RM0453
Note: The ICACHE and DCACHE must be flushed only when disabled (ICEN or DCEN = 0).
4.4

FLASH option bytes

4.4.1

Option bytes description

The option bytes can be read from the memory locations listed in the table below or from the
following option byte registers:
• FLASH option register (FLASH_OPTR)
•
FLASH PCROP zone A start address register (FLASH_PCROP1ASR)
• FLASH PCROP zone A end address register (FLASH_PCROP1AER)
•
FLASH PCROP zone B start address register (FLASH_PCROP1BSR)
• FLASH PCROP zone B end address register (FLASH_PCROP1BER)
•
FLASH WRP area A address register (FLASH_WRP1AR)
•
FLASH WRP area B address register (FLASH_WRP1BR)
•
FLASH IPCC mailbox data buffer address register (FLASH_IPCCBR)
•
FLASH CPU2 access control register (FLASH_C2ACR)
•
FLASH secure SRAM start address and CPU2 reset vector register (FLASH_SRRVR)
(1)
Address
0x1FFF 7800
0x1FFF 7808
0x1FFF 7810
0x1FFF 7818
0x1FFF 7820
0x1FFF 7828
0x1FFF 7830
0x1FFF 7838
to
0x1FFF 7860
0x1FFF 7868

Table 16. Option bytes organization

WRP1A_END[6:0]
WRP1B_END[6:0]
RM0453 Rev 5
Embedded flash memory (FLASH)
RDP[7:0]
PCROP1A_STRT[7:0]
PCROP1A_END[7:0]
WRP1A_STRT[6:0]
WRP1B_STRT[6:0]
PCROP1B_STRT[7:0]
PCROP1B_END[7:0]
IPCCDBA[13:0]
113/1450
154
