Maintenance Commands
Output (Page Three)
The following example shows Page 3 of change system-parameters
maintenance.
change system-parameters maintenance
Modem Connection: external
Data Bits: 8
Modem Name: _______
RTS/CTS Enabled: \Q3
Asynchronous Data Mode: &M0&Q0
DTE Auto-Data Speed: ______
Disable Data Compression: ______
Enable Error Control: ______
Misc. Init. Param: ______________
Field descriptions (Page Three)
Modem
Connection M
Data Bits
Parity
Modem Name
RTS/CTS Enabled
Asynchronous
Data Mode
194
Issue 5 October 2002
MAINTENANCE-RELATED SYSTEM PARAMETERS
Parity: none
Auto Answer Ring Count (rings): S0=10
Valid entries are internal or external. 11 fields disappear when
the Modem Connection field is set to internal.
These two fields establish the data format for transmitting serial
data from the switch to the modem. Valid combinations are:
Data Bits = 8, Parity = None
Data Bits = 7, Parity = (odd, even, mark, or space)
Enter up to 20 characters to provide a qualifier for a modem.
Enter up to 6 characters to informs the modem that communication
with the data source UART will be driven with RTS/CTS flow
control. (\Q3)
Enter up to 8 characters to configure the modem as an
asynchronous communications device. (&M0&Q0)
Adjustable Make/Break Ratio:
Dial Command: D
No Answer Time-out: S7=255
Page 3 of 3
Dial Type: T
