Avaya DEFINITY Server CSI Maintenance Manual page 150

Maintenance for CSI systems
A500:show switch circuit
_______________________________________________________
| Input |
| port vpi vci| port vpi
|______________|______________|_________________________|
A1.1 0 5
A1.1 0 32
A1.1 0 35
A1.2 0 5
A1.2 0 32
A1.2 0 34
Self 0 1
Self 0 2
_________________________________________________________
Screen 45. A500:show switch circuit screen
— The pmp CBR (Constant Bit Rate) virtual circuits (VCs) between
— They are established when calls are first setup between port
— The report above shows one complete talk path: one unidirectional
— These virtual circuits may persist beyond the duration of a phone
— In early version of the Release 2 A500 firmware, these connections
— There may be other CBR virtual circuits between A500 ports that are
150
Issue 5 October 2002
Output |
vci| type class
Self 0 1 pp UBR
A1.2 0 32 pp VBRnrt pcr=5729
A1.2 0 35 pmp CBR
Self 0 2 pp UBR
A1.1 0 32 pp VBRnrt pcr=5729
A1.1 0 34 pmp CBR
A1.1 0 5 pp UBR
A1.2 0 5 pp UBR
A500 port A1.1 (PPN) and A500 port A1.2 (EPN) are used for talk
paths between port networks (PPN to EPN, EPN to PPN, or EPN to
EPN).
networks. Each virtual circuit represents one party of a complete
multiparty talk path.
point-to-multipoint virtual circuit from A1.1 to A1.2, and another from
A1.2 to A1.1.
call. The Avaya MultiVantage Software saves virtual circuits for a
few seconds after the end stations have hung up in case the VC can
be used again for another call between the same two port networks.
incorrectly identified as pmp UBR.
not associated with Avaya Definity Server CSI port networks. A
common CBR application is Circuit Emulation, in which T-1, T-3, etc.
circuits are carried over ATM.
Connection |
parameters |
ppd on
/scr=5729
pcr=173
ppd on
/scr=5729
pcr=173
ppd on
ppd on
/mbs=17187
/mbs=17187
555-233-119
