COLLAR
PRESS
ROTOR SHAFT
JIG C
(FOR PRESS)
STARTING/CHARGING (J05E)
4.
FAN
SHTS021271500037
5.
6.
(1)
NOTICE
DRIVE FRAME
Do not drop the rotor.
JIG A
SHTS021271500038
7.
(1)
BEARING
COVER
SHTS021271500039
(2)
PRESS
NOTICE
FRONT BEARING Do not drop the front bearing.
JIG C
(FOR
SUPPORT)
SHTS021271500040
REMOVING THE FAN
REMOVING THE COLLAR
REMOVING THE ROTOR
Using the JIG A and press, remove the rotor from the drive frame.
REMOVING THE FRONT BEARING
Remove the 3 screws to remove the bearing cover.
Using the JIG C and press, remove the front bearing from the
drive frame.
