Hino S5-LJ05E04A Workshop Manual page 606

13–32
OIL COOLER CASE
GASKET
OIL PRESSURE
SWITCH
LUBRICATION (J05E)
MOUNTING THE OIL PRESSURE SWITCH
1.
(1)
(2)
OIL PRESSURE
SWITCH
SHTS021271200064
(3)
OIL COOLER
CASE
HARNESS
SHTS021271200065
2.
(1)
MOUNTING THE OIL PRESSURE SWITCH
Apply liquid gasket (ThreeBond TB1211: White or equivalent) to
the sealing surface of a new gasket.
Mount the gasket and oil pressure switch to the oil cooler case.
Tightening Torque:
24.5 N·m {250 kgf·cm, 18 lbf·ft}
Connect the connector to the oil pressure switch.
ADDING ENGINE OIL
Inspect the engine oil level. If insufficient, add engine oil.
Reference: MOUNTING AND DISMOUNTING THE ENGINE
(J05E), ENGINE ASSEMBLY, REPLACEMENT, NEXT STEPS
AFTER INSTALLATION (Page 5-14)
