This supplement has been prepared to provide information covering general service repairs for DUTRO
which underwent changes in December, 2003.
Applicable models:
For the service specifications and repair procedures of the above model other than those listed in the supple-
ment, refer to the following manuals.
S
DUTRO Chassis Workshop Manual
S
DUTRO Electrical Wiring Diagram
DUTRO Electrical Wiring Diagram
S
N04C−TF Engine Workshop Manual
S
S05C Engine Workshop Manual
S
M550 Manual Transmission Workshop Manual
S
H260 Manual Transmission Workshop Manual
S
H350 Manual Transmission Workshop Manual
S
All information in this manual is based on the latest product information at the time of publication. However,
specifications and procedures are subject to change without notice.
If you find any failures in this manual, you are kindly requested to inform us by using the report form on the
next page.
FOREWORD
XZU 305, 345, 404, 414, 424, 434 series
Manual Name
Pub. No.
S1−YXZE05
S1−YXZE05A−SL
S1−YXZE10A−SL
S5−YN04E01A
S5−YS05E06A
S1−YXZE09A
S1−YXZE07A
S1−YXZE06A
