Oil Pump; Oil Pan; Oil Pressure Switch - Hino S5-LJ05E04A Workshop Manual

OIL PUMP

INSTRUMENTS
Depth gauge
Micrometer
Cylinder gauge
Vernier calipers
Dial gauge

OIL PAN

COMMON TOOLS
Scraper
GREASE AND OTHERS
Liquid gasket (ThreeBond TB1207D: Silver or equivalent or
ThreeBond TB1217G: Gray or equivalent)

OIL PRESSURE SWITCH

INSTRUMENTS
Circuit tester
GREASE AND OTHERS
Liquid gasket (ThreeBond TB1211: White or equivalent)
REQUIRED ITEMS (J05E)
Name
Name
Name
Name
Name
Remarks
For measuring width of drive gear and depth of cylinder
block side pump housing
For measuring the drive gear shaft outer diameter and
driven gear shaft outer diameter
For measuring the cylinder block side bush inner diameter,
driven gear bush inner diameter, cylinder block side pump
housing inner diameter, and cylinder block hole diameter
For measuring the drive gear outer diameter
For measuring the backlashes between the drive gear and
driven gear and between the oil pump drive gear and sub-
idle gear
Remarks
For removing liquid gasket
Remarks
Apply to each part.
Remarks
For measuring continuity between terminal and body
Remarks
Apply to the gasket seal surface.
