TIMING GEAR AND CAM IDLE GEAR

SST
Shape
COMMON TOOLS
Scraper
INSTRUMENTS
Micrometer
Cylinder gauge
Thickness gauge
Dial gauge
GREASE AND OTHERS
Sealant (Thread Lock Super 5M or equivalent)
REQUIRED ITEMS (J05E)
Part No.
S0942-01100
S0941-11300
Name
Name
Name
Name
Sliding hammer
Socket wrench
Remarks
For removing liquid gasket
Remarks
For measuring the outer diameter of each idle gear shaft
For measuring the inner diameter of each idle gear bush
For measuring idle gear end play
For measuring each gear backlash and camshaft end play
Remarks
Apply to the thread of the rear end plate mounting Torx bolt.
3–21
EN01F02127020702006011
Remarks
For pulling off the main idle
gear shaft and sub idle gear
shaft
For attaching and detaching
the Torx bolt
