OIL COOLER

TIGHTENING TORQUE
Tightening part
Oil pressure switch
Plug (safety valve)
Oil cooler element mounting nut
Oil cooler assembly mounting bolt

OIL PUMP

STANDARD VALUE, LIMIT AND ACTION
Inspection item
Width of drive gear
Depth of cylinder block side pump housing
Difference between width of drive gear and
depth of cylinder block side pump housing
Outer diameter of drive gear shaft
Inner diameter of cylinder block side bush
Difference between drive gear shaft outer
diameter and cylinder block side bush inner
diameter
Drive gear outer diameter
Inner diameter of cylinder block side pump
housing
Difference between drive gear outer diameter
and cylinder block pump housing inner diam-
eter
Outer diameter of driven gear shaft
Inner diameter of driven gear bush
Difference between driven gear shaft outer
diameter and driven gear bush inner diameter
Outer diameter of driven gear shaft
Cylinder block side hole diameter
Difference between driven gear shaft outer
diameter and cylinder block side hole diame-
ter
STANDARD VALUE (J05E)

LUBRICATION

Tightening torque
24.5 {250, 18}
24.5-34.3 {250-349, 19-25}
19.6-29.4 {200-299, 15-21}
28.5 {291, 21}
Standard value
28.5 {1.122}
28.5 {1.122}
0.047-0.150
{0.0019-0.0060}
18.0 {0.709}
18.0 {0.709}
0.040-0.099
{0.0016-0.0039}
54.0 {2.126}
54.0 {2.126}
0.093-0.252
{0.0037-0.0099}
18.0 {0.709}
18.0 {0.709}
0.040-0.083
{0.0016-0.0033}
18.0 {0.709}
18.0 {0.709}
0.030-0.075
{0.0012-0.0030}
Unit: Nm {kgfcm, lbfft}
Permissible limit
–
–
0.15 {0.0060}
–
–
–
–
–
0.30 {0.012}
–
–
0.15 {0.0060}
–
–
–
2–33
EN01F02127010701009001
Remarks
EN01F02127010701009002
Unit: mm {in.}
Action
Replace
Replace
Replace
Replace
Replace
Replace
Replace
Replace
Replace
Replace
Replace
Replace
Replace
Replace
Replace
