COMMON TOOLS
Scraper
INSTRUMENTS
Cylinder gauge
Micrometer
Thickness gauge
Vernier calipers
Dial gauge
GREASE AND OTHERS
Sandpaper (about No.150)
Dye penetrant (red check)
Bar of 4 mm {0.1574 in.} in diameter
REQUIRED ITEMS (J05E)
Name
Name
Name
Remarks
Removing carbon
Remarks
For measuring the cylinder liner inner diameter, piston boss
inner diameter, connecting rod bush inner diameter, and
connecting rod big end bearing inner diameter
For measuring the piston outer diameter, piston ring thick-
ness, piston pin outer diameter, and crank pin outer diame-
ter
For measuring the piston ring groove and piston ring end
gap clearance
For measuring the under head length of the connecting rod
bolt
For measuring connecting rod end play
Remarks
For removing the carbon adhered to the upper side of inner
surface of the cylinder liner
For checking the connecting rod for cracks and damage
For checking the connecting rod oil hole
3–23
