Change Synchronization - Avaya DEFINITY Server CSI Maintenance Manual

Maintenance Commands

change synchronization

Use change synchronization to specify the hierarchy of sources used for timing
synchronization. DS1 inputs to the external stratum 3 clock affect stratum 3
synchronization hierarchy. Primary and secondary fields reflect Stratum 4
synchronization. If all fields are blank, the tone clock board within each PN
provides timing for that PN.
Action/Object Qualifier
change
synchronization
Output/Input
The following example shows the output for change synchronization with 4
entered in the Stratum field.
change synchronization
SYNCHRONIZATION SOURCE (circuit pack location)
Stratum: 4
Primary: _____
Location Name
NOTE: DS1 and BRI trunk sources will result in stratum 4, type II ynchronization
The following example shows the output for change synchronization with 3
entered in the Stratum field.
change synchronization
SYNCHRONIZATION SOURCE (DS1 circuit pack location)
Stratum: 3
Port Network: 1
184
Issue 5 October 2002
Qualifier Description
Examples:
change
synchronization
change synch
SYNCHRONIZATION PLAN
Secondary: _____
Slip Location
SYNCHRONIZATION PLAN
Logins Default Feature Interactions
init none DS1 interface, BRI trunk, or
inads UDS1 board selected as a
craft primary or secondary synch
cust source cannot be removed
rcust on the DS1 circuit pack
bcms administration form or the
regular circuit pack
administration form.
Name Slip
Page 1 of 1
Page 1 of 1
555-233-119
