Field
T1 Bit 23
EFC
T1 Bit 21
FDF
T1 Bit 20
(3)
BRS
T1 Bits 19:16
DLC[3:0]
T2 Bits 31:24
DB3[7:0]
T2 Bits 23:16
DB2[7:0]
T2 Bits 15:8
DB1[7:0]
T2 Bits 7:0
D[7:0]
T3 Bits 31:24
DB7[7:0]
T3 Bits 23:16
DB6[7:0]
T3 Bits 15:8
DB5[7:0]
T3 Bits 7:0
DB4[7:0]
Tn Bits 31:24
DBm[7:0]
Tn Bits 23:16
DBm-1[7:0]
Tn Bits 15:8
DBm-2[7:0]
Tn Bits 7:0
DBm-3[7:0]
Table 393. Tx Buffer element description (continued)
Event FIFO control
– 0: Don't store Tx events
– 1: Store Tx events
FD format
– 0: Frame transmitted in Classic CAN format
– 1: Frame transmitted in CAN FD format
Bit rate switching
– 0: CAN FD frames transmitted without bit rate switching
– 1: CAN FD frames transmitted with bit rate switching
Data length code
– 0 - 8: Classic CAN + CAN FD: received frame has 0-8 data bytes
– 9 - 15: Classic CAN: received frame has 8 data bytes
– 9 - 15: CAN FD: received frame has 12/16/20/24/32/48/64 data bytes
Data Byte 3
Data Byte 2
Data Byte 1
Data Byte 0
Data Byte 7
Data Byte 6
Data Byte 5
Data Byte 4
Data Byte m
Data Byte m-1
Data Byte m-2
Data Byte m-3
