18.2
Processor instruction timings
Instruction type
Size
Data operations
16
Branches
16
Load-store Single
16
Load-store
16
Multiple
Exception
16
generating
Data operations
32
with immediate
Data operations
32
with large
immediate
Bit-field
32
operations
Data operations
32
with 3 register
ARM DDI 0337G
Unrestricted Access
Table 18-1 shows the Thumb subset supported in the ARMv7-M architecture. It
provides cycle information including annotations to explain how instruction stream
interactions affect timing. System effects, such as running code from slower memory,
are also considered.
Cycles count
a
1 (+P
if PC is destination)
a
1+P
b
a
2
(+P
if PC is destination)
b
a
1+N
(+P
if PC loaded)
-
a
1 (+P
if PC is destination)
1
1
a
1 (+P
if PC is destination)
Copyright © 2005-2008 ARM Limited. All rights reserved.
Description
ADC, ADD, AND, ASR, BIC, CMN, CMP, CPY, EOR,
LSL, LSR, MOV, MUL, MVN, NEG, ORR, ROR, SBC,
SUB, TST, REV, REV16, REVSH, SXTB, SXTH, UXTB,
and UXTH. MUL is one cycle.
B<cond>, B, BL, BX, and BLX. No BLX with immediate.
If branch taken, pipeline reloads (two cycles are added).
LDR, LDRB, LDRH, LDRSB, LDRSH, STR, STRB, and
STRH, and T variants.
LDMIA, POP, PUSH, and STMIA.
BKPT stops in debug if debug enabled, fault if debug
disabled.
SVC faults to SVCall handler, see ARMv7-M architecture
specification for details.
ADC{S}. ADD{S}, CMN, RSB{S}, SBC{S}, SUB{S},
CMP, AND{S}, TST, BIC{S}, EOR{S}, TEQ, ORR{S},
MOV{S}, ORN{S}, and MVN{S}.
MOVW, MOVT, ADDW, and SUBW. MOVW and MOVT
have a 16-bit immediate (so can replace literal loads from
memory). ADDW and SUBW have a 12-bit immediate (so
also can replace many from memory literal loads).
BFI, BFC, UBFX, and SBFX. These are bitwise operations
that enable control of position and size in bits. These both
support C/C++ bit fields (in structs) in addition to many
compare and some AND/OR assignment expressions.
ADC{S}. ADD{S}, CMN, RSB{S}, SBC{S}, SUB{S},
CMP, AND{S}, TST, BIC{S}, EOR{S}, TEQ, ORR{S},
MOV{S}, ORN{S}, and MVN{S}. No PKxxx
instructions.
Non-Confidential
Instruction Timing
Table 18-1 Instruction timings
18-3
