Def Tank; Dpr Differential Pressure Sensor; Scr Upstream Nox Sensor; Scr Downstream Nox Sensor - Hino S5-LJ05E04A Workshop Manual

3–30

DEF TANK

INSTRUMENTS
DEF analyzer
Refractive index measurement
GREASE AND OTHERS
pH test paper

DPR DIFFERENTIAL PRESSURE SENSOR

INSTRUMENTS
Circuit tester

SCR UPSTREAM NOx SENSOR

INSTRUMENTS
Circuit tester
GREASE AND OTHERS
Anti-seizure lubricant (Weicom Anti-Seize ASW "High-
Tech" Assembly Paste or equivalent)

SCR DOWNSTREAM NOx SENSOR

INSTRUMENTS
Circuit tester
GREASE AND OTHERS
Anti-seizure lubricant (Weicom Anti-Seize ASW "High-
Tech" Assembly Paste or equivalent)
REQUIRED ITEMS (J05E)
Name
Name
Name
Name
Name
Name
Name
Remarks
For DEF measurement
For DEF measurement
Remarks
For DEF measurement
Remarks
For measuring resistance across terminals
Remarks
For measuring resistance across terminals
Remarks
Apply to the threaded portion of SCR upstream NOx sen-
sor
Remarks
For measuring resistance across terminals
Remarks
Apply to the threaded portion of SCR downstream NOx
sensor
