STMicroelectronics STM32WL5 Series Reference Manual page 517

RM0453
16.6.4 EXTI pending register (EXTI_PR1)
Address offset: 0x00C
Reset value: 0x0000 0000
Contains only register bits for configurable events.
31 30 29
Res. Res. Res. Res.
15 14 13
PIF15 PIF14 PIF13 PIF12
rw rw rw
Bits 31:23 Reserved, must be kept at reset value.
Bit 22 PIF22: pending bit on event input 22
Bit 21 PIF21: pending bit on event input 21
Bits 20:17 Reserved, must be kept at reset value.
Bit 16 PIF16: pending bit on event input 16
Bit 15 PIF15: pending bit on event input 15
Bit 14 PIF14: pending bit on event input 14
Bit 13 PIF13: pending bit on event input 13
Bit 12 PIF12: pending bit on event input 12
Bit 11 PIF11: pending bit on event input 11
Bit 10 PIF10: pending bit on event input 10
Bit 9 PIF9: pending bit on event input 9
Bit 8 PIF8: pending bit on event input 8
Bit 7 PIF7: pending bit on event input 7
Bit 6 PIF6: pending bit on event input 6
Bit 5 PIF5: pending bit on event input 5
Bit 4 PIF4: pending bit on event input 4
Bit 3 PIF3: pending bit on event input 3
Bit 2 PIF2: pending bit on event input 2
Bit 1 PIF1: pending bit on event input 1
Bit 0 PIF0: pending bit on event input 0
28 27 26 25
Res. Res. Res.
12 11 10 9
PIF11 PIF10 PIF9
rw rw rw rw
These bits are set when the selected edge event or an EXTI_SWIER software trigger arrives
on the configurable event line. This bit is cleared by writing 1 to it.
0: No trigger request occurred.
1: Trigger request occurred.
Extended interrupts and event controller (EXTI)
24 23 22
Res. Res. PIF22 PIF21
rw
8 7 6
PIF8 PIF7 PIF6
rw rw rw
RM0453 Rev 5
21 20 19 18
Res. Res. Res.
rw
5 4 3 2
PIF5 PIF4 PIF3 PIF2
rw rw rw rw
17 16
Res. PIF16
rw
1 0
PIF1 PIF0
rw rw
517/1450
