CYLINDER HEAD ASSEMBLY

SST
Shape
COMMON TOOLS
Scraper
INSTRUMENTS
Vernier calipers
Straightedge
Thickness gauge
GREASE AND OTHERS
Liquid gasket (ThreeBond TB1211: White or equivalent)
Dye penetrant (red check)
Liquid gasket (ThreeBond TB1207B: Black or equivalent)
REQUIRED ITEMS (J05E)
Part No.
S0943-31070
S0947-21210
SN441-00610
Name
Name
Name
Name
Eye bolt
Bar
Steel Ball
Remarks
For removing liquid gasket
Remarks
For measuring the under head length of the head bolt
Measuring the strain of bottom surface of cylinder head
and manifold mounting surface
Measuring the strain of bottom surface of cylinder head
and manifold mounting surface
Remarks
Apply to the cylinder block upper surface back end, head
gasket mating area of the flywheel housing, and nozzle
seat lower side.
For checking the cylinder head for cracks and damage
Apply to the mating area of the half-round plug.
3–17
EN01F02127020702006004
Remarks
For attaching and detaching
the cylinder head
For staking the nozzle seat
For staking the nozzle seat
(combined use with S0947-
21210)
