare 7.5 Command Reference Guide...

  • Page 720: Configure Transceiver-Test Period

    Use this feature when the switch can be brought off-line. Configuring the transceiver test period to 11 seconds or less can affect system performance; therefore, Extreme Networks does not recommend changing the default transceiver test period. The default is adequate for most networks.

  • Page 721: Configure Transceiver-Test Threshold

    Three errors Usage Guidelines Use this feature when the switch can be brought off line. Extreme Networks does not recommend changing the default transceiver test threshold parameter. The default parameter is adequate for most networks. Example The following command configures the switch to accept 4 errors before an action is taken:...

  • Page 722: Configure Transceiver-Test Window

    Extreme Networks does not recommend changing the default transceiver test window parameter. The default parameter is adequate for most networks. Example The following command configures the switch to check for errors within the last seven 20-second...

  • Page 723: Create Log Filter

    create log filter create log filter create log filter <name> {copy <filter name>} Description Create a log filter with the specified name. Syntax Description name Specifies the name of the filter to create. copy Specifies that the new filter is to be copied from an existing one. filter name Specifies the existing filter to copy.
  • Page 724 Commands for Status Monitoring and Statistics Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 725: Delete Log Filter

    delete log filter delete log filter delete log filter [<filter name> | all] Description Delete a log filter with the specified name. Syntax Description filter name Specifies the filter to delete. Specifies that all filters, except DefaultFilter, are to be deleted Default Usage Guidelines This command deletes the specified filter, or all filters except for the filter DefaultFilter.

  • Page 726: Disable Cli-Config-Logging

    Commands for Status Monitoring and Statistics disable cli-config-logging disable cli-config-logging Description Disables the logging of CLI configuration commands to the switch Syslog. Syntax Description This command has no arguments or variables. Default Enabled Usage Guidelines command discontinues the recording of all switch configuration disable cli-config-logging changes and their sources that are made using the CLI via telnet or the local console.

  • Page 727: Disable Flowstats

    disable flowstats disable flowstats disable flowstats Description Disables the flow statistics feature on the switch. NOTE This command is available only on the “i” series switches. Syntax Description This command has no arguments or variables. Default Disabled Usage Guidelines When this feature is disabled, no flow records are exported. Example The following command disables the NetFlow statistics feature on this switch: disable flowstats...

  • Page 728: Disable Flowstats Filter Ports

    Commands for Status Monitoring and Statistics disable flowstats filter ports disable flowstats filter <filter#> ports <portlist> {ingress | egress} Description Disables a specified flow record filter for the specified ports. NOTE This command is available only on the “i” series switches. Syntax Description filter# Specifies the flow record filter that should be disabled.
  • Page 729 disable flowstats filter ports History This command was first available in ExtremeWare 6.1.5b20 for the PoS module only. This command was modified in ExtremeWare 6.2 to support all “i” series platforms. Platform Availability This command is available only on the “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 730: Disable Flowstats Ping-Check

    Commands for Status Monitoring and Statistics disable flowstats ping-check disable flowstats ping-check {<group#> | all} Description Disables the flow statistics ping-check function for a specified group of collector devices. NOTE This command is available only on the “i” series switches. Syntax Description group# Specifies the export group for which the ping-check function should be disabled.

  • Page 731: Disable Flowstats Ports

    disable flowstats ports disable flowstats ports disable flowstats ports <portlist> Description Disables the flow statistics function on the specified ports. NOTE This command is available only on the “i” series switches. Syntax Description portlist Specifies a list of ports or slots and ports for which the flowstats function should be disabled. May be in the form 1, 2, 3-5, 2:5, 2:6-2:8.

  • Page 732: Disable Log Debug-Mode

    Commands for Status Monitoring and Statistics disable log debug-mode disable log debug-mode Description Disables debug mode. The switch stops logging events of severity debug-summary, debug-verbose, and debug-data. Syntax Description This command has no arguments or variables. Default Disabled Usage Guidelines This command disables debug mode.

  • Page 733: Disable Log Display

    disable log display disable log display disable log display Description Disables the sending of messages to the console display. Syntax Description This command has no arguments or variables. Default Disabled Usage Guidelines If the log display is disabled, log information is no longer written to the serial console. This command setting is saved to FLASH and determines the initial setting of the console display at boot-up.

  • Page 734: Disable Log Target

    Commands for Status Monitoring and Statistics disable log target disable log target [console-display | memory-buffer | nvram | session | syslog [<host name/ip> {:<udp-port>} [local0 ... local7]]] Description Stop sending log messages to the specified target. Syntax Description console-display Specifies the console display. memory-buffer Specifies the switch memory buffer.
  • Page 735 disable log target Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 736: Disable Rmon

    Commands for Status Monitoring and Statistics disable rmon disable rmon Description Disables the collection of RMON statistics on the switch. Syntax Description This command has no arguments or variables. Default By default, RMON is disabled. However, even when RMON is disabled, the switch responds to RMON queries and sets for alarms and events.

  • Page 737: Disable Sflow

    disable sflow disable sflow disable sflow Description Globally disables sFlow statistical packet sampling. NOTE This command is available only on the “i” series switches. Syntax Description This command has no arguments or variables. Default Disabled Usage Guidelines This command disables sFlow globally on the switch. This command does not disable sFlow if it is enabled on individual ports.

  • Page 738: Disable Sflow Backoff-Threshold

    Commands for Status Monitoring and Statistics disable sflow backoff-threshold disable sflow backoff-threshold Description Disables the sFlow backoff-threshold feature, which limits the maximum number of packets sent to the sFlow collector per second. NOTE This command is available only on the “i” series switches. Syntax Description This command has no arguments or variables.

  • Page 739: Disable Sflow Ports

    disable sflow ports disable sflow ports disable sflow ports [<portlist> | all] Description Disables sFlow statistical packet sampling on a particular list of ports. NOTE This command is available only on the “i” series switches. Syntax Description portlist Specifies a list of ports or slots and ports. May be in the form 1, 2, 3-5, 2:5, 2:6-2:8. Applies the command to all ports.

  • Page 740: Disable Sys-Health-Check

    Commands for Status Monitoring and Statistics disable sys-health-check disable sys-health-check Description Disables the BlackDiamond system health checker. NOTE This command is available only on the BlackDiamond switches. Syntax Description This command has no arguments or variables. Default Enabled Usage Guidelines If the system health checker is disabled, it does not test I/O modules, MSM modules, and the backplane for system faults.

  • Page 741: Disable Syslog

    disable syslog disable syslog disable syslog Description Disables logging to all remote syslog server targets. Syntax Description This command has no arguments or variables. Default Disabled Usage Guidelines Disables logging to all remote syslog server targets, but not to the switch targets. This setting is saved in FLASH, and will be in effect upon boot-up.

  • Page 742: Disable Temperature-Logging

    Commands for Status Monitoring and Statistics disable temperature-logging disable temperature-logging Description Stops recording the celsius system temperature to the syslog for the BlackDiamond and Alpine systems. (The temperature is recorded in degrees celsius.) NOTE This command is available only on modular switches. Syntax Description This command has no arguments or variables.
  • Page 743 disable temperature-logging Platform Availability This command is available on modular switches only. ExtremeWare 7.5 Command Reference Guide...

  • Page 744: Disable Transceiver-Test

    Commands for Status Monitoring and Statistics disable transceiver-test For an Alpine switch: disable transceiver-test [all | slot <slot number> {backplane} ] For a BlackDiamond switch: disable transceiver-test [all | slot <slot number> | msm-a | msm-b] Description Disables the integrity testing of the transceivers used for communication between the ASICs and the CPU on an MSM or an SMMi module.
  • Page 745 disable transceiver-test slot 4 GM4X Operational MAC 2b81b BPLNE SMMI Operational UART 2b81a BPLNE SMMI Operational FLASH 2b81a BPLNE SMMI Operational SRAM 2b81a BPLNE SMMI Operational NVRAM 2b81a BPLNE SMMI Operational ENET 2b81a BPLNE Basbrd Operational QUAKE 2b81a BPLNE Basbrd Operational TWISTER 2b81a For ExtremeWare 6.2.2b108:...

  • Page 746: Enable Cli-Config-Logging

    Commands for Status Monitoring and Statistics enable cli-config-logging enable cli-config-logging Description Enables the logging of CLI configuration commands to the Syslog for auditing. Syntax Description This command has no arguments or variables. Default Enabled Usage Guidelines ExtremeWare allows you to record all configuration changes and their sources that are made using the CLI by way of Telnet or the local console.

  • Page 747: Enable Flowstats

    enable flowstats enable flowstats enable flowstats Description Enables the flow statistics feature on the switch. NOTE This command is available only on the “i” series switches. Syntax Description This command has no arguments or variables. Default Disabled Usage Guidelines None Example The following command enables NetFlow statistics feature on this switch: enable flowstats...

  • Page 748: Enable Flowstats Filter Ports

    Commands for Status Monitoring and Statistics enable flowstats filter ports enable flowstats filter <filter#> ports <portlist> {ingress | egress} Description Enables a specified flow record filter for the specified ports. NOTE This command is available only on the “i” series switches. Syntax Description filter# Specifies the flow record filter that should be enabled.
  • Page 749 enable flowstats filter ports Platform Availability This command is available on “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 750: Enable Flowstats Ping-Check

    Commands for Status Monitoring and Statistics enable flowstats ping-check enable flowstats ping-check {<group#>} Description Enables the flow statistics ping-check function for a specified group of collector devices. NOTE This command is available only on the “i” series switches. Syntax Description group# Specifies the export group for which the ping-check function should be enabled.

  • Page 751: Enable Flowstats Ports

    enable flowstats ports enable flowstats ports enable flowstats ports <portlist> Description Enables the flow statistics function on the specified ports. NOTE This command is available only on the “i” series switches. Syntax Description portlist Specifies a list of ports or slots and ports for which the flowstats function should be enabled. May be in the form 1, 2, 3-5, 2:5, 2:6-2:8.

  • Page 752: Enable Log Debug-Mode

    Commands for Status Monitoring and Statistics enable log debug-mode enable log debug-mode Description Enables debug mode. The switch allows debug events included in log filters to be logged. Syntax Description This command has no arguments or variables. Default Disabled Usage Guidelines This command enables debug mode.

  • Page 753: Enable Log Display

    enable log display enable log display enable log display Description Enables a running real-time display of log messages on the console display. Syntax Description This command has no arguments or variables. Default Disabled Usage Guidelines If you enable the log display on a terminal connected to the console port, your settings will remain in effect even after your console session is ended (unless you explicitly disable the log display).

  • Page 754: Enable Log Target

    Commands for Status Monitoring and Statistics enable log target enable log target [console-display | memory-buffer | nvram | session | syslog [<host name/ip> {:<udp-port>} [local0 ... local7]]] Description Start sending log messages to the specified target. Syntax Description console-display Specifies the console display. memory-buffer Specifies the switch memory buffer.
  • Page 755 enable log target Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 756: Enable Rmon

    Commands for Status Monitoring and Statistics enable rmon enable rmon Description Enables the collection of RMON statistics on the switch. Syntax Description This command has no arguments or variables. Default By default, RMON is disabled. However, even in the disabled state, the switch responds to RMON queries and sets for alarms and events.
  • Page 757 enable rmon To view the status of RMON polling on the switch, use the command. The show management show command displays information about the switch including the enable/disable state for management RMON polling. Example The following command enables the collection of RMON statistics on the switch: enable rmon History This command was first available in ExtremeWare 4.1.

  • Page 758: Enable Sflow

    Commands for Status Monitoring and Statistics enable sflow enable sflow Description Globally enables sFlow statistical packet sampling. NOTE This command is available only on the “i” series switches. Syntax Description This command has no arguments or variables. Default Disabled Usage Guidelines This command enables sFlow globally on the switch.

  • Page 759: Enable Sflow Backoff-Threshold

    enable sflow backoff-threshold enable sflow backoff-threshold enable sflow backoff-threshold Description Enables the sFlow backoff-threshold feature, limiting the maximum number of packets sent to the sFlow collector per second. NOTE This command is available only on the “i” series switches. Syntax Description This command has no arguments or variables.

  • Page 760: Enable Sflow Ports

    Commands for Status Monitoring and Statistics enable sflow ports enable sflow ports <portlist> Description Enables sFlow statistical packet sampling on one or more ports. NOTE This command is available only on the “i” series switches. Syntax Description portlist Specifies a list of ports or slots and ports. May be in the form 1, 2, 3-5, 2:5, 2:6-2:8. Default Disabled Usage Guidelines...

  • Page 761: Enable Sys-Health-Check

    enable sys-health-check enable sys-health-check enable sys-health-check Description Enables the BlackDiamond system health checker. NOTE This command is available only on the BlackDiamond switches. Syntax Description This command has no arguments or variables. Default Enabled Usage Guidelines The system health checker tests I/O modules, MSM modules, and the backplane by forwarding packets every 4 seconds.
  • Page 762 Commands for Status Monitoring and Statistics History This command was first available in ExtremeWare 6.2. Platform Availability This command is available on BlackDiamond switches only. ExtremeWare 7.5 Command Reference Guide...

  • Page 763: Enable Syslog

    enable syslog enable syslog enable syslog Description Enables logging to all remote syslog host targets. Syntax Description This command has no arguments or variables. Default Disabled Usage Guidelines In order to enable remote logging, you must do the following: • Configure the syslog host to accept and log messages. •...

  • Page 764: Enable Temperature-Logging

    Commands for Status Monitoring and Statistics enable temperature-logging enable temperature-logging Description Records the system temperature in celsius for the BlackDiamond and Alpine systems to the syslog. NOTE This command is available only on modular switches. Syntax Description This command has no arguments or variables. Default Disabled Usage Guidelines...
  • Page 765 enable temperature-logging History This command was first available in ExtremeWare 6.2.2b108. This command was not supported in ExtremeWare 7.0. The command was supported and the syntax changed from in ExtremeWare enable log temperature 7.1.0. Platform Availability This command is available on modular switches only. ExtremeWare 7.5 Command Reference Guide...

  • Page 766: Enable Transceiver-Test

    Commands for Status Monitoring and Statistics enable transceiver-test For an Alpine switch: enable transceiver-test [all | slot <slot number> {backplane} ] For a BlackDiamond switch: enable transceiver-test [all | slot <slot number> | msm-a | msm-b] Description Enables an integrity test of the transceivers used for communication between the ASICs and the CPU on an MSM or an SMMi module.
  • Page 767 enable transceiver-test slot 2 Unknown slot 3 FM8V Operational MAC 2b81b slot 4 GM4X Operational MAC 2b81b BPLNE SMMI Operational UART 2b81a BPLNE SMMI Operational FLASH 2b81a BPLNE SMMI Operational SRAM 2b81a BPLNE SMMI Operational NVRAM 2b81a BPLNE SMMI Operational ENET 2b81a BPLNE Basbrd...

  • Page 768: Save Log

    Commands for Status Monitoring and Statistics save log save log file ascii <local-filespec> {messages [memory-buffer | nvram]} {severity <severity> {only}} {starting [date <date> time <time> | date <date> | time <time>]} {ending [date <date> time <time> | date <date> | time <time>]} {match <match-expression>} {format <format>} {chronological} Description Saves the current log messages to the local file system.
  • Page 769 save log command, see the command on page 775, and for the option see the command show log format on page 688. configure log target format Example The following command saves messages with a critical severity to the filename switch4critical.log: save log switch4critical.log critical The following command saves messages with warning, error, or critical severity to the filename switch4warn.log:...

  • Page 770: Show Flowstats

    Commands for Status Monitoring and Statistics show flowstats show flowstats Description Displays status information for the flow statistics function. NOTE This command is available only on the “i” series switches. Syntax Description Default Displays summary statistics information for all ports. Usage Guidelines The command with no arguments displays flowstats configuration information for all ports.
  • Page 771 show flowstats Dest/Src Info: match-all-flows DestIP: 10.0.1.1/255.255.255.254 DestPort: any SrcIP: 10.201.32.1/255.255.255.255 SrcPort: any Flags: E - Enable, D - Disable; I - Ingress, S - Egress; A - Aggregation History This command was first available in ExtremeWare 6.2. Platform Availability This command is available on “i”...

  • Page 772: Show Flowstats

    Commands for Status Monitoring and Statistics show flowstats show flowstats <portlist> Description Displays status information for the flow statistics function for specified ports. NOTE This command is available only on the “i” series switches. Syntax Description portlist Specifies a list of ports or slots and ports for which flow statistics should be displayed. May be in the form 1, 2, 3-5, 2:5, 2:6-2:8.
  • Page 773 show flowstats DestIP: 10.201.26.0/ 255.255.255.0 DestPort: any SrcIP: 10.201.31.0/ 255.255.255.0 SrcPort: any Flags: E - Enable, D - Disable; I - Ingress, S - Egress; A - Aggregation History This command was first available in ExtremeWare 6.2. Platform Availability This command is available on “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 774: Show Flowstats Export

    Commands for Status Monitoring and Statistics show flowstats export show flowstats export [ detail |{<group number> detail} ] Description Displays configuration information an export group. NOTE This command is available only on the “i” series switches. Syntax Description group number Specifies a group number for which configuration information should be displayed.

  • Page 775: Show Log

    show log show log show log {messages [memory-buffer | nvram]} {severity <severity> {only}} {starting [date <date> time <time> | date <date> | time <time>]} {ending [date <date> time <time> | date <date> | time <time>]} {match <match-expression>} {format <format>} {chronological} Description Displays the current log messages.
  • Page 776 Commands for Status Monitoring and Statistics • Component, Subcomponent, and Condition Name—describes the subsystem in the software that generates the event. This provides a good indication of where a fault might lie. • Message—a description of the event occurrence. If the event was caused by a user, the user name is also provided.
  • Page 777 show log The three severity levels for extended debugging, , and debug-summary debug-verbose debug-data require that debug mode be enabled (which may cause a performance degradation). See the command on page 752. enable log debug-mode Table 15: Severity Levels Assigned by the Switch Level Description Critical...
  • Page 778 Commands for Status Monitoring and Statistics The following command displays messages with warning, error, or critical severity: show log warning The following command displays messages containing the string “slot 2”: show log match "slot 2" History This command was first available in ExtremeWare 2.0. This command was modified in ExtremeWare 6.2.2 to include the option.

  • Page 779: Show Log Components

    show log components show log components show log components {<event component> | all} Description Display the name, description and default severity for all components. Syntax Description event component Specifies component to display. Displays all components. Default Usage Guidelines This command displays the name, description, and default severity defined for the specified components and subcomponents.
  • Page 780 Commands for Status Monitoring and Statistics Tracking ESRP Tracking Error Forwarding Data Base Error IP FDB Error IPMC IP Multicast FDB Error Replacement FDB Replacement Error IGMP Internet Group Management Protocol Error Snooping IGMP Snooping Error AccessList IP Access List Error Forwarding IP Forwarding...

  • Page 781: Show Log Configuration

    show log configuration show log configuration show log configuration Description Displays the log configuration for switch log settings, and for certain targets. Syntax Description This command has no arguments or variables. Default Usage Guidelines This command displays the log configuration for all targets. The state of the target, enabled or disabled is displayed.
  • Page 782 Commands for Status Monitoring and Statistics History This command was first available in ExtremeWare 2.0. The additional EMS information was added in ExtremeWare 7.1.0 This command was added to the Summit “e” series of switches in ExtremeWare 7.2e Platform Availability This command is available on all platforms.

  • Page 783: Show Log Configuration Filter

    show log configuration filter show log configuration filter show log configuration filter {<filter name>} Description Displays the log configuration for the specified filter. Syntax Description filter name Specifies the filter to display. Default If no options are specified, the command displays the configuration for all filters. Usage Guidelines This command displays the configuration for filters.
  • Page 784 Commands for Status Monitoring and Statistics events from the STP.OutBPDU component. The third item includes the remaining events from the STP component. The severity value is show as “-”, indicating that the component’s default severity threshold controls which messages are passed. History This command was first available in ExtremeWare 7.1.0 This command was added to the Summit “e”...

  • Page 785: Show Log Configuration Target

    show log configuration target show log configuration target show log configuration target {console-display | memory-buffer | nvram | session | syslog <host name/ip> {: <udp-port>}[local0 ... local7]} Description Displays the log configuration for the specified target. Syntax Description console-display Show the log configuration for the console display. memory-buffer Show the log configuration for volatile memory.

  • Page 786: Show Log Counters

    Commands for Status Monitoring and Statistics show log counters show log counters {<event condition> | [all | <event component>] {severity <severity> {only}}} Description Displays the incident counters for events. Syntax Description event condition Specifies the event condition to display. Specifies that all events are to be displayed. event component Specifies that all the events associated with a particular component or subcomponent should be displayed.
  • Page 787 show log counters The output produced by the above command is similar to the following: Comp SubComp Condition Severity Rf Notified Occurred ------- ----------- ----------------------- ------------- -- -------- -------- InBPDU PDUDrop Error PDUIgn Debug-Summary PDUTrace Info The following command displays the event counters for the event condition PDUDrop in the component STP.InBPDU: show log counters "STP.InBPDU.PDUDrop"...

  • Page 788: Show Log Events

    Commands for Status Monitoring and Statistics show log events show log events {<event condition> | [all | <event component>] {severity <severity> {only}}} {detail} Description Displays information about the individual events (conditions) that can be logged. Syntax Description event condition Specifies the event condition to display. Specifies that all events are to be displayed.
  • Page 789 show log events The output produced by the above command is similar to the following: Comp SubComp Condition Severity Parameters ------- ----------- ----------------------- ------------- ---------- InBPDU PDUDrop Error PDUIgn Debug-Summary PDUTrace Info The following command displays the details of the event condition PDUTrace in the component STP.InBPDU: show log events stp.inbpdu.pdutrace detail The output produced by the above command is similar to the following:...

  • Page 790: Show Memory

    Commands for Status Monitoring and Statistics show memory show memory {detail} Description Displays the current system memory information. Syntax Description detail Specifies task-specific memory usage. Default Usage Guidelines A BlackDiamond or Summit switch must have 32MB of DRAM to support the features in ExtremeWare version 4.0 and above.
  • Page 791 show memory History This command was first available in ExtremeWare 2.0. This command was added to the Summit “e” series of switches in ExtremeWare 7.1e. Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 792: Show Packet-Mem-Scan-Recovery-Mode

    Commands for Status Monitoring and Statistics show packet-mem-scan-recovery-mode show packet-mem-scan-recovery-mode Description Displays the recovery mode setting for slot’s that have packet memory scanning enabled. NOTE This command is available only on the BlackDiamond switches. Syntax Description This command has no arguments or variables. Default Usage Guidelines command displays the following information:...
  • Page 793 show packet-mem-scan-recovery-mode Platform Availability This command is available on BlackDiamond switches only. ExtremeWare 7.5 Command Reference Guide...

  • Page 794: Show Packet Miscompare

    Default Usage Guidelines Use this command only at the direction of Extreme Networks personnel. Extreme Networks support personnel can capture corrupted packet data to help in troubleshooting problems using the following command: show packet miscompare <slot number>...

  • Page 795: Show Ports Rxerrors

    show ports rxerrors show ports rxerrors show ports {mgmt | <portlist>| vlan <vlan name>} rxerrors Description Displays real-time receive error statistics. For PoS modules, displays the information for the PoS ports. Only a subset of the statistics rxerror displayed by this command are applicable to PoS ports. The fields that do not apply to PoS ports are displayed with values of all zeroes.
  • Page 796 Commands for Status Monitoring and Statistics • Receive Jabber Frames (RX Jabber)—The total number of frames received by the port that was of greater than the support maximum length and had a Cyclic Redundancy Check (CRC) error. • Receive Alignment Errors (RX Align)—The total number of frames received by the port that occurs if a frame has a CRC error and does not contain an integral number of octets.
  • Page 797 show ports rxerrors Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 798: Show Ports Stats

    Commands for Status Monitoring and Statistics show ports stats show ports {mgmt | <portlist> | vlan <vlan name>} stats {cable-diagnostics} Description Displays real-time port statistics. Syntax Description mgmt Specifies the management port. NOTE: This option is available only for switches that provide a management port. portlist Specifies one or more ports or slots and ports.
  • Page 799 show ports stats • Received Byte Count (RX Byte Count)—The total number of bytes that were received by the port, including bad or lost frames. This number includes bytes contained in the Frame Check Sequence (FCS), but excludes bytes in the preamble. •...
  • Page 800 Commands for Status Monitoring and Statistics History This command was first available in ExtremeWare 2.0. This command was modified in ExtremeWare 4.0 to support modular switches. This command was modified in Extreme 4.1 to discontinue support for the chassis link status indicator. This command was added to the Summit “e”...

  • Page 801: Show Ports Txerrors

    show ports txerrors show ports txerrors show ports {mgmt | <portlist>| vlan <vlan name>} txerrors Description Displays real-time transmit error statistics. For PoS modules, displays the information for the PoS ports. txerror Syntax Description mgmt Specifies the management port. NOTE: This option is available only on switches that provide a management port. portlist Specifies one or more ports or slots and ports.
  • Page 802 Commands for Status Monitoring and Statistics • Transmit Errored Frames (TX Error)—The total number of frames that were not completely transmitted by the port because of network errors (such as late collisions or excessive collisions). • Transmit Lost Frames (TX Lost)—The total number of frames transmitted by the port that were lost. •...
  • Page 803 show ports txerrors Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 804: Show Sflow Configuration

    Commands for Status Monitoring and Statistics show sflow configuration show sflow configuration Description Displays the current sFlow configuration. NOTE This command is available only on the “i” series switches. Syntax Description This command has no arguments or variables. Default Usage Guidelines This command displays all sFlow configuration information for the switch.
  • Page 805 show sflow configuration SFLOW Configured Agent IP: 10.203.2.38 Operational Agent IP: 10.203.2.38 BackOff Threshold: disabled BackOff Threshold (No. of Samples): 50 SFLOW Configured Agent IP: 10.201.6.100 Collectors Collector IP 10.201.6.250, Port 6343 Collector IP 123.124.125.111 port 6344 SFLOW Port Configuration Port Status enabled...

  • Page 806: Show Sflow Statistics

    Commands for Status Monitoring and Statistics show sflow statistics show sflow statistics Description Displays sFlow statistics. NOTE This command is available only on the “i” series switches. Syntax Description This command has no arguments or variables Default Usage Guidelines This command displays sFlow statistics collected on all enabled ports. (No per port status is displayed.) The following fields are displayed: •...
  • Page 807 show sflow statistics Packet Drops Zero Sampling rate No Receivers History This command was first available in an ExtremeWare 7.3.0. Platform Availability This command is available on “i” series platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 808: Show Version

    Commands for Status Monitoring and Statistics show version show version {detail} Description Displays the hardware serial numbers and versions, and software versions currently running on the switch, and (if applicable) the modules. Syntax Description detail Specifies display of slot board name and chassis or platform name. Default Usage Guidelines On modular switches, displays the switch serial number and version numbers of MSM modules...
  • Page 809 show version On a stackable switch, this command produces output similar to the following: System Serial Number: 800078-11-0035M02442 CPU Serial Number: 700027-11 0034M-01445 CPLD Rev 04 Daughtercard Serial Number: 703015-02 0029M-02701 CPLD Rev ÿ Image Extremeware Version 6.2.0 (Build 60) by Release_Master 09/21/0120:53:17 On a BlackDiamond switch, this command produces output similar to the following: Chassis:...
  • Page 810 Commands for Status Monitoring and Statistics Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 811: Unconfigure Flowstats Filter Ports

    unconfigure flowstats filter ports unconfigure flowstats filter ports unconfigure flowstats filter <filter#> ports <portlist> Description Removes the filter specification for the specified ports. NOTE This command is available only on the “i” series switches. Syntax Description filter# Specifies the filter specification that should be removed. portlist Specifies a set of ports or slots and ports from which the filter specification is removed.

  • Page 812: Unconfigure Flowstats Ports

    Commands for Status Monitoring and Statistics unconfigure flowstats ports unconfigure flowstats ports [<portlist> | all] Description Resets the flow statistics configuration parameters for the specified ports to their default values. NOTE This command is available only on the “i” series switches. Syntax Description portlist Specifies a set of ports or slots and ports that should be reset.

  • Page 813: Unconfigure Log Filter

    unconfigure log filter unconfigure log filter unconfigure log filter <filter name> Description Resets the log filter to its default values; removes all filter items. Syntax Description filter name Specifies the log filter to unconfigure. Default Usage Guidelines If the filter name specified is DefaultFilter, this command restores the configuration of DefaultFilter back to its original settings.

  • Page 814: Unconfigure Log Target Format

    Commands for Status Monitoring and Statistics unconfigure log target format unconfigure log target [console-display | memory-buffer | nvram | session | syslog [<host name/ip> {:<udp-port>} [local0 ... local7]]] format Description Resets the log target format to its default values. Syntax Description console-display Specifies the console display format.
  • Page 815 unconfigure log target format • severity—on • event-name—none • host-name—off • priority—on • tag-id—off • tag-name—on • sequence-number—off • process-name—off • process-id—off • source-function—off • source-line—off Usage Guidelines Use this command to reset the target format to the default format. Example The following command sets the log format for the target (the current session) to the default:...

  • Page 816: Unconfigure Packet-Mem-Scan-Recovery-Mode

    Commands for Status Monitoring and Statistics unconfigure packet-mem-scan-recovery-mode unconfigure packet-mem-scan-recovery-mode slot [msm-a | msm-b | <slot number>] Description Disables packet memory scanning and the recovery mode on a BlackDiamond module, and returns the system to the configured system health check behavior. NOTE This command is available only on the BlackDiamond switches.

  • Page 817: Unconfigure Sflow Agent

    unconfigure sflow agent unconfigure sflow agent unconfigure sflow agent Description Resets the sFlow agent IP address to the default value. NOTE This command is available only on the “i” series switches. Syntax Description This command has no arguments or variables. Default The default IP address is 0.0.0.0.

  • Page 818: Unconfigure Sflow Backoff-Threshold

    Commands for Status Monitoring and Statistics unconfigure sflow backoff-threshold unconfigure sflow backoff-threshold Description Removes the configured value of the sFlow backoff threshold and resets it to 0 (zero). NOTE This command is available only on the “i” series switches. Syntax Description The command has no arguments or variables.

  • Page 819: Unconfigure Sflow Collector

    unconfigure sflow collector unconfigure sflow collector unconfigure sflow collector [<ip-address> | all] Description Removes the IP addresses of a selected sFlow collector so that sampled flows are no longer sent to that collector. NOTE This command is available only on the “i” series switches. Syntax Description ip-address Specifies the IP address of configured collector to reset.

  • Page 820: Unconfigure Transceiver-Test Failure-Action

    Commands for Status Monitoring and Statistics unconfigure transceiver-test failure-action unconfigure transceiver-test failure-action Description Returns the switch to its default of sending transceiver test messages to the syslog if too many failures are detected within the specified window. NOTE This command is available only on modular switches. Syntax Description The command has no arguments or variables.

  • Page 821: Unconfigure Transceiver-Test Period

    Use this feature when the switch can be brought off-line. Configuring the transceiver test period to 11 seconds or less can affect system performance; therefore, Extreme Networks does not recommend changing the default transceiver test period. The default is adequate for most networks.

  • Page 822: Unconfigure Transceiver-Test Threshold

    Default Usage Guidelines Use this feature when the switch can be brought off line. Extreme Networks does not recommend changing the default transceiver test period. The default is adequate for most networks. Example The following command returns the transceiver test threshold to 3 errors:...

  • Page 823: Unconfigure Transceiver-Test Window

    This configuration provides a sliding window. When you return to the default window, the switch checks for errors within the last eight 20-second windows. Extreme Networks does not recommend changing the default transceiver test window. The default is adequate for most networks.

  • Page 824: Upload Log

    Commands for Status Monitoring and Statistics upload log upload log <host name/ip> <filename> {messages [memory-buffer | nvram]} {severity <severity> {only}} {starting [date <date> time <time> | date <date> | time <time>]} {ending [date <date> time <time> | date <date> | time <time>]} {match <match-expression>} {format <format>} {chronological} Description Uploads the current log messages to a TFTP server.
  • Page 825 upload log most of the options of this command, see the command on page 775, and for the show log format option see the command on page 688. configure log target format Example The following command uploads messages with a critical severity to the filename switch4critical.log on TFTP server at 10.31.8.25: upload log 10.31.8.25 switch4critical.log critical The following command uploads messages with warning, error, or critical severity to the filename...
  • Page 826 Commands for Status Monitoring and Statistics ExtremeWare 7.5 Command Reference Guide...

  • Page 827: Security Commands

    Security Commands This chapter describes commands for: • Creating and configuring routing access policies • Creating and configuring IP access lists • Creating and configuring route maps (“i” series switches only) • Managing MAC address access to the switch • Managing the switch using SSH2 •...

  • Page 828: Mac Address Security

    Security Commands Route maps are used to modify or filter routes redistributed between two routing domains. They are also used to modify or filter the routing information exchanged between the domains. NOTE Route maps are supported only on the “i” series switches. MAC Address Security The switch maintains a database of all media access control (MAC) addresses received on all of its ports.

  • Page 829: Network Login

    Network Login Network Login Network login is a feature designed to control the admission of user packets into a network by giving network access only to users that have been properly authenticated. Network login is controlled by an administrator on a per port, per VLAN basis and uses an integration of DHCP, user authentication over the web interface or 802.1x client software, and, a RADIUS server to provide a user database or specific configuration details.

  • Page 830: Clear Netlogin State

    Security Commands clear netlogin state clear netlogin state port <portlist> vlan <vlan name> Description Clears and initializes the network login sessions on a VLAN port. Syntax Description portlist Specifies the ports to clear. vlan name Specifies a VLAN to clear. Default None Usage Guidelines...

  • Page 831: Clear Netlogin State Mac-Address

    clear netlogin state mac-address clear netlogin state mac-address clear netlogin state mac-address <hex-octet> Description Initialize or reset the network login sessions for a specified supplicant. Syntax Description hex-octet Specifies the MAC address of the supplicant. Default Usage Guidelines This command is essentially equivalent to a particular supplicant’s logging out. The MAC address is cleared from the FDB, the port is put back to its original VLAN (for campus mode), and the port state is set to unauthenticated, if this was the last authenticated MAC on this port.

  • Page 832: Configure Access-Profile Add

    Security Commands configure access-profile add For the “i” series switches: configure access-profile <access profile> add {<seq_number>} {permit | deny} [ipaddress <ip address> <mask> {exact} | as-path <path-expression> | bgp-community [internet | no-export | no-advertise | no-export-subconfed | <as_no:number> | number <community>] | ipxnet <netid> <netid mask> | ipxsap <sap_type>...
  • Page 833 configure access-profile add netid/netid mask Specifies an IPX netID and mask as an entry in the profile list. NOTE: This option is available only on “i” series switches. sap_type/service_name Specifies an IPX SAP service type and service name as an entry in the profile list. NOTE: This option is available only on “i”...
  • Page 834 Security Commands Examples The following command adds an IP subnet address to access profile nosales, as the next available entry: configure access-profile nosales add ipaddress 10.1.33.0/24 The following command configures the access profile AS1 to permit AS paths beginning with AS number 1, followed by any AS number from 2 - 8, and ending with either AS number 11, 13, or 15: configure access-profile AS1 add 15 permit as-path “^1 2-8 [11 13 15]$”...

  • Page 835: Configure Access-Profile Delete

    configure access-profile delete configure access-profile delete configure access-profile <access profile> delete <seq_number> Description Deletes an access profile entry using the sequence number. Syntax Description access profile Specifies an access profile name. seq-number Specifies the order of the entry within the access profile. If no sequence number is specified, the new entry is added to the end of the access-profile and is automatically assigned a value of 5 more than the sequence number of the last entry.

  • Page 836: Configure Access-Profile Mode

    Security Commands configure access-profile mode configure access-profile <access profile> mode [permit | deny | none] Description Configures the access profile mode to permit or deny access, or to require per-entry access control. Syntax Description access profile Specifies an access profile name. permit Allows the addresses that match the access profile description.

  • Page 837: Configure Auth Mgmt-Access Local

    configure auth mgmt-access local configure auth mgmt-access local configure auth mgmt-access local Description Configures local authentication for management sessions. If local authentication is configured for management sessions, users are authenticated through local user database. Syntax Description This command has no arguments or variables. Default Usage Guidelines RADIUS or TACACS servers are used only if they are enabled.
  • Page 838 Security Commands Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 839: Configure Auth Mgmt-Access Radius

    configure auth mgmt-access radius configure auth mgmt-access radius configure auth mgmt-access radius primary [<ipaddress> | <hostname>] {secondary [<ipaddress> | hostname]} Description Configures authentication of management sessions for RADIUS servers. Syntax Description primary Configures the primary RADIUS authentication server that is used for management sessions. secondary Configures the secondary RADIUS authentication server that is used for management sessions.

  • Page 840: Configure Auth Mgmt-Access Radius-Accounting

    Security Commands configure auth mgmt-access radius-accounting configure auth mgmt-access radius-accounting primary [<ipaddress> | <hostname>] {secondary {<ipaddress> | <hostname>]} Description Configures RADIUS accounting servers for accounting management sessions. Syntax Description ipaddress Specifies the IP addresses of the primary or secondary accounting server. hostname Specifies the host name of the authentication server.

  • Page 841: Configure Auth Mgmt-Access Tacacs

    configure auth mgmt-access tacacs configure auth mgmt-access tacacs configure auth mgmt-access tacacs primary [<ipaddress> | <hostname>] {secondary [<ipaddress> | <hostname>]} Description Configures authentication of management sessions for TACACS servers. Syntax Description primary Configures the primary TACACS+ authentication server that is used for management sessions. secondary Configures the secondary TACACS+ authentication server that is used for management sessions.
  • Page 842 Security Commands Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 843: Configure Auth Mgmt-Access Tacacs-Accounting

    configure auth mgmt-access tacacs-accounting configure auth mgmt-access tacacs-accounting configure auth mgmt-access tacacs-accounting primary [<ipaddress> | <hostname>] {secondary [<ipaddress> | <hostname>]} Description Configures TACACS accounting servers for accounting management sessions. Syntax Description primary Configures the primary TACACS+ accounting server that is used for management sessions. secondary Configures the secondary TACACS+ accounting server that is used for management sessions.
  • Page 844 Security Commands Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 845: Configure Auth Netlogin Radius

    configure auth netlogin radius configure auth netlogin radius configure auth netlogin radius primary [<ipaddress> | <hostname>] {secondary [<ipaddress> | <hostname>]} Description Configures authentication of netlogin sessions through RADIUS servers. Syntax Description primary Configures the primary RADIUS authentication server that is used for netlogin sessions. secondary Configures the secondary RADIUS authentication server that is used for netlogin sessions.

  • Page 846: Configure Auth Netlogin Radius-Accounting

    Security Commands configure auth netlogin radius-accounting configure auth netlogin radius-accounting primary [<ipaddress> | <hostname>] {secondary [<ipaddress> | <hostname>]} Description Configures the use of RADIUS accounting servers for netlogin session accounting. Syntax Description primary Configures the primary RADIUS accounting server that is used for netlogin sessions. secondary Configures the secondary RADIUS accounting server that is used for netlogin sessions.

  • Page 847: Configure Cpu-Dos-Protect Alert-Threshold

    configure cpu-dos-protect alert-threshold configure cpu-dos-protect alert-threshold configure cpu-dos-protect alert-threshold <packets per second> Description Configures the number of packets per second that the switch needs to receive on a port for an access list to be enabled for denial of service protection. Syntax Description packets per second Configures the number of packets per second that the switch needs to receive on a port...

  • Page 848: Configure Cpu-Dos-Protect Filter-Precedence

    Security Commands configure cpu-dos-protect filter-precedence configure cpu-dos-protect filter-precedence <number> Description Configures the access list precedence for denial of service protection. If you set the filter-precedence to 0, the ACLs created by DoS protection will be overwritten by the default VLAN QoS profile. Syntax Description filter-precedence Configures the access list precedence.

  • Page 849: Configure Cpu-Dos-Protect Filter-Type-Allowed

    configure cpu-dos-protect filter-type-allowed configure cpu-dos-protect filter-type-allowed configure cpu-dos-protect filter-type-allowed <destination | source>] Description Configures the type of access list allowed for denial of service protection. Syntax Description destination Specifies that destination ACLs can be created. source Specifies that source ACLs can be created. Default The default is destination.

  • Page 850: Configure Cpu-Dos-Protect Messages

    Security Commands configure cpu-dos-protect messages configure cpu-dos-protect messages [on | off] Description Configures messaging for denial of service protection. Syntax Description Turns messaging on. Turns messaging off. Default The default is on. Usage Guidelines None Example The following command sets messaging to be off: configure cpu-dos-protect messages off History This command was first available in ExtremeWare 6.2.2.

  • Page 851: Configure Cpu-Dos-Protect Notice-Threshold

    configure cpu-dos-protect notice-threshold configure cpu-dos-protect notice-threshold configure cpu-dos-protect notice-threshold <packets per second> Description Configures the number of packets per second that the switch needs to receive on a port for messages to be logged. Used for denial of service protection. Syntax Description packets per second Configures the number of packets per second that the switch needs to receive on a port...

  • Page 852: Configure Cpu-Dos-Protect Timeouts

    Security Commands configure cpu-dos-protect timeouts configure cpu-dos-protect timeouts <seconds> Description Configures the number of seconds prior to timeout for denial of services. Syntax Description seconds Specifies the number of seconds before a timeout takes place. Default None Usage Guidelines When heavy traffic reaches the alert threshold, a hardware ACL is created that blocks the traffic for the timeout number of seconds.

  • Page 853: Configure Cpu-Dos-Protect Trusted-Ports

    configure cpu-dos-protect trusted-ports configure cpu-dos-protect trusted-ports configure cpu-dos-protect trusted-ports [add <slot number> | all | delete <slot number> | none | <slot number>] Description Specifies the ports to be trusted when considering denial of service threats. Syntax Description Adds trusted port protection. Specifies that all ports are trusted.

  • Page 854: Configure Cpu-Dos-Protect (Port-Based)

    Security Commands configure cpu-dos-protect (Port-Based) configure cpu-dos-protect [ports <portnumber> |all] alert-threshold <pkts> interval-time <seconds> Description Sets the maximum allowed limit before invoking denial of service (DoS) protection and discarding packets. NOTE This command is available only on the “e” series switches. Syntax Description portnumber Specifies one or more port numbers.

  • Page 855: Configure Cpu-Dos-Protect Trusted-Ports

    configure cpu-dos-protect trusted-ports configure cpu-dos-protect trusted-ports configure cpu-dos-protect trusted-ports [add <port number> | delete <port number> | all | none] Description Configures the trusted port feature at a system level. Syntax Description port number Specifies a port. Specifies all ports as trusted. none Specifies that no ports are trusted.

  • Page 856: Configure Enhanced-Dos-Protect Ipfdb Agingtime

    Security Commands configure enhanced-dos-protect ipfdb agingtime configure enhanced-dos-protect ipfdb agingtime <aging> ports <portlist> Description Configures the aging time on untrusted ports for enhanced denial of service protection. Syntax Description aging Specifies the number of seconds for the aging time per port. The aging value is the software cache timeout: the duration of time to be considered to reach the threshold.

  • Page 857: Configure Enhanced-Dos-Protect Ipfdb Cache-Size

    configure enhanced-dos-protect ipfdb cache-size configure enhanced-dos-protect ipfdb cache-size configure enhanced-dos-protect ipfdb cache-size <cache-size> Description Configures the cache size on untrusted ports for enhanced denial of service protection. Syntax Description cache-size Specifies the cache size limit in kilobytes. The default value is 256. The maximum value is 256000.

  • Page 858: Configure Enhanced-Dos-Protect Ipfdb Learn-Limit

    Security Commands configure enhanced-dos-protect ipfdb learn-limit configure enhanced-dos-protect ipfdb learn-limit <learn-limit> ports <portlist> Description Configures the learning limit on untrusted ports for enhanced denial of service protection. Syntax Description learn-limit Specifies the number of packets allowed on the selected ports within the learning window before the rate limit is applied;...

  • Page 859: Configure Enhanced-Dos-Protect Ipfdb Learn-Window

    configure enhanced-dos-protect ipfdb learn-window configure enhanced-dos-protect ipfdb learn-window configure enhanced-dos-protect ipfdb learn-window <learn-window> ports <portlist> Description Configures the learning window on untrusted ports for the enhanced denial of service protection IPFDB learning qualifier. Syntax Description learn-window Specifies the number of seconds for the learning window per port. This value is the duration of time to be considered to reach the threshold.

  • Page 860: Configure Enhanced-Dos-Protect Ports

    Security Commands configure enhanced-dos-protect ports configure enhanced-dos-protect ports [trusted | untrusted] <portlist> Description Configures ports as trusted, so that enhanced denial of service protection is not applied to the ports; or configures ports as untrusted, so that enhanced denial of service protection is applied to the ports. Syntax Description trusted Specifies the selected ports as trusted, so that enhanced denial of service is not applied to...

  • Page 861: Configure Enhanced-Dos-Protect Rate-Limit

    configure enhanced-dos-protect rate-limit configure enhanced-dos-protect rate-limit configure enhanced-dos-protect rate-limit [threshold <threshold> | drop-probability <drop-probability> | learn-window <learn-window> | protocol [all | icmp]] ports <portlist> Description Configures rate limiting for enhanced denial of service protection. Syntax Description threshold Specifies the number of packets allowed on a given port within the learning window before the rate limit is applied.
  • Page 862 Security Commands The following command sets the rate limiting learn window on ports 2 and 3 to 90 seconds: configure enhanced-dos-protect rate-limit learn-window 90 ports 2,3 The following command sets the rate limiting protocol to all packet types on ports 1 through 3: configure enhanced-dos-protect rate-limit protocol all ports 1-3 History This command was first available in ExtremeWare 7.3.0 and ExtremeWare 7.3e.

  • Page 863: Configure Ip-Subnet-Lookup Maskbits

    configure ip-subnet-lookup maskbits configure ip-subnet-lookup maskbits configure ip-subnet-lookup maskbits <length> Description This command changes the length of the IPDA subnet lookup mask. NOTE This command is available only on the “i” series switches. Syntax Description length Specifies the number of maskbits for the IPDA subnet lookup mask. Default is 24. Default The default length of the subnet lookup mask is 24 bits.

  • Page 864: Configure Mac-Lockdown-Timeout Ports Aging-Time

    Security Commands configure mac-lockdown-timeout ports aging-time configure mac-lockdown-timeout ports [<portlist> | all] aging-time <seconds> Description This command configures the MAC address lockdown timeout value in seconds for the specified port or group of ports or for all ports. Syntax Description portlist Specifies one or more ports or slots and ports.

  • Page 865: Configure Netlogin Base-Url

    configure netlogin base-url configure netlogin base-url configure netlogin base-url <url> Description This command configures the base URL for network login. Syntax Description Specifies the base URL for network login. Default The base URL default value is “network-access.net”. Usage Guidelines When you log in using a web browser, you are redirected to the specified base URL, which is the DNS name for the switch.

  • Page 866: Configure Netlogin Mac-Address

    Security Commands configure netlogin mac-address configure netlogin mac-address [ <mac-address> {mask <mask>} | default ] {<password>} Description Configures the MAC address/mask pairs that are used for authentication in MAC-based network login. Syntax Description mac address Specifies a client MAC address in the form nn:nn:nn:nn:nn:nn. default Used as the default entry password the supplicant's mac-address does not match any of the entries in the table.

  • Page 867: Configure Netlogin Mac Auth-Retry-Count

    configure netlogin mac auth-retry-count configure netlogin mac auth-retry-count configure netlogin mac auth-retry-count <value> Description Configures the maximum number of times the RADIUS client tries again to authenticate a port using the MAC address before it times out. Syntax Description value Specifies the maximum number of retries for MAC-based RADIUS authentication.

  • Page 868: Configure Netlogin Mac Reauth-Period

    Security Commands configure netlogin mac reauth-period configure netlogin mac reauth-period <seconds> Description Configures the reauthentication interval for ports using MAC-based RADIUS authentication. Syntax Description seconds Specifies the interval between successive RADIUS Access-Request messages that reauthenticate the port. The range of values is 600-60000. Default 1800 seconds Usage Guidelines...

  • Page 869: Configure Netlogin Redirect-Page

    configure netlogin redirect-page configure netlogin redirect-page configure netlogin redirect-page <url> Description Configures the redirect URL for network login. Syntax Description Specifies the redirect URL for network login. Default The redirect URL default value is “http://www.extremenetworks.com”. Usage Guidelines In ISP mode, you can configure network login to be redirected to a base page after successful login using this command.

  • Page 870: Configure Radius Server

    Security Commands configure radius server For the “i” series switches: configure radius [primary | secondary] server [<ipaddress> | <hostname>] {<L4 port no>} client-ip [<ipaddress>] For the “e” series switches: configure radius [primary | secondary] server [<ipaddress> | <hostname>] client-ip [<ipaddress>] Description Configures the primary and secondary RADIUS authentication server.
  • Page 871 configure radius server Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 872: Configure Radius Shared-Secret

    Security Commands configure radius shared-secret configure radius [primary | secondary] shared-secret {encrypted} [<string>] Description Configures the authentication string used to communicate with the RADIUS authentication server. Syntax Description primary Configures the authentication string for the primary RADIUS server. secondary Configures the authentication string for the secondary RADIUS server. encrypted Indicates that the secret should be encrypted.

  • Page 873: Configure Radius Timeout

    configure radius timeout configure radius timeout configure radius {[primary | secondary] {server <ipaddress> | <hostname>}} timeout <seconds> Description Configures the timeout interval for RADIUS authentication requests. Syntax Description primary Configures the timeout for the primary RADIUS server. secondary Configures the timeout for the secondary RADIUS server. ipaddress Specifies the IP address of the server being configured.
  • Page 874 Security Commands Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 875: Configure Radius-Accounting Server

    configure radius-accounting server configure radius-accounting server configure radius-accounting [primary | secondary] server [<ipaddress> | <hostname>] {<L4 port no>} client-ip [<ipaddress>] Description Configures the primary and secondary RADIUS accounting servers. Syntax Description primary Configure the primary RADIUS accounting server. secondary Configure the secondary RADIUS accounting server. ipaddress The IP address of the accounting server being configured.

  • Page 876: Configure Radius-Accounting Shared-Secret

    Security Commands configure radius-accounting shared-secret configure radius-accounting [primary | secondary] shared-secret {encrypted} [<string>] Description Configures the authentication string used to communicate with the RADIUS accounting server. Syntax Description primary Configures the authentication string for the primary RADIUS accounting server. secondary Configures the authentication string for the secondary RADIUS accounting server.

  • Page 877: Configure Radius-Accounting Timeout

    configure radius-accounting timeout configure radius-accounting timeout configure radius-accounting {[primary | secondary] {server <ipaddress> | <hostname>}} timeout <seconds> Description Configures the timeout interval for RADIUS-Accounting authentication requests. Syntax Description primary Configures the timeout for the primary RADIUS accounting server. secondary Configures the timeout for the secondary RADIUS accounting server. ipaddress Specifies the IP address of the server being configured.

  • Page 878: Configure Route-Map Add

    Security Commands configure route-map add configure route-map <route-map> add <seq_number> [permit | deny] {match-one | match-all} {set lpm-routing | set iphost-routing} Description Adds an entry in the route map with the specified sequence number and action. NOTE This command is available only on the “i” series switches. Syntax Description route-map The name of the route map to which this entry should be added.
  • Page 879 configure route-map add Examples The following command adds an entry to the route-map named bgp-out that denies all matching routes: configure route-map bgp-out add 10 deny The following command adds an entry to the route-map named bgp-out that will be evaluated after the previous entry, and that permits all matching routes: configure route-map bgp-out add 20 permit History...

  • Page 880: Configure Route-Map Add Goto

    Security Commands configure route-map add goto configure route-map <route_map> <seq_number> add goto <new_route_map> Description Configures a route map statement to transfer evaluation to another route map. goto NOTE This command is available only on the “i” series switches. Syntax Description route-map The name of the route map to which this statement should be added.

  • Page 881: Configure Route-Map Add Match

    configure route-map add match configure route-map add match configure route-map <route-map> <seq_number> add match [nlri-list <access profile> | as-path [access-profile <access profile> | <as_number>] | community [access-profile <access profile> | <as_number>:<number> | number <community> | no-advertise | no-export | no-export-subconfed] | next-hop <ip address>...
  • Page 882 Security Commands Usage Guidelines A match operation specifies a criterion that must be matched for the route to be successful. If there are multiple statements in a route table entry, match statements are evaluated before set or goto statements. When an entry has multiple match statements, the primitive in the entry match-one match-all...

  • Page 883: Configure Route-Map Add Set

    configure route-map add set configure route-map add set configure route-map <route-map> <seq_number> add set [as-path <as_number> | community [[access-profile <access-profile> | <as_number>:<number> | number <community> | no-advertise | no-export | no-export-subconfed] | remove | [add | delete] [access-profile <access-profile> | <as no> : <number> | number <community>...
  • Page 884 Security Commands next-hop <ipaddress> Sets the next hop in the path attribute to the specified IP address. internal When used in the BGP neighbor output route map, sets the MED attribute to a value equal to the metric to reach the nexthop. med_number Sets the MED attribute to the specified value.

  • Page 885: Configure Route-Map Delete

    configure route-map delete configure route-map delete configure route-map <route_map> delete <seq_number> Description Deletes an entry from the route map. NOTE This command is available only on the “i” series switches. Syntax Description route_map The name of the route map to which this entry should be added. seq_number Specifies a sequence number that uniquely identifies the entry, and determines the position of the entry in the route map.

  • Page 886: Configure Route-Map Delete Goto

    Security Commands configure route-map delete goto configure route-map <route_map> <seq_number> delete goto <new_route_map> Description Deletes a route map statement. goto NOTE This command is available only on the “i” series switches. Syntax Description route_map The name of the route map from which this statement should be deleted. seq_number The sequence number of the entry in the route map from which this statement should be deleted.

  • Page 887: Configure Route-Map Delete Match

    configure route-map delete match configure route-map delete match configure route-map <route-map> <seq_number> delete match [nlri-list <access-profile> | as-path [access-profile <access-profile> | <as_number>] | community [access-profile <access-profile> | <as_number>:<number> | number <community> | no-advertise | no-export | no-export-subconfed] | next-hop <ip address> | med <number> | tag <number> | origin [igp | egp | incomplete]] Description Deletes a route map...
  • Page 888 Security Commands Example The following command deletes the statement from entry 15 in route map bgp-out that specifies that the access profile aslist should be used to match the AS path: configure bgp-out 15 add match as-path access-profile aslist History This command was first available in ExtremeWare 6.1.

  • Page 889: Configure Route-Map Delete Set

    configure route-map delete set configure route-map delete set configure route-map <route-map> <seq_number> delete set [as-path <as_number> | community [[access-profile <access-profile> | <as_number>:<number> | number <community> | no-advertise | no-export | no-export-subconfed] | remove | [add | delete] [access-profile <access-profile> | <as_number>:<number> | number <community> | no-advertise | no-export | no-export-subconfed]] | next-hop <ip address>...
  • Page 890 Security Commands add | delete <med_number> Specifies add or delete of the specified value to or from the MED. local-preference <number> Specifies a local preference number. weight <number> Specifies a weight associated with the NLRI. origin [igp | egp | incomplete] Specifies the origin.

  • Page 891: Configure Security-Profile Default-User-Vlan

    configure security-profile default-user-vlan configure security-profile default-user-vlan configure security-profile <name> default-user-vlan <vlan> Description Configures the default data VLAN for wireless users. Syntax Description name Specifies the name of the security profile. vlan Specifies the name of the default VLAN for wireless users. Default Wireless management default VLAN Usage Guidelines...

  • Page 892: Configure Security-Profile Dot11-Auth Network-Auth Encryption

    Security Commands configure security-profile dot11-auth network-auth encryption configure security-profile <name> dot11-auth <open | shared> network-auth <none | dot1x |mac-radius |web-based | wpa | wpa-psk | wpa2 | wpa2-psk> encryption <none | aes |tkip | aes-tkip | wep64 | wep128> Description Enables dot11 authentication, network authentication, and encryption.

  • Page 893: Usage Guidelines

    configure security-profile dot11-auth network-auth encryption Usage Guidelines The following table lists the valid combinations of authentication and encryption: Dot11 Authentication Network Authentication Encryption open none Choices: • none • wep64 • wep128 open web-based Choices: • none • wep64 • wep128 open mac-radius...
  • Page 894 Security Commands Examples The following command sets WPA2 authentication and encryption with AES encryption: configure security-profile secure1 dot11-auth open network-auth wpa2 encryption aes History This command was first available in ExtremeWare 6.2s. Platform Availability This command is available on the Summit 300-48, Summit 300-24, Summit 400-24p, and Alpine 3800 switches.

  • Page 895: Configure Security-Profile Dot1X-Wpa-Timers Group-Update-Timer

    configure security-profile dot1x-wpa-timers group-update-timer configure security-profile dot1x-wpa-timers group-update-timer configure security-profile <name> dot1x-wpa-timers group-update-timer <minutes> Description When the network-authentication is set to dot1x, WPA or WPA2, this command configures the interval when group keys for dot1x and WPA clients are updated. Syntax Description name Specifies the name of the security profile.

  • Page 896: Configure Security-Profile Dot1X-Wpa-Timers Pairwise-Update-Timer

    Security Commands configure security-profile dot1x-wpa-timers pairwise-update-timer configure security-profile <name> dot1x-wpa-timers pairwise-update-timer <minutes> Description When the network-authentication is set to dot1x, WPA or WPA2, this command configures the interval when pairwise keys for dot1x and WPA clients are updated. Syntax Description name Specifies the name of the security profile.

  • Page 897: Configure Security-Profile Dot1X-Wpa-Timers Reauth-Period

    configure security-profile dot1x-wpa-timers reauth-period configure security-profile dot1x-wpa-timers reauth-period configure security-profile <name> dot1x-wpa-timers reauth-period <seconds> Description When the network-authentication is set to dot1x, WPA or WPA2, this command configures the interval when clients are re-authenticated. Syntax Description name Specifies the name of the security profile. seconds Specifies the interval in seconds.

  • Page 898: Configure Security-Profile Ess-Name

    Security Commands configure security-profile ess-name configure security-profile <name> ess-name <ess_name> Description Sets the name of the wireless network for the 802.11 interface associated with the security profile. Syntax Description name Specifies the name of the security profile. ess_name Specifies the ESS name. Default Usage Guidelines ESS names can be shared across wireless ports and interfaces.

  • Page 899: Configure Security-Profile Ssid-In-Beacon

    configure security-profile ssid-in-beacon configure security-profile ssid-in-beacon configure security-profile <name> ssid-in-beacon {on | off} Description Establishes whether the service set identifier (SSID) is advertised in the beacon frame. Syntax Description name Specifies the name of the security profile. Specifies that the beacon contains the SSID. Specifies that the beacon does not contain the SSID.

  • Page 900: Configure Security-Profile Use-Dynamic-Vlan

    Security Commands configure security-profile use-dynamic-vlan configure security-profile <name> use-dynamic-vlan {y | n} Description Determines whether or not the security profile uses the dynamic VLAN (VLAN pushed by the RADIUS server through a VSA (Vendor Specific Attribute)). Syntax Description name Specifies the names of the security profile. Specifies yes, to use the dynamic VLAN.
  • Page 901 configure security-profile use-dynamic-vlan Platform Availability This command is available on the Summit 300-48, Summit 300-24, Summit 400-24p, and Alpine 3800 switches. ExtremeWare 7.5 Command Reference Guide...

  • Page 902: Configure Security-Profile Wep Default-Key-Index

    Security Commands configure security-profile wep default-key-index configure security-profile <name> wep default-key-index <index> Description Sets the default key index for the security profile in case of static WEP encryption. Syntax Description name Specifies the names of the security profile. index Specifies the index of the WEP key. Valid ranges are 0-3. Default Zero (0) Usage Guidelines...

  • Page 903: Configure Security-Profile Wep Key Add

    configure security-profile wep key add configure security-profile wep key add configure security-profile <name> wep key add <index> [hex <hexoctet> | plaintext <string>] Description Adds the given WEP key at the specified index. Syntax Description name Specifies the names of the security profile. index Specifies the index.

  • Page 904: Configure Security-Profile Wep Key Delete

    Security Commands configure security-profile wep key delete configure security-profile <name> wep key delete [all | <integer>] Description Deletes the specified WEP key. Syntax Description name Specifies the names of the security profile. Specifies that all WEP keys are deleted. integer Specifies the numeric value identifying the WEP key.

  • Page 905: Configure Security-Profile Wpa-Psk

    configure security-profile wpa-psk configure security-profile wpa-psk configure security-profile <name> wpa-psk [hex <hexadecimal_digit> | passphrase <alphanumeric_string>] Description Configures the WPA pre-shared key to have the specified hexadecimal or alphanumeric value. Syntax Description name Specifies the names of the security profile. Specifies the WPA pre-shared key type as hexadecimal. hexadecimal digit Specifies a 64-byte hexadecimal key.

  • Page 906: Configure Security-Profile Wpa2-Psk

    Security Commands configure security-profile wpa2-psk configure security-profile <name> wpa2-psk [hex <hexadecimal_digit> | passphrase <alphanumeric_string>] Description Configures the WPA2 pre-shared key to have the specified hexadecimal or alphanumeric value. Syntax Description name Specifies the names of the security profile. Specifies the WPA2 pre-shared key type as hexadecimal. hexadecimal digit Specifies a 64-byte hexadecimal key.

  • Page 907: Configure Security-Profile Wpa-Only

    configure security-profile wpa-only configure security-profile wpa-only configure security-profile <name> wpa-only [on | off] Description Prohibits use of wpa2 when wpa is selected as the network-authentication algorithm (see “configure security-profile dot11-auth network-auth encryption” on page 892). Syntax Description name Specifies name of the security-profile. Prohibits use of wpa2 when wpa is selected as the network authentication algorithm.

  • Page 908: Configure Ssh2 Key

    Secure Copy Program (SCP) or the Secure File Transfer Protocol (SFTP). Before you can enable SSH2, you must first obtain a security license from Extreme Networks. After you receive the license, you must enable SSH2 and generate a host key. To enable SSH2, use the enable command.
  • Page 909 configure ssh2 key Example The following command generates an authentication key for the SSH2 session: configure ssh2 key The command responds with the following messages: WARNING: Generating new server host key This will take approximately 10 minutes and cannot be canceled. Continue? (y/n) If you respond yes, the command prompts as follows: Enter some random characters.

  • Page 910: Configure Ssl Certificate Pregenerated

    Security Commands configure ssl certificate pregenerated configure ssl certificate pregenerated Description Obtains the pre-generated certificate from the user. Syntax Description This command has no parameters or variables. Default Usage Guidelines This command is also used when downloading or uploading the configuration. The certificate information stored in the uploaded configuration file should not be modified, because it is signed using the issuer’s private key.

  • Page 911: Configure Ssl Certificate Privkeylen Country Organization Common-Name

    configure ssl certificate privkeylen country organization common-name configure ssl certificate privkeylen country organization common-name configure ssl certificate privkeylen <length> country <code> organization <org_name> common-name <name> Description Creates a self-signed certificate and private key that can be saved in NVRAM. Syntax Description length Specifies the private key length in bytes.
  • Page 912 Security Commands Platform Availability This command is available in all platforms that use the SSH image except for the Summit “i” platform switches that use the SSH Base image. ExtremeWare 7.5 Command Reference Guide...

  • Page 913: Configure Ssl Privkey Pregenerated

    configure ssl privkey pregenerated configure ssl privkey pregenerated configure ssl privkey pregenerated Description Obtains the pre-generated private key from the user. NOTE This command is available only for the Alpine 3800 and Summit 300 series switches. Syntax Description This command has no parameters or variables. Default Usage Guidelines This command is also used when downloading or uploading the configuration.

  • Page 914: Configure Tacacs Server

    Security Commands configure tacacs server For the “i” switches: configure tacacs [primary | secondary] server [<ipaddress> | <hostname>] {<L4 port no>} client-ip <ipaddress> For the “e” switches: configure tacacs [primary | secondary] server [<ipaddress> | <hostname>] {<L4 port no>} client-ip [<ipaddress>] Description Configures the server information for a TACACS+ authentication server.
  • Page 915 configure tacacs server This command was added to the Summit “e” series of switches in ExtremeWare 7.1e. Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 916: Configure Tacacs Server Timeout

    Security Commands configure tacacs server timeout configure tacacs [primary |secondary] server <ipaddress> timeout <seconds> Description Configures the timeout interval for TACAS+ authentication requests for the primary and secondary servers. NOTE This command is available only on the “i” series switches. Syntax Description ipaddress Specifies the IP address of the primary or secondary server.

  • Page 917: Configure Tacacs Shared-Secret

    configure tacacs shared-secret configure tacacs shared-secret configure tacacs [primary | secondary] shared-secret {encrypted} <string> Description Configures the shared secret string used to communicate with the TACACS+ authentication server. Syntax Description primary Configures the authentication string for the primary TACACS+ server. secondary Configures the authentication string for the secondary TACACS+ server.

  • Page 918: Configure Tacacs Timeout

    Security Commands configure tacacs timeout configure tacacs [primary | secondary] {server <ipaddress> | <hostname>}} timeout <seconds> Description Configures the timeout interval for TACAS+ authentication requests. Syntax Description primary Configures the timeout for the primary TACACS+ server. secondary Configures the timeout for the secondary TACACS+ server. ipaddress Specifies the IP address of the TACACS+ server being configured.

  • Page 919: Configure Tacacs-Accounting Server

    configure tacacs-accounting server configure tacacs-accounting server configure tacacs-accounting [primary | secondary] server [<ipaddress> | <hostname>] {<tcp_port>} client-ip <ipaddress> Description Configures the primary and secondary TACACS+ accounting servers. Syntax Description primary Configures the primary TACACS+ accounting server. secondary Configures the secondary TACACS+ accounting server. ipaddress Specifies the IP address of the TACACS+ server being configured.

  • Page 920: Configure Tacacs-Accounting Shared-Secret

    Security Commands configure tacacs-accounting shared-secret configure tacacs-accounting [primary | secondary] shared-secret {encrypted} <string> Description Configures the shared secret string used to communicate with the TACACS+ accounting server. Syntax Description primary Configures the authentication string for the primary TACACS+ accounting server. secondary Configures the authentication string for the secondary TACACS+ accounting server.

  • Page 921: Configure Tacacs-Accounting Timeout

    configure tacacs-accounting timeout configure tacacs-accounting timeout configure tacacs-accounting {[primary | secondary] {server [<ipaddress>] | <hostname>}} timeout <seconds> Description Configures the timeout interval for TACACS+ accounting authentication requests. Syntax Description primary Configures the timeout for the primary TACACS+ accounting server. secondary Configures the timeout for the secondary TACACS+ accounting server.

  • Page 922: Configure Vlan Access-Profile

    Security Commands configure vlan access-profile configure vlan <vlan name> access-profile [<access profile> | none] Description Configures a BlackDiamond 6800 series switch running ExtremeWare 4.1 to control the routing of traffic between VLANs. NOTE This command is available only on the BlackDiamond 6800 series switches. Syntax Description vlan name Specifies the name of an egress VLAN.
  • Page 923 configure vlan access-profile Platform Availability This command is available on the BlackDiamond 6800 MSM32 only. ExtremeWare 7.5 Command Reference Guide...

  • Page 924: Configure Vlan Dhcp-Address-Range

    Security Commands configure vlan dhcp-address-range configure vlan <vlan-name> dhcp-address-range <start-addr> - <end-addr> {<mask>} Description Configures a set of DHCP addresses for a VLAN. Syntax Description vlan-name Specifies the name of the VLAN to be configured. start-addr Specifies the starting IP address in the configured range. end-addr Specifies the ending IP address in the configured range.
  • Page 925 configure vlan dhcp-address-range Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 926: Configure Vlan Dhcp-Lease-Timer

    Security Commands configure vlan dhcp-lease-timer configure vlan <name> dhcp-lease-timer <lease-timer> Description Configures the timer value in seconds returned as part of the DHCP response. Syntax Description name Specifies the VLAN on whose ports netlogin should be disabled. lease-timer Specifies the timer value, in seconds. Default Usage Guidelines The timer value is specified in seconds.

  • Page 927: Configure Vlan Dhcp-Options

    configure vlan dhcp-options configure vlan dhcp-options configure vlan <vlan-name> dhcp-options [dhcp-gateway <gateway-addr> | dns-server <dns-server-ip> | wins-server <wins-server-ip>] {<start-addr>} Description Configures the DHCP options returned as part of the DHCP response by a switch configured as a DHCP server. Syntax Description vlan-name Specifies the name of the VLAN to be configured.
  • Page 928 Security Commands 40.0.0.40. Similarly, for the secondary subnet the DHCP address range is configured ranging from 50.0.0.5 to 50.0.0.40. To configure the DHCP gateway as 40.0.0.90 for the primary subnet, use the following command: configure vlan test dhcp-options dhcp-gateway 40.0.0.90 To configure the DHCP gateway as 50.0.0.90 for the secondary subnet use the following command: configure vlan test dhcp-options dhcp-gateway 50.0.0.90 50.0.0.5 NOTE...
  • Page 929 configure vlan dhcp-options History This command was first available in ExtremeWare 6.2. This command was added to the Summit “e” series of switches in ExtremeWare 7.1e. This command was modified so that remote or secondary subnets could be configured for DHCP options in ExtremeWare (through the addition of the parameter ).

  • Page 930: Configure Vlan Netlogin-Lease-Timer

    Security Commands configure vlan netlogin-lease-timer configure vlan <vlan name> netlogin-lease-timer <seconds> Description Configures the timer value returned as part of the DHCP response for clients attached to network login-enabled ports. Syntax Description vlan name Specifies the VLAN to which this timer value applies. seconds Specifies the timer value, in seconds.

  • Page 931: Create Access-List

    create access-list create access-list create access-list <name> access-mask <access-mask name> {dest-mac <dest_mac} {source-mac <src_mac>} {vlan <name>} {ethertype [IP | ARP | <hex_value>]} {tos <ip_precedence> | code-point <code_point>} {ipprotocol [tcp | udp | icmp | igmp | <prococol_num>]} {dest-ip <dest_IP>/<mask length>} {dest-L4port <dest_port>} {source-ip <src_IP>/<mask length>} {source-L4port <src_port>...
  • Page 932 Security Commands code-point Specifies a 6-bit DiffServ code point. Valid entries are from 0 to 63. dot1p Specifies the priorities for 802.1p. permit-established Specifies to deny any new TCP session initiation. deny Specifies to drop the packet. vlan-pri Specifies the 802.1p priority of the VLAN tag, which is a three-bit field. Valid values are 0 to 7.

  • Page 933: Create Access-List Icmp Destination Source

    create access-list icmp destination source create access-list icmp destination source create access-list <name> icmp destination [<dest_ipaddress>/<mask> | any] source [<src_ipaddress>/<source_mask> | any] type <icmp_type> code <icmp_code> [permit | deny] {<portlist>} {precedence <number>} Description Creates a named IP access list that applies to ICMP traffic. NOTE This command is available only on the “i”...
  • Page 934 Security Commands History This command was first available in ExtremeWare 6.0, and replaced the command. configure ipqos Platform Availability This command is available on the “i” series platforms only. ExtremeWare 7.5 Command Reference Guide...

  • Page 935: Create Access-List Ip Destination Source Ports

    create access-list ip destination source ports create access-list ip destination source ports create access-list <name> ip destination [<dest_ipaddress>/<mask> | any] source [<src_ipaddress>/<src_mask> | any] [permit {<qosprofile>} | deny] ports [<portlist> | any] {precedence <prec_number>} Description Creates a named IP access list that applies to all IP traffic. NOTE This command is available only on the “i”...
  • Page 936 Security Commands The following command defines a default entry that is used to specify an explicit deny: create access-list denyall ip dest 0.0.0.0/0 source 0.0.0.0/0 deny ports any History This command was first available in ExtremeWare 6.0, and replaced the command.

  • Page 937: Create Access-List Tcp Destination Source Ports

    create access-list tcp destination source ports create access-list tcp destination source ports create access-list <name> tcp destination [<dest_ipaddress>/<mask> | any] ip-port [<dst_port> | range <dst_port_min> <dst_port_max> | any] source [<src_ipaddress>/<src_mask> | any] ip-port [<src_port> | range <src_port_min> <src_port_max> | any] [permit <qosprofile> | permit-established | deny] ports [<portlist>...
  • Page 938 Security Commands Default Usage Guidelines The access list is applied to all ingress packets. Example The following command defines an access-list rule named allow10_23 with precedence 30 that permits TCP port 23 traffic destined for other 10.x.x.x networks, and assigns QoS profile Qp4: create access-list allow10_23 tcp dest 10.0.0.0/8 ip-port 23 source any ip-port any permit qosprofile qp4 ports any precedence 30 History...

  • Page 939: Create Access-List Udp Destination Source Ports

    create access-list udp destination source ports create access-list udp destination source ports create access-list <name> udp destination [<dest_ipaddress>/<mask> | any] ip-port [<dst_port> | range <dst_port_min> <dst_port_max> | any] source [<src_ipaddress>/<src_mask> | any] ip-port [<src_port> | range <src_port_min> <src_port_max> | any] [permit <qosprofile> | deny] ports [<portlist>...
  • Page 940 Security Commands Usage Guidelines The access list is applied to all ingress packets. Example The following command defines an access-list rule named allow10_35 with precedence 70 that permits udp port 35 traffic destined for other 10.X.X.X networks, and assigns QoS profile Qp2: create access-list allow10_35 udp dest 10.0.0.0/8 ip-port 35 source any ip-port any permit qosprofile qp2 ports any precedence 70 History...

  • Page 941: Create Access-Mask

    create access-mask create access-mask create access-mask <access-mask name> {dest-mac} {source-mac} {vlan} {tos |code-point} {ethertype} {ipprotocol} {dest-ip/<mask length>} {source-L4port | {icmp-type} {icmp-code}} {permit-established} {egressport} {ports} {precedence <number>}{vlan-pri}{vlan-pri-2bits} Description Creates an access mask. NOTE This command is available only on the “e” series switches. Syntax Description access mask name Specifies the name of the access-mask.
  • Page 942 Security Commands Default Usage Guidelines None Example The following commands create the access mask and access lists: create access-mask ipproto_mask ipprotocol ports precedence 25000 create access-list denytcp ipproto_mask ipprotocol tcp ports 2,10 deny create access-list denyudp ipproto_mask ipprotocol udp ports 2,10 deny History This form of the command was available in ExtremeWare 7.1e.

  • Page 943: Create Access-Profile Type

    create access-profile type create access-profile type For the “i” series switches: create access-profile <access profile> type [ipaddress | ipx-node | ipx-net | ipx-sap | as-path | bgp-community | vlan] For the “e” series switches: create access-profile <access profile> type [ipaddress | as-path] Description Creates an access profile.
  • Page 944 Security Commands Examples The following command creates an access profile named nosales that will contain IP address/mask pairs: create access-profile nosales type ipaddress The following command creates an access profile that will contain AS path expressions: create access-profile AS1 type as-path History A limited version of this command was first available in ExtremeWare 4.0.

  • Page 945: Create Rate-Limit

    create rate-limit create rate-limit create rate-limit <rule_name> access-mask <access-mask name> {dest-mac <dest_mac>} {source-mac <scr_mac>} {vlan <name>} {ethertype [IP | ARP | <hex_value>]} {tos <ip_precedence> | code-point <code_point>} {ipprotocol [tcp | udp | icmp | igmp | <prococol_num>]} {dest-ip <dest_IP>/<mask length>} {dest-L4port <dest_port>} {source-ip <src_IP>/<mask length>} {source-L4port <src_port>...
  • Page 946 Security Commands vlan-pri-2bits Specifies the two most significant bits of the vlan-pri field. Example This command creates an access list named denyping that filters out ping (ICMP echo) packets. ICMP echo packets are defined as type 8 code 0: create access-list denyping icmp destination any source any type 8 code 0 deny ports History This command was first available in ExtremeWare 7.1e.

  • Page 947: Create Route-Map

    create route-map create route-map create route-map <name> Description Creates a route map statement. NOTE This command is available only on the “i” series switches. Syntax Description name Specifies a route map name. Default Usage Guidelines Route maps are a mechanism that can be used to conditionally control the redistribution of routes between two routing domains, and to modify the routing information that is redistributed.

  • Page 948: Create Security-Profile

    Security Commands create security-profile create security-profile <name> {copy <existing_profile>} Description Creates a new security profile. NOTE This command is available on Summit 300 and Alpine 3800 series switches only. Syntax Description name Specifies the name of the security profile being created. existing_profile Specifies the name of an existing profile from which the system copies the initial values.

  • Page 949: Create Trusted-Mac-Address

    create trusted-mac-address create trusted-mac-address For the “i” switches: create trusted-mac-address {mac-address} <xx:yy:zz:aa:bb:cc> {mask <dd:ee:ff:gg:hh:kk>} vlan <vlan-name | all> {port <portlist>} {protocol[DHCP|ARP]} For the “e” switches: create trusted-mac-address mac-address <mac_address> [mask <mask>] vlan <vlan_name>| all [ports <portlist>] [protocol {DHCP|ARP}] Description Configures a trusted media access control (MAC) address with mask for each VLAN or all VLANs for the ARP or DHCP protocols.
  • Page 950 Security Commands Use the following command to delete a trusted MAC address: delete trusted-mac-address [mac-address <mac_address> {mask <mask>} <vlan_name>] | all [ports <portlist>] [protocol [DHCP|ARP]] Example The following command creates a trusted MAC address of for all ports in the 00:e0:18:01:32:1f VLAN named vlan1: create trusted-mac-address 00:e0:18:01:32:1f vlan1...

  • Page 951: Delete Access-List

    delete access-list delete access-list For the “i” switches: delete access-list [<name> | all] For the “i” switches: delete access-list <name> Description Deletes an access list. Syntax Description name Specifies the name of the access list to be deleted. Specifies that all access lists should be deleted. NOTE: This option is available only on the “I”...

  • Page 952: Delete Access-Mask

    Security Commands delete access-mask delete access-mask <name> Description Deletes the named access-mask. NOTE This command is available only on the “e” series switches. Syntax Description name Specifies the name of the access list to be deleted. Usage Guidelines None Example The following command disables statistics collection for access list allow102: delele access-list allow102 History...

  • Page 953: Delete Access-Profile

    delete access-profile delete access-profile delete access-profile <access profile> Description Deletes an access profile. Syntax Description access profile Specifies the access profile name to be deleted. Default Usage Guidelines None Example The following command deletes an access profile named nosales: delete access-profile nosales History This command was first available in ExtremeWare 4.0.

  • Page 954: Delete Rate-Limit

    Security Commands delete rate-limit delete rate-limit <name> Description Deletes a rate limit rule. NOTE This command is available only on the “e” series switches. Syntax Description name Specifies the name of the rate limit rule. Usage Guidelines None Example The following command deletes a rate limit rule named throttle2: delete access-profile throttle2 History This command was first available in ExtremeWare 7.1e.

  • Page 955: Delete Route-Map

    delete route-map delete route-map delete route-map <route map> Description Deletes a route map statement from the route map. NOTE This command is available only on the “i” series switches. Syntax Description route map Specifies a route map name. Default Usage Guidelines None Example The following command deletes a route-map named bgp-out:...

  • Page 956: Delete Security-Profile

    Security Commands delete security-profile delete security-profile <name> Description Deletes the named security profile. Syntax Description name Specifies the name of an existing security profile to be deleted. Default Usage Guidelines Use this command to delete the named security profile. The named profile cannot be attached to any active ports before deletion.

  • Page 957: Delete Trusted-Mac-Address

    delete trusted-mac-address delete trusted-mac-address delete trusted-mac-address [mac-address <mac_address> {mask <mask>} <vlan_name>] | all [ports <portlist>] [protocol [DHCP|ARP]] Description Deletes a trusted MAC address. Syntax Description <xx:yy:zz:aa:bb:cc> Specifies the MAC address of the enabled trusted-MAC. Either is specified in the form xx:yy:zz:aa:bb:cc.
  • Page 958 Security Commands Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 959: Disable Access-List

    disable access-list disable access-list disable access-list <name> [counter | log] Description Disables message logging or the collection of access-list statistics. NOTE This command is available only on the “i” series switches. Syntax Description name Specifies the name of the access list. counter Specifies that access-list statistics collection should be disabled.

  • Page 960: Disable Arp-Learning

    Security Commands disable arp-learning disable arp-learning Description Disables the ARP-learning feature on the switch. Syntax Description This command has no arguments or variables. Default By default, ARP learning is enabled. Usage Guidelines None Example History This command was first available in ExtremeWare 7.3.0. and ExtremeWare 7.3e. Platform Availability This command is available on all platforms.

  • Page 961: Disable Arp-Learning Ports

    disable arp-learning ports disable arp-learning ports disable arp-learning ports <portlist> Description Disables the ARP-learning feature on a port or ports. Syntax Description portlist Specifies the ingress port(s) on which this rule is applied. any specifies that the rule will be applied to all ports. Default By default, ARP learning is enabled.

  • Page 962: Disable Arp-Learning Vlan

    Security Commands disable arp-learning vlan disable arp-learning vlan <vlan name> Description Disables the ARP-learning feature on a specified VLAN. Syntax Description vlan name Specifies the vlan to which the rule applies. Default By default, ARP learning is enabled. Usage Guidelines None Example History...

  • Page 963: Disable Arp-Learning Vlan Ports

    disable arp-learning vlan ports disable arp-learning vlan ports disable arp-learning vlan <vlan name> port <portlist> Description Disables the ARP-learning feature on a port in the specified VLAN. Syntax Description vlan name Specifies the vlan to which the rule applies. portlist Specifies the ports to which the rule applies.

  • Page 964: Disable Cpu-Dos-Protect

    Security Commands disable cpu-dos-protect disable cpu-dos-protect Description Disables denial of service protection. Syntax Description There are no arguments or variables for this command. Default The default is disabled. Usage Guidelines None Example The following command disables denial of service protection. disable cpu-dos-protect History This command was first available in ExtremeWare 6.2.2.

  • Page 965: Disable Dhcp Ports Vlan

    disable dhcp ports vlan disable dhcp ports vlan disable dhcp ports <portlist> vlan <vlan name> Description Disables DHCP on a specified port in a VLAN. Syntax Description portlist Specifies the ports for which DHCP should be disabled. vlan name Specifies the VLAN on whose ports DHCP should be disabled. Default Usage Guidelines The DHCP server should be used with network login and not as a stand-alone DHCP server.

  • Page 966: Disable Enhanced-Dos-Protect

    Security Commands disable enhanced-dos-protect disable enhanced-dos-protect {rate-limit | ipfdb} {ports [<portlist> | all]} Description Disables enhanced denial of service protection globally or for selected ports. Syntax Description rate-limit Disables software rate limiting. ipfdb Disables the IPFDB learning qualifier. portlist Specifies one or more ports or slots and ports. On a modular switch, can be a list of slots and ports.

  • Page 967: Disable Ip-Subnet-Lookup

    disable ip-subnet-lookup disable ip-subnet-lookup disable ip-subnet-lookup Description Disables the IPDA subnet lookup feature in a switch. Syntax Description There are no arguments or variables for this command. Default The default is disabled. Usage Guidelines On the “i” series switches, system rebooting is needed for a new setting to be effective. On the “e”...

  • Page 968: Disable Mac-Lockdown-Timeout Ports

    Security Commands disable mac-lockdown-timeout ports disable mac-lockdown-timeout ports [<portlist> | all] Description This command disables the MAC address lockdown timeout feature for the specified port or group of ports or for all ports. Syntax Description portlist Specifies one or more ports or slots and ports. On a modular switch, can be a list of slots and ports. On a stand-alone switch, can be one or more port numbers.

  • Page 969: Disable Netlogin

    disable netlogin disable netlogin disable netlogin [web-based |dot1x |mac] Description Disables network login modes. Syntax Description web-based Specifies web-based authentication. dot1x Specifies 802.1x authenticating. Specifies MAC-based RADIUS authentication. Default Web-based and 802.1x authentication are enabled by default. MAC-based authentication is disabled by default. Usage Guidelines All types, any combination of types, or no type of authentication can be enabled on the same switch.
  • Page 970 Security Commands keyword was added in Extremeware 7.4. Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 971: Disable Netlogin Logout-Privilege

    disable netlogin logout-privilege disable netlogin logout-privilege disable netlogin logout-privilege Description Disables the network login logout window pop-up. Syntax Description This command has no arguments or variables. Default Enabled Usage Guidelines This command controls the logout window pop-up on the web-based network client. This command applies only to the web-based authentication mode of network login.

  • Page 972: Disable Netlogin Ports

    Security Commands disable netlogin ports disable netlogin ports <portlist> vlan <vlan name> Description Disables network login on a specified port in a VLAN. Syntax Description portlist Specifies the ports for which netlogin should be disabled. vlan name Specifies the VLAN on whose ports netlogin should be disabled. Default Usage Guidelines Network login must be disabled on a port before you can delete a VLAN that contains that port.

  • Page 973: Disable Netlogin Ports Mac

    disable netlogin ports mac disable netlogin ports mac disable netlogin ports <portlist> mac Description Disables MAC-based network login on specified ports. Syntax Description portlist Specifies the ports for which MAC-based network login should be disabled. Default By default, MAC-based network login is disabled. Usage Guidelines None Example...

  • Page 974: Disable Netlogin Session-Refresh

    Security Commands disable netlogin session-refresh disable netlogin session-refresh Description Disables network login session refresh. Syntax Description This command has no arguments or variables. Default Disabled Usage Guidelines Network login sessions can refresh themselves after a configured timeout. After the user has been logged in successfully, a logout window opens which can be used to close the connection by clicking on the LogOut link.

  • Page 975: Disable Radius

    disable radius disable radius disable radius Description Disables the RADIUS client. Syntax Description This command has no arguments or variables. Default RADIUS authentication is disabled by default. Usage Guidelines None Example The following command disables RADIUS authentication for the switch: disable radius History This command was first available in ExtremeWare 4.1.

  • Page 976: Disable Radius-Accounting

    Security Commands disable radius-accounting disable radius-accounting Description Disables RADIUS accounting. Syntax Description This command has no arguments or variables. Default Usage Guidelines None Example The following command disables RADIUS accounting for the switch: disable radius-accounting History This command was first available in ExtremeWare 4.1. This command was added to the Summit “e”...

  • Page 977: Disable Source-Ip-Lockdown Ports

    disable source-ip-lockdown ports disable source-ip-lockdown ports disable source-ip-lockdown ports [all | <portlist>] Description Disables the source IP lockdown feature on one or more ports. Syntax Description port-list Specifies the ports to which the command applies. Specifies all ports. Default By default source IP lockdown is disabled. Usage Guidelines Example History...

  • Page 978: Disable Ssh2

    Security Commands disable ssh2 disable ssh2 Description Disables the SSH2 server for incoming SSH2 sessions to the switch. Syntax Description This command has no arguments or variables. Default Disabled Usage Guidelines SSH2 session options (access profile and non-default port setting) are not saved when SSH2 is disabled. To view the status of SSH2 telnet sessions on the switch, use the show management command.

  • Page 979: Disable Tacacs

    disable tacacs disable tacacs disable tacacs Description Disables TACACS+ authentication. Syntax Description This command has no arguments or variables. Default Usage Guidelines None Example The following command disables TACACS+ authentication for the switch: disable tacacs History This command was first available in ExtremeWare 6.1. This command was added to the Summit “e”...

  • Page 980: Disable Tacacs-Accounting

    Security Commands disable tacacs-accounting disable tacacs-accounting Description Disables TACACS+ accounting. Syntax Description This command has no arguments or variables. Default Usage Guidelines None Example The following command disables TACACS+ accounting: disable tacacs-accounting History This command was first available in ExtremeWare 6.1. This command was added to the Summit “e”...

  • Page 981: Disable Tacacs-Authorization

    disable tacacs-authorization disable tacacs-authorization disable tacacs-authorization Description Disables TACACS+ authorization. Syntax Description This command has no arguments or variables. Default Usage Guidelines This command disables CLI command authorization but leaves user authentication enabled. Example The following command disables TACACS+ CLI command authorization: disable tacacs-authorization History This command was first available in ExtremeWare 6.1.

  • Page 982: Disable Trusted-Mac-Address

    Security Commands disable trusted-mac-address disable trusted-mac-address {vlan <vlan-name>} Description Disables trusted Organizational Unique Identifier (OUI) or MAC addresses for port-specific configurations. Syntax Description vlan name Specifies the VLAN on whose ports trusted-MAC feature should be disabled. Default Disabled Usage Guidelines Use this command to disable OUI or MAC addresses for port-specific configurations.

  • Page 983: Disable Web

    disable web disable web disable web Description Disables both HTTP access and secure HTTP access (HTTPS) to the switch. NOTE This command is available only for the Summit 300 series switches. Syntax Description This command has no parameters or variables. Default Enabled Usage Guidelines...

  • Page 984: Disable Web Http

    Security Commands disable web http disable web http Description Disables HTTP access to the switch on the default HTTP port (80). NOTE This command is available only on the Alpine 3800 and Summit 300 series switches. Syntax Description This command has no parameters or variables. Default Enabled Usage Guidelines...

  • Page 985: Disable Web Https

    disable web https disable web https disable web https Description Disables secured HTTP access (HTTPS) to the switch on the default HTTPS port (443). NOTE This command is available only on the Alpine 3800 and Summit 300 series switches. Syntax Description This command has no parameters or variables.

  • Page 986: Download Ssl Certificate

    Security Commands download ssl certificate download ssl <ip address> certificate <cert file> Description Permits downloading of a certificate key from files stored in a TFTP server. Syntax Description ip address Specifies the IP address of the TFTP server. cert file Specifies the name of certificate key.

  • Page 987: Download Ssl Privkey

    download ssl privkey download ssl privkey download ssl <ip address> privkey <key file> Description Permits downloading of a private key from files in a TFTP server. NOTE This command is available only for the Alpine 3800 and Summit 300 switches. Syntax Description ip address Specifies the IP address of the TFTP server.
  • Page 988 Security Commands Platform Availability Beginning with ExtremeWare 7.4, this command is available in all platforms using SSH image except for the Summit “i” platform switches using SSH Base image (.SBxtr). ExtremeWare 7.5 Command Reference Guide...

  • Page 989: Enable Access-List

    enable access-list enable access-list enable access-list <name> [counter | log] Description Enables message logging or the collection of access-list statistics. NOTE This command is available only on the “i” series switches. Syntax Description name Specifies the name of the access list. counter Specifies that access-list statistics should be collected.

  • Page 990: Enable Arp-Learning

    Security Commands enable arp-learning enable arp-learning Description Enables the ARP-learning feature on the switch. Syntax Description This command has no arguments or variables. Default By default, ARP learning is enabled. Usage Guidelines None Example History This command was first available in ExtremeWare 7.3.0 and ExtremeWare 7.3e. Platform Availability This command is available on all platforms.

  • Page 991: Enable Arp-Learning Ports

    enable arp-learning ports enable arp-learning ports enable arp-learning ports <portlist> Description Enables the ARP-learning feature on a port or ports. Syntax Description portlist Specifies the ingress port(s) on which this rule is applied. any specifies that the rule will be applied to all ports. Default By default, ARP learning is enabled.

  • Page 992: Enable Arp-Learning Vlan

    Security Commands enable arp-learning vlan enable arp-learning vlan <vlan name> Description Enables the ARP-learning feature on a vlan. NOTE This command is available only on the “i” series switches. Syntax Description vlan name Specifies the vlan to which the rule applies. Default By default, ARP learning is enabled.

  • Page 993: Enable Arp-Learning Vlan Ports

    enable arp-learning vlan ports enable arp-learning vlan ports enable arp-learning vlan <vlan name> port <portlist> Description Enables the ARP-learning feature on a port in the specified VLAN. Syntax Description vlan name Specifies the vlan to which the rule applies. portlist Specifies the ports to which the rule applies.

  • Page 994: Enable Cpu-Dos-Protect

    Security Commands enable cpu-dos-protect enable cpu-dos-protect Description Enables denial of service protection. Syntax Description There are no arguments or variables for this command. Default The default is disabled. Usage Guidelines None Example The following command enables denial of service protection. enable cpu-dos-protect History This command was first available in ExtremeWare 6.2.2.

  • Page 995: Enable Cpu-Dos-Protect Simulated

    enable cpu-dos-protect simulated enable cpu-dos-protect simulated enable cpu-dos-protect simulated Description Enables simulated denial of service protection. Syntax Description There are no arguments or variables for this command. Default The default is disabled. Usage Guidelines When simulated denial of service protection is enabled, no ACLs are created. This mode is useful to gather information about normal traffic levels on a switch.

  • Page 996: Enable Dhcp Ports Vlan

    Security Commands enable dhcp ports vlan enable dhcp ports <portlist> vlan <vlan name> Description Enables DHCP on a specified port in a VLAN. NOTE This command is available only on the “e” series switches. Syntax Description portlist Specifies the ports for which DHCP should be disabled. vlan name Specifies the VLAN on whose ports DHCP should be disabled.

  • Page 997: Enable Enhanced-Dos-Protect

    enable enhanced-dos-protect enable enhanced-dos-protect enable enhanced-dos-protect {rate-limit | ipfdb} {ports [<portlist> | all]} Description Enables enhanced denial of service protection globally or for selected ports. Syntax Description rate-limit Enables software rate limiting. ipfdb Enables the IPFDB learning qualifier, resulting in reduction of IPFDB thrashing. portlist Specifies one or more ports or slots and ports.

  • Page 998: Enable Ip-Subnet-Lookup

    Security Commands enable ip-subnet-lookup enable ip-subnet-lookup Description Enables IPDA subnet lookup feature in a switch. Syntax Description There are no arguments or variables for this command. Default Disabled Usage Guidelines For a new setting to be effective in the “i” series switches, system rebooting is needed. Rebooting is not needed for the “e”...
  • Page 999 enable ip-subnet-lookup Platform Availability This command is available on all platforms. ExtremeWare 7.5 Command Reference Guide...

  • Page 1000: Enable Mac-Lockdown-Timeout Ports

    Security Commands enable mac-lockdown-timeout ports enable mac-lockdown-timeout ports [<portlist> | all] Description This command enables the MAC address lockdown timeout feature for the specified port or group of ports or for all ports. Syntax Description portlist Specifies one or more ports or slots and ports. On a modular switch, can be a list of slots and ports. On a stand-alone switch, can be one or more port numbers.
