3–34

RADIATOR CAP

INSTRUMENTS
Radiator cap tester (commercially available)

THERMOSTAT CASE AND THERMOSTAT

INSTRUMENTS
Vernier calipers
COMMON TOOLS
Scraper
GREASE AND OTHERS
Liquid gasket (ThreeBond TB1207B: Black or equivalent)
REQUIRED ITEMS (J05E)

COOLING

Name
Name
Name
Name
Remarks
For measuring valve opening pressure
Remarks
For measuring valve lift amount
Remarks
For removing liquid gasket
Remarks
Apply to the joining surface of the thermostat case.
EN01F02127020702008001
