GREASE AND OTHERS
Lapping compound

CRANKSHAFT FRONT OIL SEAL

SST
Shape

FRONT OIL SEAL RETAINER

GREASE AND OTHERS
Liquid gasket (ThreeBond TB1207B: Black or equivalent or
ThreeBond TB1217G: Gray or equivalent)

FLYWHEEL ASSEMBLY

SST
Shape
COMMON TOOLS
Brass bar
REQUIRED ITEMS (J05E)
Name
Part No.
S0942-01731
S0940-71030
Name
Part No.
S0948-11340
Name
Remarks
For valve finishing
Name
Oil seal puller
Oil seal press
Remarks
Apply to the front oil seal retainer mounting surface.
Name
Guide
Remarks
For removing the ring gear
3–19
EN01F02127020702006006
Remarks
For pulling off a crankshaft
front oil seal
For press-fitting the crank-
shaft front oil seal
EN01F02127020702006007
EN01F02127020702006008
Remarks
For attaching and detaching
the flywheel
