Engine Mechanical; Head Cover; Rocker Arm Assembly; Camshaft Assembly - Hino S5-LJ05E04A Workshop Manual

3–16

HEAD COVER

GREASE AND OTHERS
Liquid gasket (ThreeBond TB1207B: Black or equivalent or
ThreeBond TB1217G: Gray or equivalent)

ROCKER ARM ASSEMBLY

INSTRUMENTS
Micrometer
Cylinder gauge
Thickness gauge
GREASE AND OTHERS
Flexible wire of approximately 0.8 mm {0.0315 in.} in diam-
eter

CAMSHAFT ASSEMBLY

INSTRUMENTS
Micrometer
Cylinder gauge
Dial gauge
Vernier calipers
REQUIRED ITEMS (J05E)

ENGINE MECHANICAL

Name
Name
Name
Name
Remarks
Apply to the mating area of the half-round plug.
Remarks
For measuring the outer diameter of the rocker arm shaft
For measuring the inner diameter of the rocker arm bush
For measuring valve clearance
Remarks
For mounting the rocker arm
Remarks
For measuring the camshaft cam height and journal outer
diameter
For measuring the inner diameter of the camshaft bearing.
For measuring the camshaft runout, camshaft end play,
and backlash
For measuring the under head length of cam the shaft gear
mounting bolt
