display system-parameters duplication

Field descriptions
Synchronization stratum that is used (3 or 4)
Stratum
First choice system synchronization source (blank = no synchronization);
Primary
valid only if stratum 4 synchronization specified
Second choice system synchronization source (blank = no
Secondary
synchronization); valid only if stratum 4 synchronization specified
Circuit pack location (cabinet-carrier-slot) of all administered DS1 circuit
Location
packs are listed here.
User-defined name administered for the DS1 circuit pack. Blank means
Name
no user-defined name administered.
If the DS1 circuit pack has slip alarm, field shows y; otherwise, n.
Slip
Stratum 3 only; specifies the port network supplying synchronization
Port Network
through the tone clock circuit pack.
display system-parameters duplication
Use display system-parameters duplication to display the status (enabled or
disabled) of Switch Processing Element (SPE) and Port Network Connectivity
(PNC) duplication.
The following must be duplicated:
Each switch node record and every switch node with its duplicate (cabinet
administration is a prerequisite).
Every fiber link containing either an expansion interface circuit pack as an
endpoint, or a DS1-C (fiber link administration is a prerequisite, and circuit
pack administration follows duplication administration).
All nonduplicated switch node interfaces (SNI) to SNI fiber links are automatically
duplicated.
NOTE:
Use change System-Parameters Customer-Options to access the
Customer Options screen, and enter y in the PNC Duplication field before
any duplication administration.
PNC Duplication cannot be enabled until all pnc-a and pnc-b boards are
released from the "busyout" state.
