Bit 8 Reserved, must be kept at reset value.
Bits 7:3 Reserved, must be kept at reset value.
Bits 2:0 MODE1[2:0]: DAC channel1 mode
These bits can be written only when the DAC is disabled and not in the calibration mode
(when bit EN1 = 0 and bit CEN1 = 0 in the DAC_CR register). If EN1 = 1 or CEN1 = 1 the
write operation is ignored.
They can be set and cleared by software to select the DAC channel1 mode:
– DAC channel1 in Normal mode
000: DAC channel1 is connected to external pin with Buffer enabled
001: DAC channel1 is connected to external pin and to on chip peripherals with Buffer
enabled
010: DAC channel1 is connected to external pin with Buffer disabled
011: DAC channel1 is connected to on chip peripherals with Buffer disabled
– DAC channel1 in sample & hold mode
100: DAC channel1 is connected to external pin with Buffer enabled
101: DAC channel1 is connected to external pin and to on chip peripherals with Buffer
enabled
110: DAC channel1 is connected to external pin and to on chip peripherals with Buffer
disabled
111: DAC channel1 is connected to on chip peripherals with Buffer disabled
Note: This register can be modified only when EN1 = 0.
19.7.10
DAC channel1 sample and hold sample time register
(DAC_SHSR1)
Address offset: 0x40
Reset value: 0x0000 0000
31
30
29
Res.
Res.
Res.
Res.
15
14
13
Res.
Res.
Res.
Res.
Bits 31:10 Reserved, must be kept at reset value.
Bits 9:0 TSAMPLE1[9:0]: DAC channel1 sample time (only valid in Sample and hold mode)
These bits can be written when the DAC channel1 is disabled or also during normal operation.
in the latter case, the write can be done only when BWST1 of DAC_SR register is low, If
BWST1 = 1, the write operation is ignored.
Note:
It represents the number of LSI clocks to perform a sample phase. Sampling time =
(TSAMPLE1[9:0] + 1) x LSI clock period.
28
27
26
25
Res.
Res.
Res.
12
11
10
9
Res.
Res.
rw
24
23
22
Res.
Res.
Res.
8
7
6
TSAMPLE1[9:0]
rw
rw
rw
RM0453 Rev 5
Digital-to-analog converter (DAC)
21
20
19
18
Res.
Res.
Res.
Res.
5
4
3
2
rw
rw
rw
rw
17
16
Res.
Res.
1
0
rw
rw
613/1450
