RM0453
4.10

FLASH registers

4.10.1

FLASH access control register (FLASH_ACR)

Address offset: 0x000
Reset value: 0x0000 0600
31 30 29
Res. Res. Res. Res.
15 14 13
PES Res. Res. DCRST ICRST
rw
Bits 31:17 Reserved, must be kept at reset value.
Bit 16 EMPTY: Flash user area empty
Bit 15 PES: CPU1 program/erase suspend request
Bits 14:13 Reserved, must be kept at reset value.
Bit 12 DCRST: CPU1 data cache reset
Bit 11 ICRST: CPU1 instruction cache reset
Bit 10 DCEN: CPU1 data cache enable
Bit 9 ICEN: CPU1 instruction cache enable
28 27 26 25
Res. Res. Res.
12 11 10 9
DCEN ICEN
rw rw rw rw
When read, this bit indicates whether the first location of the user flash is erased or has a
programmed value.
0: Read: user flash programmed
1: Read: user flash empty
0: Flash program and erase operations granted
1: Any new flash program and erase operation is suspended until this bit and the same bit in
FLASH_C2ACR are cleared. The PESD bit in FLASH_SR and FLASH_C2SR areset when
at least one PES bit in FLASH_ACR or FLASH_C2ACR is set.
0: CPU1 data cache not reset
1: CPU1 data cache reset
This bit can be written only when the data cache is disabled.
0: CPU1 instruction cache not reset
1: CPU1 instruction cache reset
This bit can be written only when the instruction cache is disabled.
0: CPU1 data cache disabled
1: CPU1 data cache enabled
0: CPU1 instruction cache disabled
1: CPU1 instruction cache enabled
24 23 22
Res. Res. Res.
8 7 6
PRFTEN Res. Res.
rw
RM0453 Rev 5
Embedded flash memory (FLASH)
21 20 19 18
Res. Res. Res. Res.
5 4 3 2
Res. Res. Res.
rw
17 16
Res. EMPTY
rw
1 0
LATENCY[2:0]
rw rw
129/1450
