ACCELERATOR PEDAL

STANDARD VALUE, LIMIT AND ACTION
Accelerator sensor 1 output volt-
age
Accelerator sensor 2 output volt-
age
TIGHTENING TORQUE
Tightening part
Accelerator pedal assembly mounting nut

BLOCK HEATER

TIGHTENING TORQUE
Tightening part
Block heater socket mounting bolt
STANDARD VALUE (J05E)
Inspection item
Accelerator fully-closed
Accelerator fully open
Accelerator fully-closed
Accelerator fully open
Standard value
0.6-1.0 V
2.8-3.6 V
1.4-1.8 V
3.6-4.4 V
Tightening torque
5.5 {56, 4}
Tightening torque
1.4-1.7 {14-17, 1.0-1.3}
2–5
EN01F02127010701002005
Action
Replace
Replace
Replace
Replace
Unit: Nm {kgfcm, lbfft}
Remarks
EN01F02127010701002006
Unit: Nm {kgfcm, lbfft}
Remarks
