Compare negation of register value with another register value
Compare immediate 8-bit value
Compare registers
Compare high register to low or high register
Change processor state
Copy high or low register value to another high or low register
Bitwise exclusive OR register values
Condition the following instruction
Condition the following two instructions
Condition the following three instructions
Condition the following four instructions
Multiple sequential memory word loads
Load memory word from base register address + 5-bit immediate offset
Load memory word from base register address + register offset
Load memory word from PC address + 8-bit immediate offset
Load memory word from SP address + 8-bit immediate offset
Load memory byte [7:0] from register address + 5-bit immediate offset
Load memory byte [7:0] from register address + register offset
Load memory halfword [15:0] from register address + 5-bit immediate offset
Load halfword [15:0] from register address + register offset
Load signed byte [7:0] from register address + register offset
Load signed halfword [15:0] from register address + register offset
Logical shift left by immediate number
Logical shift left by number in register
Logical shift right by immediate number
Logical shift right by number in register
2-14
Table 2-4 16-bit Cortex-M3 instruction summary (continued)
Copyright © 2005-2008 ARM Limited. All rights reserved.
Non-Confidential
Assembler
CMN <Rn>, <Rm>
CMP <Rn>, #<immed_8>
CMP <Rn>, <Rm>
CMP <Rn>, <Rm>
CPS <effect>, <iflags>
CPY <Rd> <Rm>
EOR <Rd>, <Rm>
IT <cond>
IT<x> <cond>
IT<x><y> <cond>
IT<x><y><z> <cond>
LDMIA <Rn>!, <registers>
LDR <Rd>, [<Rn>, #<immed_5> * 4]
LDR <Rd>, [<Rn>, <Rm>]
LDR <Rd>, [PC, #<immed_8> * 4]
LDR, <Rd>, [SP, #<immed_8> * 4]
LDRB <Rd>, [<Rn>, #<immed_5>]
LDRB <Rd>, [<Rn>, <Rm>]
LDRH <Rd>, [<Rn>, #<immed_5> * 2]
LDRH <Rd>, [<Rn>, <Rm>]
LDRSB <Rd>, [<Rn>, <Rm>]
LDRSH <Rd>, [<Rn>, <Rm>]
LSL <Rd>, <Rm>, #<immed_5>
LSL <Rd>, <Rs>
LSR <Rd>, <Rm>, #<immed_5>
LSR <Rd>, <Rs>
