change ip-network-region
Output
change ip-network-region 1
Region: 1
Name:
Audio Parameters
Codec Set: 1
Location: 3
UDP Port Range
Min: 2048
Max: 65535
_
DiffServ/TOS Parameters
Call Control PHB Value:
VoIP Media PHB Value:
BBE PHB Value:
802.1p/Q Enabled? n
Call Control 802.1p Priority:
VoIP Media 802.1p Priority:
guaranteed-service
change ip-network-region 10
Region
1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2
001-032
033-064
065-080
This screen appears when the IP Stations, the H.323 Trunks, and the Remote
Office fields on the System-Parameters Customer-Options screen are enabled.

Field descriptions

Blank indicates there is no connectivity between these network regions.
Region
1 - 7 indicates the preferred codec set that you should use between these
network regions.
555-233-119
IP Network Region
Direct IP-IP Audio Connections? n
RTCP Monitor Server Parameters
Use Default Server Parameters? n
Resource Reservation Parameters
Retry upon RSVP Failure Enabled? y
802.1Q VLAN:
Inter Network Region Connection Management
(Group of 32)
4
IP Audio Hairpinning? y
RTCP Enabled? y
Server IP Address: ___.___.___.__
Server Port: _____
RTCP Report Period(secs): __
RSVP Enabled? y
RSVP Refresh Rate(secs):
RSVP Profile:
Issue 5 October 2002
Page 1 of 2
Page 2 of 2
183
