Extended interrupts and event controller (EXTI)
16.6.11
EXTI interrupt mask register (EXTI_CnIMR2)
Address offset: Block 1: 0x090
Address offset: Block 2: 0x0D0
Reset value: 0x0000 0000
31
30
29
Res.
Res.
Res.
Res.
15
14
13
Res.
IM46
IM45
IM44
rw
rw
Bits 31:15 Reserved, must be kept at reset value.
Bit 14 IM46: Wake-up with interrupt mask on event input 46
Bit 13 IM45: Wake-up with interrupt mask on event input 45
Bit 12 IM44: Wake-up with interrupt mask on event input 44
Bit 11 IM43: Wake-up with interrupt mask on event input 43
Bit 10 IM42: Wake-up with interrupt mask on event input 42
Bit 9 IM41: Wake-up with interrupt mask on event input 41
Bit 8 IM40: Wake-up with interrupt mask on event input 40
Bit 7 IM39: Wake-up with interrupt mask on event input 39
Bit 6 IM38: Wake-up with interrupt mask on event input 38
Bit 5 IM37: Wake-up with interrupt mask on event input 37
Bit 4 IM36: Wake-up with interrupt mask on event input 36
Bit 3 Reserved, must be kept at reset value.
Bit 2 IM34: Wake-up with interrupt mask on event input 34
Bits 1:0 Reserved, must be kept at reset value.
16.6.12
EXTI event mask register (EXTI_CnEMR2)
Address offset: Block 1: 0x094
Address offset: Block 2: 0x0D4
Reset value: 0x0000 0000
31
30
29
Res.
Res.
Res.
Res.
15
14
13
Res.
Res.
Res.
Res.
522/1450
28
27
26
25
Res.
Res.
Res.
12
11
10
9
IM43
IM42
IM41
rw
rw
rw
rw
0: Wake-up with interrupt request from line 46 is masked.
1: Wake-up with interrupt request from line 46 is unmasked.
28
27
26
25
Res.
Res.
Res.
12
11
10
9
Res.
Res.
EM41
rw
24
23
22
Res.
Res.
Res.
8
7
6
IM40
IM39
IM38
IM37
rw
rw
rw
24
23
22
Res.
Res.
Res.
8
7
6
EM40
Res.
Res.
rw
RM0453 Rev 5
21
20
19
18
Res.
Res.
Res.
Res.
5
4
3
2
IM36
Res.
IM34
rw
rw
rw
21
20
19
18
Res.
Res.
Res.
Res.
5
4
3
2
Res.
Res.
Res.
Res.
RM0453
17
16
Res.
Res.
1
0
Res.
Res.
17
16
Res.
Res.
1
0
Res.
Res.
