Hino S5-LJ05E04A Workshop Manual page 237

ELEMENT
COVER
EMISSION CONTROL (J05E)
2. MOUNTING THE ELEMENT
(1) Replace with a new O-ring and apply engine oil. Mount it to the
CAP
cap.
(2) Replace with a new element and mount it by aligning with the
body center boss.
O-RING
BODY
CENTER
BOSS
SHTS021270700020
(3) Mount the cap by turning clockwise until it lifts up.
! CAUTION
CAP
• Do not tighten the cap excessively.
• The O-ring is nonreusable.
•
Remove the dirt or foreign matter on the O-ring mounting
surface.
NOTICE
It is recommended that the element of the closed ventilator be
replaced once after replacing the oil filter twice.
CLOSED
Reference: LUBRICATION (J05E), OIL FILTER, REPLACEMENT,
VENTILATOR
REMOVING THE OIL FILTER (Page 13-4)
SHTS021270700021
(4) Mount the closed ventilator cover from the 2 bolts.
Tightening Torque:
SHTS021270700022
31 N·m {316 kgf·cm, 23 lbf·ft}
8–13
