General-purpose I/Os (GPIO)
10.4.2 GPIOx output type register (GPIOx_OTYPER) (x = A to B)
Address offset: Block A: 0x0004
Address offset: Block B: 0x0404
Reset value: 0x0000 0000
31 30 29 28
Res. Res. Res. Res.
15 14 13 12
OT15 OT14 OT13 OT12
rw rw rw rw
Bits 31:16 Reserved, must be kept at reset value.
Bits 15:0 OTy: Port Pxy output type configuration (y = 15 to 0)
10.4.3 GPIOx output speed register (GPIOx_OSPEEDR) (x = A to B)
Address offset: Block A: 0x0008
Address offset: Block B: 0x0408
Reset value: Block A: 0x0C00 0000
Reset value: Block B: 0x0000 00C0
31 30 29
OSPEED15[1:0] OSPEED14[1:0] OSPEED13[1:0]
rw rw rw
15 14 13
OSPEED7[1:0] OSPEED6[1:0]
rw rw rw
Bits 31:0 OSPEEDy[1:0]: Port Pxy output speed configuration (y = 15 to 0)
Note: Refer to the device datasheet for the frequency specifications and the power supply
410/1450
27 26 25
Res. Res. Res.
11 10 9
OT11 OT10 OT9
rw rw rw
These bits are written by software to configure the I/O output type.
0: Output push-pull (reset state)
1: Output open-drain
28 27 26 25
OSPEED12[1:0]
rw rw rw rw
12 11 10 9
OSPEED5[1:0] OSPEED4[1:0]
rw rw rw rw
These bits are written by software to configure the I/O output speed.
00: Low speed
01: Medium speed
10: Fast speed
11: High speed
and load conditions for each speed.
24 23 22
Res. Res. Res. Res.
8 7 6
OT8 OT7 OT6 OT5
rw rw rw
24 23 22
OSPEED11[1:0]
rw rw rw
8 7 6
OSPEED3[1:0]
rw rw rw
