10–74
TORQUES
BOLT
ENGINE MECHANICAL (J05E)
(2) Use the cylinder gauge to measure the inner diameter of the idle
gear bushing.
SHTS021270900155
(3) Calculate the difference between the outer diameter of the idle
gear shaft and the inner diameter of the idle gear bush. If the
measurement reading exceeds the permissible limit, replace the
idle gear shaft and idle gear.
MOUNTING THE TIMING GEARS IN THE FLYWHEEL
HOUSING AND THE REAR END PLATE
1. MOUNTING REAR END PLATE
(1) Replace with the new gasket and install the rear end plate.
! CAUTION
CYLINDER
Check that no dirt, fouling or foreign matters remain in the
BLOCK
threaded holes or on the mounting surface on the cylinder block.
(2) Apply the sealant (Thread Lock Super 5M or equivalent) to
threads of the torque bolts.
(3) Use the SST, mount the torque bolts.
REAR END
SST:
PLATE
Tightening Torque:
SHTS021270900156
55 N·m {561 kgf·cm, 41 lbf·ft}
Measured item
Shaft outer
diameter
Main idle gear
Bushing inner
diameter
Shaft outer
diameter
Sub idle gear
Bushing inner
diameter
Shaft outer
diameter
Cam idle gear
Bushing inner
diameter
Standard value
Measured item
(mm {in.})
0.030-0.090
Main idle gear
{0.0012-0.0035}
0.025-0.075
Sub idle gear
{0.0010-0.0030}
0.025-0.075
Cam idle gear
{0.0010-0.0030}
S0941-11300
Socket wrench
Standard value
(mm {in.})
57 {2.244}
57 {2.244}
50 {1.969}
50 {1.969}
34 {1.339}
34 {1.339}
Permissible limit
(mm {in.})
0.20 {0.0079}
0.20 {0.0079}
0.20 {0.0079}
