1 VEHICLE RECEIPT FOR INSPECTION
YES
2. MANUAL REGENERATION
2
MANUAL REGENERATION
YES
No clean up necessary
Vehicle delivery
EXHAUST (J05E)

OVERALL OPERATION FLOW

1. Check the malfunction code with the HINO-DX.
Standard value: No malfunction code
NO
SHTS021271000056
1. After a manual regeneration, check the differential pressure with
the HINO-DX.
Standard value:
Reference: EXHAUST (J05E), DPR CLEANER, OVERALL
OPERATION FLOW, LIST OF STANDARD VALUES FOR DIF-
FERENTIAL PRESSURE INSPECTION (Page 11-44)
NO
SHTS021271000057
4. For P200C, P244B, P244A, P2459, P2463
5. For others than above
3. INSPECT THE DPR FILTER.
