11–120 EXHAUST (J05E)

REPLACEMENT

REMOVING THE OUTSIDE TEMPERATURE
SENSOR
1. DISCONNECTING THE HARNESS
(1) Disconnect the connector connected to the outside temperature
sensor.
2. REMOVING THE OUTSIDE TEMPERATURE SENSOR
(1) Unfasten the clamp to remove the outside temperature sensor
from the bracket.
OUTSIDE
TEMPERATURE
SENSOR
SHTS021271000208
MOUNTING THE OUTSIDE TEMPERATURE
SENSOR
1. MOUNTING THE OUTSIDE TEMPERATURE SENSOR
(1) Mount the outside temperature sensor to the bracket with the
clamp.
2. CONNECTING THE HARNESS
(1) Connect the connector to the outside temperature sensor.
OUTSIDE
TEMPERATURE
SENSOR
SHTS021271000209
