8.2

NVIC programmer's model

8.2.1 NVIC register map
Name of register
Interrupt Control Type Register
Auxiliary Control Register
SysTick Control and Status Register
SysTick Reload Value Register
SysTick Current Value Register
SysTick Calibration Value Register
Irq 0 to 31 Set Enable Register
.
.
.
Irq 224 to 239 Set Enable Register
ARM DDI 0337G
Unrestricted Access
This section lists and describes the NVIC registers. It contains the following:
• NVIC register map
• NVIC register descriptions on page 8-7.
Table 8-1 lists the NVIC registers. The System Control space includes the NVIC. The
NVIC space is split as follows:
•
0xE000E000 - 0xE000E00F
• 0xE000E010 - 0xE000E0FF
•
0xE000E100 - 0xE000ECFF
•
0xE000ED00 - 0xE000ED8F
— CPUID
— System control, configuration, and status
— Fault reporting
• 0xE000EF00 - 0xE000EF0F
•
0xE000EFD0 - 0xE000EFFF.
Read/write
Copyright © 2005-2008 ARM Limited. All rights reserved.
. Interrupt Type Register
. System Timer
. NVIC
. System Control Block, including:
. Software Trigger Exception Register
ID space.
Type
Read-only
Read/write
Read/write
Read/write
Read/write clear
Read-only
.
.
.
Read/write
Non-Confidential
Nested Vectored Interrupt Controller

Table 8-1 NVIC registers

Reset
Address
value
0xE000E004 a
0xE000E008 0x00000000
0xE000E010 0x00000000
Unpredictable
0xE000E014
0xE000E018 Unpredictable
0xE000E01C STCALIB
0xE000E100 0x00000000
. .
. .
. .
0xE000E11C 0x00000000
Page
page 8-7
page 8-8
page 8-9
page 8-10
page 8-11
page 8-12
page 8-13
.
.
.
page 8-13
8-3
